Installation & Operating Manual
The Harman Exception Wood Stove
(Model TL200)
R7
SAFETY NOTICE
PLEASE READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR NEW ROOM HEATER. FAILURE TO
FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH.
FOR USE IN THE U.S. AND CANADA SUITABLE FOR INSTALLATION IN MOBILE HOMES
IF THIS HARMAN EXCEPTION MODEL TL200 STOVE IS NOT PROPERLY INSTALLED, A HOUSEFIRE MAY RESULT.
FOR YOUR SAFETY, FOLLOW INSTALLATION DIRECTIONS.
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONSAND INSTALLATION INSPECTION
REQUIREMENTS IN YOUR AREA.
CONTACT YOUR LOCAL AUTHORITY (SUCH AS MUNICIPAL BUILDING DEPARTMENT, FIRE DEPARTMENT, FIRE
PREVENTION BUREAU, ETC.) TO DETERMINE THE NEED FOR A PERMIT.
CETTE GUIDE D'UTILISATION EST DISPONIBLE EN FRANCAIS. CHEZ VOTRE CONCESSIONNAIRE DE HARMAN STOVE
COMPANY.
SAVE THESE INSTRUCTIONS.
Advertisement
Table of Contents
Related Manuals for Harman Stove Company TL200
Summary of Contents for Harman Stove Company TL200
-
Page 1: Safety Notice
FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH. FOR USE IN THE U.S. AND CANADA SUITABLE FOR INSTALLATION IN MOBILE HOMES IF THIS HARMAN EXCEPTION MODEL TL200 STOVE IS NOT PROPERLY INSTALLED, A HOUSEFIRE MAY RESULT. FOR YOUR SAFETY, FOLLOW INSTALLATION DIRECTIONS. -
Page 2: Table Of Contents
The Harman Exception was designed to make burning wood easier by adding a top load door which allows more wood to fit into the large firebox. The Exception's smoke free design draws smoke down through the stove, not into your room. -
Page 3: Specifications
Specifications 3.5" 3.75" Weight Flue Size Log Length Recommended Heating Capacity Average Emissions Emissions on Low Blower Size (optional) Outside Air size 440 lbs 6 inch 18" with 20" Max 1500 to 2800 sq. ft. 4.4 Grams Per Hr. 2.25 Grams Per Hr. 105 cfm variable speed 3 inch... - Page 4 Combination Top Load Door and Damper Arm Side Shield Front Load Door Latch Specifications Top Load Door Ash Door Latch Top Load Opening Front Load Door Grates Andirons Ash Door...
-
Page 5: Operation
Close the door by pushing in and push- ing the handle all the way down. To open the top load door move the wooden knob located on the left side of the stove front and upward until it locks the top open. - Page 6 Combustion in your Harman Exception is controlled very precisely. During a wood fire, primary combustion air enters the bottom of the stove, is directed up to the top of the load door and then down past the glass, finally enter- ing the combustion chamber.
-
Page 7: Building A Fire
Air Control The air control lever is located directly below the ash lip of the stove. Using this lever you will be able to vary the amount of air delivered to the fire, creating a range of heat outputs. The low heat output setting is to the left, and high is to the far right. - Page 8 Operation Operating as a Fireplace The TL200 is tested and approved to be burned with the front load door open and the damper open. In this mode of operation you get a true fire sound as well as appear- ance.
-
Page 9: Maintenance
The inside of the fire chamber should be exam- ined for damage to the refractory lining material, grates, casting or Afterburner glass. If any bricks have been dam- aged, replace them with Harman Stove Company replace- ment parts. Glass - Replacement If the stove’s glass is cracked or broken, you must... - Page 10 After a period of time, you may find that the front door does not close as firmly as when your stove was new. This is due to a natural com- pression of the gaskets. To tighten the seal, open the door and rotate the handle one full turn counterclockwise or bend the latch plate on the stove.
