- Page 1 WIRELESS DUAL-BAND N+ moDEm-RoUTER PLAY N600 DB User Manual F9J1102 8820au00841 Rev.A01 English...
-
Page 2: Table Of Contents
Enabling Auto Update on Your Belkin Router . . . . . . . . . . . . . . . . . -
Page 3: Getting Started
Raising the Router above Ethernet Cable floor level can improve the strength of your wireless signal. Network information card (attached to router) Belkin Setup CD with User Manual... - Page 4 GettInG StaRted How to Set It Up *Filter may be required...
- Page 5 2. Plug the Router’s power supply into a wall outlet. 3. Put the CD into your computer. If the CD doesn’t open automatically, please browse to your CD drive and double-click on the Belkin Setup CD icon. Setup 4. Click the Setup icon on the CD menu.
- Page 6 GettInG StaRted 5. After a brief installation, the setup software will ask you for the network name and password from the network information card that is attached to your Router. Store the card under the base of your Router for future reference.
- Page 7 This may take a few minutes to complete. Once finished, a “Success” message will appear indicating that you are connected to the Internet via your new Belkin Router. during setup you may be asked for additional information. You may need to enter a username and password provided by your ISP.
-
Page 8: Advanced Tools & Settings
GettInG StaRted advanced tools & Settings After the initial setup is complete, you have the option to change settings like your network name, security type, and password. To make these changes and others, click on the Advanced Tools icon at the CD Setup menu and select one of the following settings that you would like to change: network name &... -
Page 9: The Belkin Router Manager
To access the Router settings, click on the icon and select from the menu that appears. Video Mover The status of your Router is shown by the Belkin Router Manager Check for Updates icon, which closely mimics the light on the front of the Router. -
Page 10: Manual Setup Using Your Browser
GettInG StaRted Manual Setup Using Your Browser In your browser, type “http://router” (you do not need to type in anything else such as “www”). Then press the Enter key. If you’re still having trouble running the manual setup option, type “192.168.2.1”... -
Page 11: Adding Computers To Your Network
This may take a few minutes to complete. Once finished, a “Success” message will appear indicating that you are connected to the Internet via your new Belkin Router. note: The setup software runs only on Windows and Mac OS X systems. - Page 12 2. Within two minutes, press the WPS button on 2. Select your Belkin Router from the list of available networks. You your Router and hold for two seconds. can identify your Belkin Router by locating the network name (SSID) from the card located underneath the foot of your Router.
-
Page 13: Adding Usb Devices
GettInG StaRted adding USB devices... - Page 14 You can manually check the status of your shared drive by visiting You can manually check the status of your printer by visiting the the USB Print and Storage Manager, found under the Belkin Router USB Print and Storage Manager, found under the Belkin Router...
- Page 15 Router. When the light above the USB port is lit, your device is available to computers on your network. Computers running the Belkin USB Print and Storage Manager will be able to make use of the shared device by visiting the USB Print and Storage Manager, found under the Belkin Router Manager icon displayed in your system tray (Windows) or menu bar (Mac).
-
Page 16: Bundled Software
Memory Safe allows you to set up a routine backup of your files to a hard drive or flash drive attached to your Router. Memory Safe is found in the Belkin Router Manager icon USB Print and Storage Manager displayed in your system tray (Windows) or menu bar (Mac). -
Page 17: Additional Capabilities
GettInG StaRted additional Capabilities Video Mover Video Mover sends media from a USB drive attached to your Router to any UPnP (Universal Plug-and-Play) or DLNA-compatible device on your network. These devices include certain gaming Guest access systems, televisions, Blu-ray players, and cell phones. You can allow guests to use your Internet connection without joining your personal network. -
Page 18: Getting To Know Your Router
GettinG to Know Your router Front Panel B) wi-Fi Protected Setup (wPS) Light and Button The WPS button on the front of your Router can be used to help establish a secure connection between your Router and other WPS-enabled Wi-Fi devices such as computers. To use the WPS feature on your Router, see “Getting Started >... -
Page 19: Back Panel
GettinG to Know Your router Back Panel A) ADSL Connector C) uSB Port D) reset Button Connect your Router to a USB printers, disks, and other This button is used to restart phone jack using a telephone USB devices plugged into this your Router in rare cases when it cord. -
Page 20: Technical Details
To save you the cost of adding IP addresses per Belkin Router Monitor computer in your house, your Belkin Router uses Network The Belkin Router Monitor application helps you to monitor Address Translation (NAT) technology, allowing you to your Router’s status and change network settings. -
Page 21: System Requirements
Technical DeTails system Requirements setup software A computer running Windows XP SP3 and higher, ® Windows Vista 32 and 64 bit, or ® Modem Router Windows 7 32 and 64 bit; or Mac OS X, 10.5 and 10.6 Broadband ADSL Internet connection with ®... -
Page 22: Using Your Router
USING YOUR ROUTER Enabling Auto Update on Your Belkin Router The Router has the capability to automatically check for a newer version of firmware and alert you when it’s available. You can choose to download the new version or ignore it. By default this feature is disabled. If you want to enable it, select “Enable”... - Page 23 USING YOUR ROUTER Select “Enable” by clicking the radio button and then click “Apply Changes” at the bottom of the screen. 4. Click on “System Settings” in the left-hand column under the “Utilities” heading. 5. Toward the lower-half side of the screen you will find “Auto Update Firmware Enabling”.
