- Page 1 ® UPER 6016T-GTF UPER ERVER 6016T-GIBXF UPER ERVER 6016T-GIBQF UPER ERVER USER’S MANUAL Revision 1.0...
- Page 2 Please Note: For the most up-to-date version of this manual, please see our web site at www.supermicro.com. Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual at any time and without notice. This product, including software, if any, and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any medium or machine without prior written consent.
-
Page 3: About This Manual
Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 6016T-GTF/ GIBXF/GIBQF. Installation and maintenance should be performed by experienced technicians only. The SuperServer SuperServer 6016T-GTF/GIBXF/GIBQF is a 1U rackmount server based on the SC818GTQ-1400B server chassis and the Super X8DTT-F/X8DTT- IBXF/X8DTT-IBQF serverboards. - Page 4 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Chapter 4: System Safety You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the SuperServer 6016T-GTF/GIBXF/GIBQF. Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X8DTT-F/X8DTT-IBXF/X8DTT-IBQF serverboard, including the locations and functions of connectors, headers and jump- ers.
- Page 5 Preface Notes...
-
Page 6: Table Of Contents
Server Chassis Features ................1-5 System Power ....................1-5 SATA Subsystem ..................... 1-5 Front Control Panel ..................1-5 Cooling System ....................1-5 Contacting Supermicro ..................1-6 Chapter 2 Server Installation Overview ......................2-1 Unpacking the System ..................2-1 Preparing for Setup ..................2-1 Choosing a Setup Location ................ - Page 7 Table of Contents Installing the Server into a Telco Rack ............2-9 Checking the Serverboard Setup ..............2-10 Checking the Drive Bay Setup ...............2-11 Chapter 3 System Interface Overview ......................3-1 Control Panel Buttons ..................3-1 Reset ....................... 3-1 Power ......................3-1 Control Panel LEDs ..................
- Page 8 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Chapter 6 Advanced Chassis Setup Static-Sensitive Devices .................. 6-1 Precautions ..................... 6-1 Control Panel ....................6-2 System Cooling ....................6-2 System Fan Failure ..................6-3 Drive Bay Installation/Removal ............... 6-4 Accessing the Drive Bays ................6-4 Peripheral Drive Installation ................
-
Page 9: Chapter 1 Introduction
SC818GTQ-1400B chassis and one X8DTT-F/X8DTT-IBXF/X8DTT-IBQF server- boards. Please refer to our web site for information on operating systems that have been certifi ed for use with the server (www.supermicro.com). In addition to the serverboard and chassis, various hardware components may have been included with the system, as listed below. -
Page 10: Serverboard Features
Processors The X8DTT-F/X8DTT-IBXF/X8DTT-IBQF supports two Intel® 5500 Series proces- sors in LGA1366 sockets. Please refer to our web site for a complete listing of supported processors (www.supermicro.com). Memory The X8DTT-F/X8DTT-IBXF/X8DTT-IBQF has twelve DIMM sockets that can sup- port up to 48 GB of registered ECC DDR3-1333/1066/800 SDRAM (192 GB for the system). -
Page 11: Onboard Controllers/Ports
Chapter 1: Introduction Onboard Controllers/Ports Onboard I/O backpanel ports on each serverboard include one COM port, a VGA port, two USB ports, a dedicated IPMI LAN port and two Gigabit LAN (NIC) ports. An Infi niBand port is also included on the X8DTT-IBXF/X8DTT-IBQF serverboards (the 6016T-GIBXF and 6016T-GIBQF only). - Page 12 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual CPU#1 CPU#2 Port1 Port0 Ports 2,1 Kawela MT25408 QSFP Ports Connect-X IB PCI-E Gen2/DDR or QDR Intel Ports RJ45 RJ45 5520 Ports PCI-E x16 7,8,9,10 SST25 VF016 CLINK CLINK ICH10R PE 4-1 SATA SATA #1 SATA #2 SATA #3 SATA #4...
