Panasonic CQ-C1115N Operating Instructions

CD Player/Receiver
CQ-C1115N
Model:
BAND CQ-C1115N Operating Instructions
APM
SEL
PWR CLOCK
SRC MUTE 7 8 9 10 11 12 SQ/SCAN
1 2 3 4 5 6 DISP
¡Please read these instructions carefully before using this product and keep this manual for future reference.
Direct Sales at Panasonic UK
¡ Order accessories and consumable items for your product
Sales and Support Information with ease and confidence by phoning our Customer Care
Centre Monday - Thursday 9:00am - 5:30pm, Friday
For UK and Ireland customers only. 9:30am - 5:30pm. (Excluding public holidays).
¡ Or go on line through our Internet Accessory ordering
application at www.panasonic.co.uk.
¡ Most major credit and debit cards accepted.
Customer Care Centre
¡ All enquiries, transactions and distribution facilities are
¡ For customers within the UK: 08705 357357
provided directly by Panasonic UK Ltd.
¡ For customers within the Republic of Ireland: 01 289 8333
¡ It couldn't be simpler!
¡ Visit our website for product information
¡ Also available through our Internet is direct shopping for a
¡ E-mail: customer.care@panasonic.co.uk
wide range of finished products, so take a browse on our
website for further details.
Matsushita Electric Industrial Co., Ltd.
Web Site: http://panasonic.net
YFM284C651CA PTW1206-1106 Printed in China
Safety Information
■ ■
Read the operating instructions for the unit and all other compo- This manual uses pictographs to show you how to use the product
nents of your car audio system carefully before using the system. safely and to alert you to potential dangers resulting from improper
They contain instructions about how to use the system in a safe and connections and operations. The meanings of the pictographs are
effective manner. Panasonic assumes no responsibility for any prob- explained below. It is important that you fully understand the mean-
lems resulting from failure to observe the instructions given in this ings of the pictographs in order to use this manual and the system
manual. properly.
This pictograph intends to alert you to the presence of This pictograph intends to alert you to the presence of
important operating instructions and installation important operating instructions and installation instruc-
instructions. Failure to heed the instructions may tions. Failure to heed the instructions may result in
Warning Caution
result in severe injury or death. injury or material damage.
Observe the following warnings when installing.
Warning
❑ Disconnect the lead from the negative (–) battery termi-
Observe the following warnings when using this
nal before installation.
Wiring and installation with the negative (–) battery terminal con-
unit.
nected may cause electrical shock and injury due to a short circuit.
❑ The driver should neither watch the display nor operate
Some cars equipped with the electrical safety system have specific
the system while driving.
procedures of battery terminal disconnection.
Watching the display or operating the system will distract the driv- FAILURE TO FOLLOW THE PROCEDURE MAY LEAD TO THE
er from looking ahead of the vehicle and can cause accidents.
UNINTENDED ACTIVATION OF THE ELECTRICAL SAFETY SYSTEM
Always stop the vehicle in a safe location and use the parking RESULTING IN DAMAGE TO THE VEHICLE AND PERSONAL
brake before watching the display or operating the system.
INJURY OR DEATH.
❑ Use the proper power supply.
❑ Never use safety-related components for installation,
This product is designed for operation with a negative grounded
grounding, and other such functions.
12 V DC battery system. Never operate this product with other bat-
Do not use safety-related vehicle components (fuel tank, brake,
tery systems, especially a 24 V DC battery system.
suspension, steering wheel, pedals, airbag, etc.) for wiring or fix-
❑ Protect the Deck Mechanism.
ing the product or its accessories.
❑ Installing the product on the air bag cover or in a location
Do not insert any foreign objects into the slot of this unit.
❑ Do not disassemble or modify the unit.
where it interferes with airbag operation is prohibited.
Do not disassemble, modify the unit or attempt to repair the prod- ❑ Check for piping, gasoline tank, electric wiring, and other
uct yourself. If the product needs to be repaired, consult your
items before installing the product.
dealer or an authorized Panasonic Service Centre.
If you need to open a hole in the vehicle chassis to attach or wire
❑ Do not use the unit when it is out of order.
the product, first check where the wire harness, gasoline tank, and
If the unit is out of order (no power, no sound) or in an abnormal
electric wiring are located. Then open the hole from outside if pos-
state (has foreign objects in it, is exposed to water, is smoking, or
sible.
smells), turn it off immediately and consult your dealer. ❑ Never install the product in a location where it interferes
❑ Refer fuse replacement to qualified service personnel.
with your field of vision.
When the fuse burns out, eliminate the cause and have it replaced ❑ Never have the power cord branched to supply other
with the fuse prescribed for this unit by a qualified service engi-
equipment with power.
neer. Incorrect replacement of the fuse may lead to smoke, fire,
❑ After installation and wiring, you should check the nor-
and damage to the product.
mal operation of other electrical equipment.
The continuation of their using in abnormal conditions may cause
fire, electrical shock or a traffic accident.
❑ In the case of installation to an airbag-equipped car, con-
firm warnings and cautions of the vehicle manufacturer
before installation.
❑ Make sure the leads do not interfere with driving or get-
ting in and out of the vehicle.