-
Page 24: (Mac)
Setup steps: 1. Click on the blue Belkin Router Manager icon (right-click for Windows) in your system tray (Windows) or menu bar (Mac). 2. Select “Check for Updates” or “Update Available” from the menu. -
Page 25: Updating The Router's Firmware Via The Web Interface
Internet as this interface is built into the Router itself. Setup steps: 1. Locate and download the firmware file from the Belkin support site. (Type your part number into the search box in the top right corner and look for “Firmware” in the title.) 2. - Page 26 USING YOUR ROUTER 4. Open a web browser on the computer. 5. In the address bar of the web browser, type “http://192.168.2.1” and press “Enter” on your keyboard. 6. Click “Login” in the upper right-hand corner of the page. The Router does not ship with a password, so just click “Submit”.
- Page 27 USING YOUR ROUTER 9. Select the firmware file by left-clicking on it and then click the “Open” button in the lower-right corner of the window. This will take you back into the Router’s interface. 8. Click the “Browse” button toward the middle of the screen to search for the file you saved previously.
- Page 28 USING YOUR ROUTER A prompt asking, “Are you sure you want to continue with upgrading?” will appear. Click “OK”. A second prompt will open telling you the Router will not respond during the upgrade and warning you not to remove the power supply from the Router.
-
Page 29: Resetting The Router
USING YOUR ROUTER Resetting the Router Restoring Your Router to Factory Defaults Press and hold the “Reset” button for at least 10 seconds, and then release it. The lights on the Router will momentarily Reset Button – Red flash. The “Router” light will begin to blink. When the “Router” The “Reset”... -
Page 30: Restoring The Router To Default Settings Using The Web Interface
USING YOUR ROUTER Restoring the Router to Default Settings Using the Web Interface Symptoms You need to restore the factory defaults using the web interface. 3. Click “Login” in the upper right-hand corner of the page. The This may be because the Router is not performing as expected Router does not ship with a password, so just click “Submit”. - Page 31 USING YOUR ROUTER 4. Click on “Restore Factory Defaults” in the left- 5. Click on the “Restore Defaults” button. hand column under the “Utilities” heading.
- Page 32 USING YOUR ROUTER 7. The Router will begin the restoring process. Once the restore is complete, the Router will reboot. Note: This may take several minutes. Your Router has successfully been restored to its factory settings. 6. A warning box will open that says, “Warning: All your settings will be lost.
-
Page 33: Troubleshooting, Support, And Warranty
TroubleshooTing, supporT, and WarranTy Troubleshooting belkin setup cannot find my router. If Belkin Setup is not able to communicate with your Router during the installation process, please check the following items. The setup Cd does not automatically start. 1. Make sure that the wireless hardware on your computer is turned on, if available. - Page 34 Web. The light on the front of my router is blinking amber. If Belkin Setup is not able to connect the Router to the Internet, please check the following items: 1. Make sure the Router is connected to your modem with an Ethernet cable via the Router’s one WAN (modem) port.
- Page 35 TroubleshooTing, supporT, and WarranTy belkin setup completed installation, but i cannot browse the i can’t connect to the internet wirelessly. Web. The light on the front of my router is solid amber. If the light on the front of the Router is solid blue, then your 1.
- Page 36 TroubleshooTing, supporT, and WarranTy i can’t connect to the internet wirelessly and my My wireless network per formance is slow, inconsistent, network name is not listed in available networks. suffers from weak signal, or i’m having difficulty maintaining a Vpn connection. 1.
- Page 37 TroubleshooTing, supporT, and WarranTy limiting the wireless transmit rate—Limiting the wireless transmit i’ve installed this new router and some of my network clients rate can help improve range and connection stability. Most wireless (computers, game consoles, etc.) are now unable to connect. cards have the ability to limit the transmission rate.
- Page 38 TroubleshooTing, supporT, and WarranTy does the router support Wireless 5. Click “Apply Changes” to finish. Your wireless protected access (Wpa) security? connection is now encrypted. Each computer using your wireless network will need to use the new key. The Router ships with WPA/WPA2 security turned on. Windows XP and some older network hardware may note: If you are configuring the Router over a wireless require a software update to support WPA/WPA2.
- Page 39 TroubleshooTing, supporT, and WarranTy i am having difficulty setting up Wired equivalent 5. Click “Apply Changes” to finish. Your wireless privacy (Wep) security on my router. activity is now encrypted. Each computer using your wireless network will need to use the new key. 1.
- Page 40 3. The Router supports FAT16, FAT32-, or NTFS-formatted disks. Disks in other formats will not appear in the 3. The printer may not be set to auto-connect. Via the Belkin Router Finder (Mac OS X) or Windows Internet Explorer. Manager, open the USB Print and Storage Center. Check that the printer appears in the list of available devices.
- Page 41 If not, try unplugging and re-plugging the device. Please check that the USB connector is firmly plugged into the Router. 2. Via the Belkin Router Manager, open the USB Print and Storage Center. Check that the device appears in the list of available devices.
-
Page 42: Technical Support
TroubleshooTing, supporT, and WarranTy Technical support http://www.belkin.com/support http://www.belkin.com/uk/support australia http://www.belkin.com/au/support new Zealand http://www.belkin.com/au/support europe http://www.belkin.com/uk/support... -
Page 43: Regulatory Information
© 2012 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Mac and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries. Windows, Windows Vista, and Internet Explorer are either registered...