-
Page 13: Server Chassis Features
Chapter 1: Introduction Server Chassis Features System Power The SC818GTQ-1400B features a Gold Level 1400W high-effi ciency power supply. The AC power cord should be removed from the system before servicing or replac- ing the power supply. See Chapter 6 for details. SATA Subsystem The SC818GTQ-1400B chassis includes three 3.5"... -
Page 14: Contacting Supermicro
Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML... -
Page 15: Chapter 2 Server Installation
Chapter 2: Server Installation Chapter 2 Server Installation Overview This chapter provides a quick setup checklist to get your SuperServer up and running. Following these steps in the order given should enable you to have the system operational within a minimum amount of time. This quick setup assumes that your system has come to you with the processors and memory preinstalled. -
Page 16: Rack Precautions
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display Units. Warnings and Precautions! Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the fl... -
Page 17: Rack Mounting Considerations
Chapter 2: Server Installation • Always keep the rack's front door and all panels and components on the servers closed when not servicing to maintain proper cooling. Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. -
Page 18: Installing The System Into A Rack
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Installing the System into a Rack This section provides information on installing the SC818G chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean that the assembly procedure will differ slightly. -
Page 19: Installing The Inner Rail Extensions
Chapter 2: Server Installation Installing the Inner Rail Extensions The SC818G chassis includes a set of inner rack rails in two sections: inner rails (A) and inner rail extensions (B). The inner rails are preattached and do not interfere with normal use of the chassis if you decide not to install to a server rack. Attaching the inner rail extensions to to the inner rails stabilizes the chassis within the rack. -
Page 20: Assembling The Outer Rails
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Assembling the Outer Rails Each outer rail is in two sections that must be assembled before mounting on to the rack. Assembling the Outer Rails Identify the left and right outer rails by examining the ends, which bend outward. -
Page 21: Installing The Outer Rails Onto The Rack
Chapter 2: Server Installation Installing the Outer Rails onto the Rack Outer Rail Installation Adjust the outer rails to the proper length so that the outer rail fi ts snugly within the rack. Align the holes on the front of the outer rail, with the holes on the front of the rack (C) and secure with the screws provided. - Page 22 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Installing the Chassis into a Rack (Figure 2-5) Confi rm that chassis includes the inner rails and rail extensions . Also, confi rm that the outer rails are installed on the rack. Line chassis rails with the front of the rack rails. Slide the chassis rails into the rack rails, keeping the pressure even on both sides (you may have to depress the locking tabs when inserting).
-
Page 23: Installing The Server Into A Telco Rack
Chapter 2: Server Installation Installing the Server into a Telco Rack Optional brackets (p/n MCP-290-00016-0N) are needed to install the server to a telco (open type) rack. To install the server into a Telco type rack, use the two L-shaped brackets on either side of the chassis (four total). -
Page 24: Checking The Serverboard Setup
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Checking the Serverboard Setup After you install the server in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. Removing the Chassis Cover (Figure 2-7) Remove the three screws securing the top cover to the chassis. -
Page 25: Checking The Drive Bay Setup
Chapter 2: Server Installation Checking the Components You may have processors already installed to the serverboard. Each proces- sor needs its own heatsink. See Chapter 5 for instructions on processor and heatsink installation. Your server system may have come with system memory already installed. Make sure all DIMMs are fully seated in their slots. - Page 26 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Note that all power and data cables have been routed in such a way that they do not block the airfl ow generated by the fans. Providing Power The last thing you must do is to provide input power to the system. Plug the power cord from the power supply unit into a high-quality power strip that of- fers protection from electrical noise and power surges.
-
Page 27: Chapter 3 System Interface
Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the drive car- riers to keep you constantly informed of the overall status of the system as well as the activity and health of specifi... -
Page 28: Control Panel Leds
SUPERSERVER 6016T-GTF/GIBXF/GIQXF User's Manual Control Panel LEDs The control panel located on the front of the SC818GTQ chassis has fi ve LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take. -
Page 29: Nic1
Chapter 3: System Interface NIC1 Indicates network activity on LAN1 when fl ashing . This light indicates SATA and/or DVD-ROM drive activity when fl ashing. Power Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. SATA Drive Carrier LEDs •... - Page 30 SUPERSERVER 6016T-GTF/GIBXF/GIQXF User's Manual Notes...
