TM
DIGITAL BLOOD PRESSURE MONITOR
Hose plug
Air hose
Wrist
cuff
INSTRUCTION MANUAL
FOR
REF CH-611C

IDENTIFICATION OF PARTS

Systolic blood pressure
display section
Hose
socket
- Eng 1 -
Diastolic blood pressure/
Pulse display section
Power switch
Start switch
Memory recall switch
Pressure setting switch
Memory reset switch
Battery cover

Advertisement

Table of Contents
loading

Summary of Contents for Citizen REF CH-611C

  • Page 1: Identification Of Parts

    INSTRUCTION MANUAL DIGITAL BLOOD PRESSURE MONITOR REF CH-611C IDENTIFICATION OF PARTS Systolic blood pressure Memory reset switch display section Hose Hose plug Air hose socket Diastolic blood pressure/ Battery cover Pulse display section Power switch Start switch Memory recall switch...
  • Page 2: Specifications

    SPECIFICATIONS Measuring method: Oscillometric system Indication: Digital display, Height: 19mm Measuring range: Pressure; 0 280mmHg, Pulse; 40 200 beat/min. Accuracy: Pressure; 3mmHg, Pulse; 5% Inflation: Automatic inflation by internal pump Pressurization setting: 4 stage: 160, 200, 240, 280mmHg Deflation: Automatic constant speed deflation system Exhaust: Quick exhaust by electromagnetic valve Memory function:...
  • Page 3: General Remarks

    CLEANING METHOD OF CUFF After cleaning the cuff with a neutral detergent, lightly rinse it with wa- machine will cause air leakage. Also, be careful not to get water into ter and let it dry in the air. Hard rubbing or washing in a washing the air hose.
  • Page 4: Precaution For Use And Maintenance

    • Do NOT measure blood pressure immediately after drinking coffee or • Do NOT keep on measuring so many times, as your arm will have tea or smoking. built up congestion of blood, and you will not get a valid reading. •...
  • Page 5 Protect the nature environment: Manufacturer: Please help protect natural environment by respecting national and/or Name: Premier Precision Ltd. local recycling regulations when disposing of the batteries and the prod- Address: Block E, G-H, 6 floor, ucts at the end of their useful lives. Phase 2, Yip Fat Factory Building, 73-75 Hoi Yuen Road, Kwun Tong, Kowloon, Hong Kong...
  • Page 6 2. Attaching of wrist cuff All display marks appear for approx. 1 sec- ond and buzzer beeps. After all display marks are disappeared, de- flation mark “ ” appears for approx. 1 sec- ond (three short beeps notify you of ready •...
  • Page 7 • Place the wrist cuff at the 1cm from the wrist edge. At this time, the air hose should be laid across the palm of the hand extending to- • Place your elbow on table so that the cuff is at the level as your ward the middle finger.
  • Page 8: Turn Power Off

    4. To start the measurement When the diastolic pressure value is de- tected, the measurement is completed and buzzer sounds. Press the “Start Switch”. Systolic pressure is displayed on the up- per and diastolic pressure on the lower side The wrist cuff pressurizes when the “Start of the display.
  • Page 9 7. Change of the pressure-setting value • By a second depressing of “Memory Recall Switch”, the value for latest (last measured value) blood pressure is displayed. “ ” mark flushes to notify When the pressure setting is needed to be that the value is the last measured changed, press the “Pressure Setting (newest one) value.
  • Page 10: Automatic Power Off Function

    — New blood pressure value is stored in memory at pressing “Power Switch” for turn OFF or at pressing “Start Switch” for new measure- ment. 9. Automatic power off function If this unit is left on after measurement, an Automatic Power-OFF Func- tion turns the power OFF after approximately 3 minutes.
  • Page 11: Description Of Display Marks

    DESCRIPTION OF DISPLAY MARKS DISPLAY MARK CONDITION/CAUSE CORRECTIVE ACTION Measurement is begun, but the pressure was in- Change the pressurization setting one level by pressing “Pres- sufficient. sure Setting Switch” and measure once again. (Automatic remeasuring will be done only 1 time.) Appears when the blood pressure could not be measured accurately.
  • Page 12 CITIZEN is a registered trademark of Citizen Watch Co., Japan. Consumer Electronics Division CBM Bldg. 5F, 5-68-10, Nakano, Nakano-ku, Tokyo 164-0001, Japan Phone: (03)5345-7430 Fax: (03)5345-7431 E-mail: info-con@jcbm.co.jp...
