Zanussi ZDE 36150W Instruction Booklet

Tumble dryer zde 36150w
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instruction booklet
Tumble Dryer
ZDE 36150W

Advertisement

Table of Contents
loading

Related Manuals for Zanussi ZDE 36150W

Summary of Contents for Zanussi ZDE 36150W

  • Page 1 Instruction booklet Tumble Dryer ZDE 36150W...

  • Page 2: Table Of Contents

    Thank you for selecting our appliance We wish you lots of enjoyment with your new appliance and we hope that you will consider our brand again when purchasing household appliances. Please read this user manual carefully and keep it throughout the product life cycle as a refer- ence document.

  • Page 3: Safety Information

    Safety Information In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly familiar with its operation and safety features.
  • Page 4 WARNING: use. It must not be used for purposes other than those for which it was designed. Never stop a tumble dry before • Only wash fabrics which are designed the end of the drying cycle unless all items are quickly removed and spread to be machine dried.

  • Page 5: Description Of The Appliance

    Description of the appliance 1. Control panel 2. Fluff filters 3. Rating Plate 4. Adjustable feet 5. Side vent outlets 6. Ring nut 7. Rear vent outlet...

  • Page 6: The Control Panel

    The control panel Half power Start Mains-ON light Time Programme button button selector dial chart Programme chart This will help you to select the correct programme for drying. Comes on when the appliance is switched on and goes out Mains-ON light when appliance is switched off.

  • Page 7: Drying Programs

    Drying programs Cotton Selector dial: up to 150 minutes Degree of Quantity Degree of drying required spin given Drying times mins 105 - 135 800/1000 60 - 85 Cupboard 95 - 120 1200/1400 50 - 7 0 90 - 115 800/1000 45 - 70 Iron dry...

  • Page 8: Before The First Use

    Before the first use • Ensure that the electrical connections comply with the installation instructions. • Remove the polystryrene block and any material from the drum. • Before using your tumble dryer for the first time, we recommend that you place a few damp cloths inside the appliance and dry for 30 minutes.
  • Page 9 Make sure that no metal objects are left in Laundry weights the laundry (e.g. hair clips, safety pins, The following weights are indicative: pins). bathrobe 1200 g Button up pillowcases, close zip fasteners, napkin 100 g hooks and poppers. Tie any belts or long tapes.

  • Page 10: Daily Use

    Daily Use be shortened, stopped suitable for use with Load the laundry Drying Time or avoided, as this loads of up to 3kg! Selector Dial could cause skin burns or damages to Start the laundry. Additional drying If at the end of the programme, the laun- Connect the appli- dry is still too dump,...

  • Page 11: Care And Cleaning

    Care and cleaning Important: You must DISCONNECT the appliance from the electricity supply, before you can carry out any cleaning or maintenance work. External cleaning Use only soap and water and then dry thoroughly. Important: do not use methylated spirit, diluents or similar products.
  • Page 12 Important: Do not use the appliance without filters. Cleaning the drum When your laundry does not reach the desired degree of dryness, in other words, when it turns out either too dry or too damp, we advise you to clean the inside of the drum with a cloth soaked with vinegar.

  • Page 13: Something Not Working

    Something not working? If a problem occurs, you can try to solve it yourself following the instructions below. If you call out an engineer when one of the following problems occurs, or to repair a fault due to incorrect use, the callout will be charged even if requested within the guarantee period.
  • Page 14 If you are unable to identify or solve the Important: problem, contact our service centre. Before telephoning, make a note of the model, serial If you call out an engineer to a fault listed below, number and purchase date of your machine: the or to repair a fault caused by incorrect use or Service Centre will require this information.

  • Page 15: Technical Data

    Technical data Technical data Width 60 cm Dimensions Height 85 cm Depth 58 cm Electrical connection Information on the electrical connection is given on the rating plate Voltage - Overall power - on the inner edge of the appliance door Fuse Depth with loading door 109 cm...

  • Page 16: Consumption Values

    Consumption values Consumption values (*) Programme Energy Revolutions Programme duration consumption per minute (in minutes) (in kWh) Cottons Cupboard 1000 Cottons Cupboard 1400 Synthetics Cupboard 1,18 1200 Max load: The consumption values have been established Cottons load: 6 kg under standard conditions. They may deviate Synthetics load: 3 kg when the machine is operated in domestic...

  • Page 17: Disposal

    Disposal Tips for environmental protection Packaging materials To save energy and to help protect the The materials marked with the symbol environment, we recommend that you follow recyclable. these hints: This means that they can be recycled by dispos- • Try to load the maximum capacity of the ing of them properly in appropriate collection con- machine as small loads are uneconomical.

  • Page 18: Installation

    Installation It is dangerous to alter the specifica- a fixed ventilation grille, fitted to an exterior wall or window. The tumble dryer must be installed in tions or attempt to modify this prod- a clean place, where dirt does not build up. Make uct in any way.
  • Page 19 natural phenomenon. To prevent this water from Electrical connection Iying in the hose or flowing back into the tumble Any electrical work required to install this dryer, it is advisable to drill a small hole (dia. 3 appliance should be carried out by a qualified mm) in the lowest point of the hose and to place electrician or competent person.
  • Page 20 Important: The plug must be accessible after the appliance has been installed. Important: The manufacturer declines any responsibility for damage or injury through failure to comply with the above safety precaution. Should the appliance power supply cable need to be replaced, this must be carried out by our Service Centre.

  • Page 21: European Guarantee

    Guarantee SINGAPORE European guarantee Electrolux SEA Pte. Ltd. This appliance is guaranteed by Electrolux, in No.2 Leng Kee Road each of the countries listed in the following page, # 06-08 Thye Hong Center for the period specified in the appliance Singapore 159086 guarantee or otherwise by law.
  • Page 22 +353 1 40 90 753 I I t t a a l l i i a a +39 (0) 434 558500 C.so Lino Zanussi, 26 - 33080 Porcia (PN) L L a a t t v v i i j j a a +37 17 84 59 34 Kr.
  • Page 23 ü ü P P o o r r t t u u g g a a l l +35 12 14 40 39 39 Quinta da Fonte - Edificio Gonçalves Zarco - Q 35 2774 - 518 Paço de Arcos R R o o m m a a n n i i a a +40 21 451 20 30 Str.
  • Page 24 www.electrolux.com 136904190 -00- 03102007...