-
Page 31: Chapter 4 System Safety
Chapter 4: System Safety Chapter 4 System Safety Electrical Safety Precautions Note: power should always be disconnected before perform- ing any service on the system. Basic electrical safety precautions shall be followed to protect yourself from harm and the server from damage: •... -
Page 32: General Safety Precautions
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual • This product may be connected to an IT power system. In all cases, make sure that the unit is also reliably connected to Earth (ground). • Serverboard Battery: CAUTION - There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 4-1). -
Page 33: Esd Precautions
Chapter 4: System Safety • Remove any jewelry or metal objects from your body, which are excellent metal conductors that can create short circuits and harm you if they come into contact with printed circuit boards or areas where power is present. •... -
Page 34: Operating Precautions
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Operating Precautions Care must be taken to assure that the chassis cover is in place when the system is operating to ensure proper cooling. Out of warranty damage to the system can occur if this practice is not strictly followed. Figure 4-1. -
Page 35: Chapter 5 Advanced Serverboard Setup
Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install the X8DTT-F/X8DTT-IBXF/X8DTT- IBQF serverboard into the SC818GTQ-1400B chassis, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. -
Page 36: I/O Ports
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Unpacking The serverboard is shipped in antistatic packaging to avoid electrostatic discharge. When unpacking the board, make sure the person handling it is static protected. I/O Ports The I/O ports are color coded in conformance with the PC 99 specifi cation. See Figure 5-1 below for the colors and locations of the various I/O ports. -
Page 37: Processor And Heatsink Installation
CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro web site for updates on CPU support. Installing LGA1366 Processors Starting with CPU1, press the... - Page 38 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual After removing the plastic cap, use your thumb and the index fi nger to hold the CPU at the north and south center edges. Align the CPU key (the semi-circle cutout) with the socket key (the notch below the gold color dot on the side of the socket).
-
Page 39: Installing A Cpu Heatsink
Chapter 5: Advanced Serverboard Setup Installing a CPU Heatsink Remove power from the system and unplug the AC power cord from the power supply. Do not apply any thermal grease Screw #1 Screw #2 to the heatsink or the CPU die; the required amount has already been applied. -
Page 40: Removing The Heatsink
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Removing the Heatsink Warning! We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instructions below to prevent damage to the CPU or the CPU socket. -
Page 41: Installing Memory
48 GB of registered ECC DDR3-1333/1066/800 SDRAM (for a total of 192 GB in the system). Note: Check the Supermicro web site for recommended DIMMs. Installing Memory Modules Insert each memory module vertically into a slot following the charts below. - Page 42 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual DIMM Population Table DIMM DIMMs DIMM Type (Reg.= Speeds (in MHz) Ranks per DIMM Slots per Populated Registered) (any combination; Channel per Channel SR=Single Rank, DR=Dual Rank, QR=Quad Rank) Reg. DDR3 ECC 800,1066,1333 SR, DR Reg.
-
Page 43: Adding Pci Cards
Chapter 5: Advanced Serverboard Setup Due to the memory allocation to system devices, the amount of memory that remains available for operational use will be reduced when 4 GB of RAM is used. The reduction in memory availability is disproportional. Refer to the table below. Possible System Memory Allocation &... -
Page 44: Serverboard Details
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Serverboard Details Figure 5-3. X8DTT Series Serverboard Layout COM1 USB0/1 InfiniBand LAN2 LAN1 JNMI1 Connector JWD1 IPMI_LAN IPMB JPG1 JSPK1 Winbond InfiniBand WPCM450 Controller Controller JPL1 USB2/3 JWOL1 JLPC80 JBT1 Intel ICH10R Intel BIOS IOH-36D Battery T-SGPIO0 X8DTT Series... -
Page 45: X8Dtt-F/X8Dtt-Ibxf/X8Dtt-Ibqf Quick Reference
Chapter 5: Advanced Serverboard Setup X8DTT-F/X8DTT-IBXF/X8DTT-IBQF Quick Reference Jumper Description Default Setting JBT1 CMOS Clear (See Section 5-8) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1 LAN1/2 Enable/Disable Pins 1-2 (Enabled) JWD1 Watch Dog Enable/Disable/Reset Pins 1-2 (Reset) Connector Description COM1 COM1 Serial Port FAN 1-4 System/CPU Fan Headers... -
Page 46: Connector Defi Nitions
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Connector Defi nitions ATX Power 20-pin Connector Pin Defi nitions (ATX Power 1/2) Pin# Defi nition Pin # Defi nition ATX Power Connector PS On Ground The main ATX power supply connec- 5VSB Ground tors on the X8DTT-F/X8DTT-IBXF/ Ground Ground X8DTT-IBQF are proprietary 20-pin... - Page 47 Chapter 5: Advanced Serverboard Setup Overheat/Fan Fail/PWR Fail/UID OH/Fan Fail/ PWR Fail/Blue_UID LEDPin Defi nitions (JF1) Pin# Defi nition Pins 7 and 8 of JF1 are for the Over- Blue UID LED/5.5V.SB heat/Fan Fail/Power Fail and UID OH/Fan Fail/PWR Fail/Red UID LED connections.