-
Page 11: Installation
Assembly Blower (optional) Bolt the mounting plate to the bottom rear of the stove with four 1/4-20 bolts. Put the blower in place on the bracket and bolt fast. Tighten the bolts, but do not over- tighten. The power cord for the blower must be connected to a grounded outlet, and may not be routed above, under, over or around the stove itself. - Page 12 Parallel versus Corner Installations A parallel installation is one in which the back and sides of the stove are parallel to the walls behind and to the side of the stove. A corner installation is one in which the back of the stove is positioned diagonally across a corner of the room.
-
Page 13: Door Installation Tips
Door Assembly/Installation Tips Door Glass • Be sure that the door glass is installed in the door with the label, located on the glass, on the external side of the door. • Rope the glass carefully to insure proper sealing. •... -
Page 14: Linkage Installation
• With left hand, slide new drive arm through hole in side of stove. With right hand, take 1/4 x 20 grade 8 bolt along with washer and insert through hole from inside of stove. Tighten snugly using a 7/16" wrench.(Shown in Fig. 2) Figure 3 1/4 x 20 x 1/2"... - Page 15 Exception Linkage Installation, cont'd Before side shield is in place. slots for side shield tabs Side Shield After side shield is in place. Figure 4 Self-Locking Nut Figure 5 Step 3: Install the top lift arm • Tighten the 1/4-20 x 5/8 button head allen bolt. Bolt into the tab on the underside of the top lid.
- Page 16 Exception Linkage Installation, cont'd 1/4 x 20" Self Locking Nut Top Lift Arm Drive Arm Assembly Outside Damper Arm Pivot Arm Lift Lug 1/4 x 20" Button head Allenbolt Shoulder Pin Figure 7...
- Page 17 Signs of an overdraft include rapid fuel consumption, inabil- ity to slow the fire, and parts of the stove or chimney connector glowing red. It is important that you fol- low the chimney guidelines in this manual, including size, type, and height to avoid draft problems.
- Page 18 The Chimney The Exception must be installed into a chimney approved for use with solid-fuel appliances. In the U.S., the Exception must be connected to (1) a prefabricated chimney complying with the requirements for Type HT chim- neys in the Standard for Chimneys, Factory-Built, Resi- dential Type and Building Heating Appliances, UL 103, or (2) a code-approved masonry chimney with a flue liner.
- Page 19 Existing Masonry Chimneys If you plan on using a pre-existing masonry chim- ney, have it thoroughly inspected and cleaned. Any faults which make the chimney unsafe and unusable must be repaired prior to use. These can include improper height, structural defects, blockages, inadequate clearance to com- bustibles, unsealed openings into other rooms of the house, signs of creosote or smoke leakage, a loose or absent clean-out door, or absence of a liner.
-
Page 20: Chimney System
If you smell smoke, turn up the air control lever setting, and thoroughly ventilate your dwelling. During future burns, be careful not to overload the stove with fuel, so you will not be tempted to constantly operate at a low air control setting. -
Page 21: Parts List
Exception Parts List 1-10-08074 Damper linkage weldment 1-10-08075 Damper pivot arm weldment 1-10-08127 Top lift arm weldment 2-00-05204 Left side shield 3-40-05228 Wooden knob 3-40-05171 Ceramic fiber afterburner 1-10-08058 Left side plate assy. 2-00-07071-1 Left glass retainer clip 2-00-07071-2 Right glass retainer clip 3-40-05180 Afterburner glass 4-31-08078... -
Page 22: Parts Diagram
Exception TL200 Wood Stove Exception (TL200) Parts... -
Page 23: Warranty
RANTY OF MERCHANTABILITY, OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE. No employee, agent, dealer, or other person is authorized to give any warranty on behalf of Harman Stove Company. This warranty does not apply if the product has been altered in any way after leaving the factory. Harman Stove Com- pany and its agents assume no liability for “resultant damages of any kind”...