❑ Insulate all exposed wires to prevent short circuiting.
Accessories
Operating Instructions Installation kit (ZZBISC1021N-J) Notes:
(English :YFM284C651CA) Lock Cancel Plate ¡ The number in parentheses underneath
Q'ty: 1 each accessory part name is the part
Installation Instructions Q'ty: 2 number for maintenance and service.
(English :YFM294C083CA) ¡ Accessories and their part numbers are
Mounting Bolt
Q'ty: 1 subject to modification without prior
PAN EUROPEAN GUAR- Q'ty: 1 notice due to improvements.
¡
ANTEE Mounting Collar Mounting Collar and Trim Plate are
Q'ty: 1 (FX0214C384ZB) mounted on the main unit at shipment.
Q'ty: 1
Trim Plate
(YFC054C079YA)
Q'ty: 1
Power Connector
(YEAJ02874)
Q'ty: 1
Request for use of the Removable Face Plate Case
¡ To avoid trouble and ensure safety, use the optional
Removable Face Plate Case (YFC054C061ZB)
❑ Take care not to damage the leads.
Caution
When wiring, take care not to damage the leads. Prevent them
from getting caught in the vehicle chassis, screws, and moving
Observe the following cautions when using this
parts such as seat rails. Do not scratch, pull, bend or twist the
unit.
leads. Do not run them near heat sources or place heavy objects
❑ Keep the sound volume at an appropriate level. on them. If leads must be run over sharp metal edges, protect the
leads by winding them with vinyl tape or similar protection.
Keep the volume level low enough to be aware of road and traffic
❑ Use the designated parts and tools for installation.
conditions while driving.
❑ This unit is designed for use exclusively in automobiles. Use the supplied or designated parts and appropriate tools to
❑ Do not operate the unit for a prolonged period with the install the product. The use of parts other than those supplied or
designated may result in internal damage to the unit. Faulty instal-
engine turned off.
lation may lead to an accident, a malfunction or fire.
Operating the audio system for a long period of time with the
❑ Do not block the air vent or the cooling plate of the unit.
engine turned off will drain the battery.
❑ Do not expose the unit to direct sunlight or excessive Blocking these parts will cause the interior of the unit to overheat
and will result in fire or other damage.
heat.
❑ Do not install the product where it is exposed to strong
Otherwise these will raise the interior temperature of the unit, and
vibrations or is unstable.
it may lead to smoke, fire, or other damage to the unit.
❑ Do not use the product where it is exposed to water, Avoid slanted or strongly curved surfaces for installation. If the
installation is not stable, the unit may fall down while driving and
moisture, or dust.
this can lead to an accident or injury.
Exposure of the unit to water, moisture, or dust may lead to
❑ Installation Angle
smoke, fire, or other damage to the unit. Make especially sure that
The product should be installed in a horizontal position with the
the unit does not get wet in car washes or on rainy days.
front end up at a convenient angle, but not more than 30˚.
The user should bear in mind that in some areas there may be
Observe the following cautions when installing.
restrictions on how and where this unit must be installed. Consult
❑ Refer wiring and installation to qualified service personnel.
your dealer for further details.
❑ Wear gloves for safety. Make sure that wiring is complet-
Installation of this unit requires special skills and experience. For
maximum safety, have it installed by your dealer. Panasonic is not ed before installation.
liable for any problems resulting from your own installation of the ❑ To prevent damage to the unit, do not connect the power
unit.
connector until the whole wiring is completed.
❑ Follow the instructions to install and wire the product.
❑ Do not connect more than one speaker to one set of
Not following the instructions to properly install and wire the prod-
speaker leads. (except for connecting to a tweeter)
uct could cause an accident or fire.
Information on Disposal for Users of Waste Electrical & Electronic Equipment (private households)
This symbol on the products and/or accompanying documents means that used electrical and electronic products should not
be mixed with general household waste.
For proper treatment, recovery and recycling, please take these products to designated collection points, where they will be
accepted on a free of charge basis. Alternatively, in some countries you may be able to return your products to your local
retailer upon the purchase of an equivalent new product.
Disposing of this product correctly will help to save valuable resources and prevent any potential negative effects on human
health and the environment which could otherwise arise from inappropriate waste handling. Please contact your local authority for further
details of your nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
Information on Disposal in other Countries outside the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.
Notes on Discs
If you use commercial CDs, they must have the label
shown at right.
Some copy-protected music CDs are not playable.
How to hold a disc
Printed side
¡ Do not touch the underside of a disc.
¡ Do not scratch on a disc.
¡ Do not bend a disc.
¡ When not in use, keep the disc in a case.
Do not leave discs in the following places:
¡ In direct sunlight
¡ Near car heaters
¡ Dirty, dusty and damp areas
¡ On seats and dashboards
Disc cleaning
Labels created by a printer,
Use a dry, soft cloth to wipe from the center outward. Irregularly shaped discs
protective films or sheets
<Correct> <Wrong>
Do not write on the disc label with a ballpoint pen or
Disc with adhered Discs with cracks,
other hard-point pens.
stickers or tape scratches or parts missing
¡ You may have trouble playing back some CD-R/RW discs
recorded using CD recorders (CD-R/RW drives), either due
to their recording characteristics or dirt, fingerprints,
scratches, etc. on the disc surface.