- Page 48 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Power On LED The Power On LED connector is lo- Power LED Pin Defi nitions (JF1) cated on pins 15 and 16 of JF1. This Pin# Defi nition connection is used to provide LED 5V Stby indication of power being supplied to Control the system.
- Page 49 Chapter 5: Advanced Serverboard Setup Serial Ports Serial Port Pin Defi nitions (COM) One serial port is included on the Pin # Defi nition Pin # Defi nition serverboard. The COM port is located beside the VGA port. See the table on the right for pin defi...
-
Page 50: Jumper Settings
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Jumper Settings To modify the operation of the serverboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two Connector pins to change the function of the Pins connector. Pin 1 is identifi ed with a square solder pad on the printed circuit board. - Page 51 Chapter 5: Advanced Serverboard Setup LAN1/LAN2 Enable/Disable LAN1/2 Enable/Disable Jumper Settings (JPL1) Change the setting of jumper JPL1 to Jumper Setting Defi nition enable or disable the LAN1 and LAN2 Pins 1-2 Enabled ports. See the table on the right for Pins 2-3 Disabled jumper settings.
-
Page 52: Onboard Indicators
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Onboard Indicators LAN1/LAN2 LEDs LAN1/LAN2 LEDs The Ethernet ports (located beside (Connection Speed Indicator) the COM port) have two LEDs. On LED Color Defi nition each Gb LAN port, one LED indicates No connection or 10 Mb/s activity when blinking while the other Green 100 Mb/s... -
Page 53: 5-10 Installing Additional Drivers
Chapter 5: Advanced Serverboard Setup 5-10 Installing Additional Drivers After you've installed the Windows Operating System, a screen as shown below will appear. You are ready to install software programs and drivers that have not yet been installed. To install these software programs and drivers, click the icons to the right of these items. -
Page 54: Confi Guring Supero Doctor Iii
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual 5-11 Confi guring Supero Doctor III The Supero Doctor III program is a Web-base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called the SD III Client. The Supero Doctor III program included on the CDROM that came with your serverboard allows you to monitor the environment and operations of your system. - Page 55 Chapter 5: Advanced Serverboard Setup Note: SD III Software Revision 1.0 can be downloaded from our Web site at: ftp:// ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/Manuals/SDIII/UserGuide.pdf. For Linux, we will still recommend that you use Supero Doctor II.
- Page 56 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Notes 5-22...
-
Page 57: Chapter 6 Advanced Chassis Setup
Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform mainte- nance on the SC818G chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the next step. -
Page 58: Control Panel
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Figure 6-1. Chassis: Front and Rear Views Power Supply Control Panel Hot-Swap Drive Bays (3) USB Ports Dedicated IPMI LAN Port PCI Slot LAN Ports COM Port VGA Port Infi niBand Port* *The Infi niBand port is included on the 6016T-GIBXF/GIBQF only. Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the serverboard to provide you with system status indications. -
Page 59: System Fan Failure
Chapter 6: Advanced Chassis Setup System Fan Failure Fan speed is controlled by system temperature via a BIOS setting. If a fan fails, the remaining fans will ramp up to full speed. Replace any failed fan at your earli- est convenience with the same type and model (the system can continue to run with a failed fan). -
Page 60: Drive Bay Installation/Removal
Peripheral Drives: The SC818G chassis includes space for a variety of peripheral drive options, including a 2.5" hard disk drive, DVD-ROM or fl oppy drive. For a complete listing of peripheral drive options, visit the Supermicro web site at: http://www.supermicro.com/products/chassis/1U/818/SC818G-1400.cfm... - Page 61 Chapter 6: Advanced Chassis Setup Figure 6-3. Removing a Hard Drive Carrier Warning: Except for short periods of time (swapping hard drives), do not operate the server with the hard drive carriers removed.
- Page 62 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Installing a Hard Drive to the Hard Drive Carrier Remove the two screws securing the dummy drive to the carrier. Remove the dummy drive from the carrier. Install a new drive into the carrier with the printed circuit board side facing downward so that the mounting holes align with those in the carrier.
-
Page 63: Peripheral Drive Installation
Chapter 6: Advanced Chassis Setup Note: When installing the hard drive carrier that is next to the power supply, the power supply handle must be lifted before extending the hard drive carrier handle, or before inserting the hard drive carrier into the drive bay. Figure 6-5. -
Page 64: Installing The Air Shroud
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Installing the Air Shroud Air shrouds concentrate airfl ow to maximize fan effi ciency. The air shroud for the SC818G chassis does not require screws to set up. Installing the Air Shroud Position the air shroud in the chassis as illustrated above. Align the notch (A) on the air shroud with the pin (B) on the add-on card bracket. -
Page 65: Power Supply
Power Supply Failure If the power supply module fails, the system will shut down and you will need to replace the module. Replacements can be ordered directly from Supermicro (see contact information in the Preface). As there is only one power supply module in the system, power must be com- pletely removed from the server before removing and replacing the power supply for whatever reason. - Page 66 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Notes 6-10...
-
Page 67: Chapter 7 Bios
When an option is selected in the left frame, it is highlighted in white. Often a text message will accompany it. (Note: the AMI BIOS has default text messages built in. Supermicro retains the option to include, omit, or change any of these text messages.) The AMI BIOS Setup Utility uses a key-based navigation system called "hot keys". -
Page 68: Starting The Setup Utility
Warning! Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. If you have to update the BIOS, do not shut down or reset the system while the BIOS is updating. - Page 69 Chapter 7: BIOS Supermicro X8DTT/-F/-IBX/-IBXF/-IBQ/-IBQF • BIOS Build Version : This item displays the BIOS revision used in your sys- tem. • BIOS Build Date : This item displays the date when this BIOS was completed. • AMI BIOS Core Version : This item displays the revision number of the AMI BIOS Core upon which your BIOS was built.
-
Page 70: Advanced Setup Confi Gurations
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Advanced Setup Confi gurations Use the arrow keys to select Boot Setup and hit <Enter> to access the submenu items: BOOT Features Quick Boot If Enabled, this option will skip certain tests during POST to reduce the time needed for system boot. -
Page 71: Processor And Clock Options
Chapter 7: BIOS Hit 'Del' Message Display This feature displays "Press DEL to run Setup" during POST. The options are Enabled and Disabled. Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture"... - Page 72 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual C1E Support Select Enabled to use the feature of Enhanced Halt State. C1E signifi cantly reduces the CPU's power consumption by reducing the CPU's clock cycle and voltage during a "Halt State." The options are Disabled and Enabled. Hardware Prefetcher (Available when supported by the CPU) If set to Enabled, the hardware pre fetcher will pre fetch streams of data and instruc- tions from the main memory to the L2 cache in the forward or backward manner to...