¡ CD-R/RW discs are less resistant to high temperatures and
high humidity than ordinary music CDs. Leaving them
inside a car for extended periods may damage them and
make playback impossible.
¡ Some CD-R/RWs cannot be played back successfully due
to incompatibility among writing software, a CD recorder
(CD-R/RW drive) and the discs.
¡ This player cannot play the CD-R/RW discs if the session is
not closed.
¡ This player cannot play the CD-R/RW discs which contain
other than CD-DA data.
¡
Be sure to observe the instructions of the CD-R/RW disc
for handling it.
CLASS 1 LASER PRODUCT
Label Indications and Their Locations
CAUTION
LASER RADIATION WHEN OPEN. DO NOT STARE
INTO BEAM.
Caution
Caution Label
This product utilizes a laser.
Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
Do not take apart this unit or attempt to
make any changes yourself.
This unit is a very intricate device that uses a laser
pickup to retrieve information from the surface of
compact discs. The laser is carefully shielded so that
its rays remain inside the cabinet.
Deck Ass'y (in the unit,
Therefore, never try to disassemble the player or alter
upper side)
any of its parts since you may be exposed to laser
rays and dangerous voltages.
Before Reading These Instructions
Panasonic welcomes you to our constantly growing family of electronic products owners.
We endeavor to give you the advantages of precise electronic and mechanical engineering, manufactured with carefully selected components, and
assembled by people who are proud of the reputation their work has built for our company. We know this product will bring you many hours of
enjoyment, and after you discover the quality, value and reliability we have built into it, you too will be proud to be a member of our family.
Maintenance
Your product is designed and manufactured to ensure the minimum of maintenance. Use a dry, soft cloth for routine
exterior cleaning. Never use benzine, thinner, or other solvents.
If the replaced fuse fails, contact your nearest authorized Panasonic Service Centre.
Warning
¡ Use fuses of the same specified rating (15 A). Using substitutes or fuses with higher ratings, or connecting the unit direct-
ly without a fuse could cause fire or damage to the unit. If the replaced fuse fails, contact your nearest authorized
Panasonic Service Centre.
Anti-Theft System
This unit is equipped with a removable face plate. Removing this face plate makes the unit totally inoperable.
Caution
¡ This face plate is not waterproof. Do not expose it to
¡ Do not touch the contacts on the face plate and the main
water or excessive moisture.
unit, since this may result in poor electrical contact.
¡ Do not remove the face plate while driving your car.
¡ If dirt or other foreign substances get on the contacts,
¡ Do not place the face plate on the dashboard or nearby
wipe them off with a clean and dry cloth.
areas where the temperature rises high.
Removing Mounting
1 1
Turn off the power. Slide the left side of the face plate in place.
2 2
Press [ ]. The face plate will open. Press the right end of face plate until a
3 "click" is heard.
Pull it out toward you.
[ ]
Preparation
1 2
Set your car's ignition switch to the ACC Press [SRC] (PWR: Power).
or ON position.
ACC
ON
The 24-hour system is used for the clock.
1
Press [DISP] (CLOCK).
2
Hold down [DISP] (CLOCK) for more than
2 seconds.
3
Adjust the hour.
[[]: sets the hour ahead.
[]]: sets the hour back.
4
Press [DISP] (CLOCK).
5
Adjust the minute.
[[]: sets the minute ahead.
[]]: sets the minute back.
6
Press [DISP] (CLOCK).
Notes:
¡ "AdJ" is displayed before adjusting the clock.
¡ Hold down []] or [[] to change numbers rapidly.
Specifications
Power supply DC 12 V (11 – 16 V), test voltage 14.4 V, negative ground
Current consumption Less than 2.2 A (CD mode; 0.5 W x 4 channels)
Tone adjustment range Bass: ±12 dB at 100 Hz, Treble: ±12 dB at 10 kHz
Dimensions (W x H x D) 178 x 50 x 155 mm
Weight 1.3 kg
Maximum power output 45 W x 4 channels (at 1 kHz), volume control maximum
Power output 20 W x 4 (DIN 45 324, at 4 Ω)
Speaker impedance 4 – 8 Ω
Sampling frequency 8 times oversampling
DA converter 1 bit DAC System
Pick-up type Astigma 3 – beam
Light source Semiconductor laser
Wave length 790 nm
Frequency response 20 Hz – 20 kHz (±1 dB)
Signal to noise ratio 96 dB
Wow and flutter Below measurable limits
Channel separation 75 dB
FM
Frequency Range 87.5 MHz – 108 MHz
Usable Sensitivity 6 dB/µV (S/N 30 dB)
Stereo Separation 35 dB (at 1 kHz)
AM (MW)
Frequency Range 531 kHz – 1 602 kHz
Usable Sensitivity 28 dB/µV (S/N 20 dB)
Notes:
¡ Specifications and design are subject to modification without notice due to improvements.
¡ Some figures and illustrations in this manual may be different from your product.