-
Page 73: Advanced Chipset Control
Chapter 7: BIOS tion and heat dissipation. Please refer to Intel’s web site for detailed information. The options are Disable (Disable GV3) and Enable (Enable GV3). Intel® TurboMode Technology Select Enabled to use the Turbo Mode to boost system performance. The options are Enabled and Disabled. - Page 74 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual QPI L0s and L1 This enables the QPI power state to low power. L0s and L1 are automatically selected by the motherboard. The options are Disabled and Enabled. Memory Frequency This feature forces a DDR3 frequency slower than what the system has de- tected.
- Page 75 Chapter 7: BIOS Guardband Temperature (For the Closed Loop only) This is the temperature which applies to the DIMM temperature threshold. Each step is in 0.5 C increment. The default is [006]. Press "+" or "-" on your keyboard to change this value. Inlet Temperature This is the temperature detected at the chassis inlet.
- Page 76 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Intel VT-d Select Enabled to enable Intel's Virtualization Technology support for Direct I/O VT-d by reporting the I/O device assignments to VMM through the DMAR ACPI Tables. This feature offers fully-protected I/O resource-sharing across the Intel platforms, providing the user with greater reliability, security and availability in networking and data-sharing.
- Page 77 Chapter 7: BIOS Hand-Off support. When enabled, the EHCI Interface will be changed from the BIOS- controlled to the OS-controlled. The options are Disabled and Enabled. IDE/SATA Confi guration When this submenu is selected, the AMI BIOS automatically detects the presence of the IDE devices and displays the following items: SATA#1 Confi...
- Page 78 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual is not used. Block Mode allows transfers of up to 64 KB per interrupt. Select Disabled to allow data to be transferred from and to the device one sector at a time. Select Auto to allow data transfer from and to the device occur multiple sectors at a time if the device supports it.
- Page 79 Chapter 7: BIOS Select UDMA0 to allow the BIOS to use Ultra DMA mode 0. It has a data transfer rate of 16.6 MBs. It has the same transfer rate as PIO mode 4 and Multi Word DMA mode 2. Select UDMA1 to allow the BIOS to use Ultra DMA mode 1.
- Page 80 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual PCI IDE BusMaster When enabled, the BIOS uses PCI bus mastering for reading/writing to IDE drives. The options are Disabled and Enabled. Load Onboard LAN1 Option ROM/Load Onboard LAN2 Option ROM Select Enabled to enable the onboard LAN1 or LAN2 Option ROM. This is to boot computer using a network interface.
-
Page 81: Hardware Health Monitor
Chapter 7: BIOS Redirection After BIOS POST Select Disabled to turn off Console Redirection after Power-On Self-Test (POST). Select Always to keep Console Redirection active all the time after POST. (Note: This setting may not be supported by some operating systems.) Select Boot Loader to keep Console Redirection active during POST and Boot Loader. - Page 82 ‘Temperature Tolerance’ is, and not the other way around. This results in better CPU thermal management. Supermicro has leveraged this feature by assigning a temperature status to certain thermal conditions in the processor (Low, Medium and High). This makes it easier for the user to understand the CPU’s temperature status, rather than by just simply...
- Page 83 Chapter 7: BIOS Notes: The system may shut down if it continues for a long period to prevent damage to the CPU. The information provided above is for your reference only. For more information on thermal management, please refer to Intel’s Web site at www.Intel.com.
-
Page 84: View Bmc System Event Log
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Select to Enabled to allow USB devices to wakeup from S3/S4 state. The options are Enabled and Disabled. High Performance Event Timer Select Enabled to activate the High Performance Event Timer (HPET) that produces periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in synchronizing multimedia streams, providing smooth playback and reducing the de- pendency on other timestamp calculation devices, such as an x86 RDTSC Instruc- tion embedded in the CPU. - Page 85 Chapter 7: BIOS • SEL Entry Number • SEL Record ID • SEL Record Type • Timestamp, Generator ID • Event Message Format User • Event Sensor Type • Event Sensor Number, • Event Dir Type • Event Data. Clear BMC System Event Log This feature is used to clear the BMC System Event Log.
- Page 86 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Channel Number - Enter the channel number for the SET LAN Confi g com- mand. This is initially set to [1]. Press "+" or "-" on your keyboard to change the Channel Number. Channel Number Status - This feature returns the channel status for the Channel Number selected above: "Channel Number is OK"...
- Page 87 Chapter 7: BIOS IP Address The BIOS will automatically enter the IP address of this machine; however it may be over-ridden. IP addresses are 6 two-digit hexadecimal numbers (Base 16, 0 ~ 9, A, B, C, D, E, F) separated by dots. (i.e., 00.30.48.D0.D4.60). Current IP Address in BMC This item displays the current IP address used for your IPMI connection.
- Page 88 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Subnet Mask Confi guration Subnet masks tell the network which subnet this machine belongs to. The value of each three-digit number separated by dots should not exceed 255. Parameter Selector Use this feature to select the parameter of your Subnet Masks confi guration. Subnet Masks This item displays the current subnet masks setting for your IPMI connection.
-
Page 89: Dmi Event Log
Chapter 7: BIOS Specifi cation for more information at www.intel.com. The options are No Delay, 30 sec, 60 sec, 1.5 min, 2.0 min. Startup Delay - This feature enables or disables startup delay. The options are Enabled and Disabled. PEF Startup Delay - This sets the pre-determined time to delay PEF after system power-ups and resets. -
Page 90: Security Settings
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Security Settings The AMI BIOS provides a Supervisor and a User password. If you use both pass- words, the Supervisor password must be set fi rst. Supervisor Password This item indicates if a supervisor password has been entered for the system. Clear means such a password has not been used and Set means a supervisor password has been entered for the system. -
Page 91: Boot Confi Guration
Chapter 7: BIOS Clear User Password (Available only if User Password has been set) This item allows you to clear a user password after it has been entered. Password Check This item allows you to check a password after it has been entered. The options are Setup and Always. -
Page 92: Exit Options
UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Hard Disk Drives This feature allows the user to specify the boot sequence from all available hard disk drives. The settings are Disabled and a list of all hard disk drives that have been detected (i.e., 1st Drive, 2nd Drive, 3rd Drive, etc). •... - Page 93 Chapter 7: BIOS Save Changes and Exit When you have completed the system confi guration changes, select this option to leave the BIOS Setup Utility and reboot the computer, so the new system con- fi guration parameters can take effect. Select Save Changes and Exit from the Exit menu and press <Enter>.
- Page 94 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Notes 7-28...
-
Page 95: Appendix A Bios Error Beep Codes
Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process. - Page 96 UPER ERVER 6016T-GTF/GIBXF/GIQXF User's Manual Notes...
-
Page 97: Appendix B Installing Windows
South Bridge RAID Settings before you install the Windows OS and other software drivers. To confi gure RAID settings, please refer to RAID Confi guration User Guides posted on our web site at www.supermicro.com/support/manuals. Note: The following OS installation instructions are written for the Windows XP/2003 OS only. - Page 98 fi les and then continue with the Windows installation. After the installation has completed, the system will automatically reboot. Insert the Supermicro Setup CD that came with your system into the CD- ROM drive during system boot and the main screen will display.
-
Page 99: Appendix C System Specifi Cations
Appendix C: System Specifi cations Appendix C System Specifi cations Processors Two Intel® 5500 Series processors in LGA1366 sockets Note: please refer to our website for details on supported processors. Chipset Intel 5520/ICH10R BIOS 32 Mb AMI SPI Flash ROM Memory Capacity Twelve DIMM sockets that can support up to 48 GB of registered ECC DDR3- 1333/1066/800 SDRAM... - Page 100 UPER ERVER 6016T-GTF/GIBXF/GIBQF User's Manual Weight Gross (Bare Bone): 47 lbs. (21.4 kg.) System Cooling Four sets of 4-cm counter-rotating cooling fans (fan speed controlled by BIOS setting) System Input Requirements AC Input Voltage: 180-240 VAC Rated Input Current: 7.2A (180V) to 9.5 (240V) Rated Input Frequency: 50-60 Hz Power Supply Rated Output Power: 1400W w/PFC (Part# PWS-1K41F-1R)
- Page 101 Appendix C: System Specifi cations Notes...
- Page 102 ERVER 6016T-GTF/GIBXF/GIBQF User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...
