We would advise that you carefully study these Operating Instructions before attempting
to operate the vacuum cleaner and that you note the Important Safety Instructions.
Please keep in a safe place with your Authorised Dealer Service booklet.
This product complies with the directive 2006/95/EC and 2004/108/EC.
Model No.
Literature
Development:
Technology:
Codes Engineer
Quality:
Consumer Affiars:
Service:
Advertisement
Related Manuals for Panasonic MC-UG614
Summary of Contents for Panasonic MC-UG614
- Page 1 Model No. Literature Development: Technology: Codes Engineer Quality: Consumer Affiars: Service: We would advise that you carefully study these Operating Instructions before attempting to operate the vacuum cleaner and that you note the Important Safety Instructions. Please keep in a safe place with your Authorised Dealer Service booklet. This product complies with the directive 2006/95/EC and 2004/108/EC.
- Page 2 If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
- Page 3 • Do not use to pick up flammable or combustible materials, or others that may become so or use in areas where they may be pres- ent. • This appliance should be serviced by an authorised Panasonic Service Centre, and only genuine Panasonic spare parts should be used.
- Page 4 Handle Quick Release Upper Cord Hook OFF/FLOOR/CARPET Switch Mains Lead Dust Bag Cover (Dust Bag Inside) Carrying Handle HEPA Exhaust Filter Cover(Filter Inside) Swivel Model/Serial Numbers Clean Out/Hose Connector Port Nozzle Pile Height Indicator Belt Reset Button Handle Release Pedal Furniture Guard Height Adjustment Pedal...
- Page 5 Handle Cord Clip Screw Hole Handle Handle Handle Screw Screw Remove the handle screw from the rear of the Insert the handle assembly in the handle opening as handle unit. shown in the illustration. Using screwdriver, tighten handle screw. Make sure that cord hook is rotated in the upright position as shown.
- Page 6 The vacuum cleaner suction motor will continue to Belt Reset run. Button Turn off and unplug vacuum cleaner, remove obstruction, then press Allow 20 seconds to pass before attempting reset. If the problem persists, have the vacuum cleaner serviced by a qualified Panasonic technician.
- Page 7 Cord Clip Mains Lead Turn the quick release upper cord hook to either side Be sure the mains lead is locked under the cord clip on the rear of the handle. and down to release the mains lead. Plug the mains lead into a 240 Volt mains socket Detach the plug from the mains lead and pull the located near the floor.
- Page 8 There are four (4) pile height settings on the vacuum cleaner. For best deep down cleaning, use the XLO Shag, deep pile, or scatter rugs. setting. However, you may need to raise the height to Medium to deep pile. make some jobs easier, such as scatter rugs and Low to medium pile.
- Page 9 The stabilizer provided will add stability to the unit when sitting on unlevel surfaces or when using the attachment hose and accessories. 1. Remove stabilizer from filter cover holder. 1. Return stabilizer to vacuum by inserting it into the holder on the filter cover when finished. 2.
- Page 10 Connect any of the accessories, as indicated. Lift out accessories needed. To prevent damage to carpeted floors when using tools, lock handle in the upright position. The agitator will automatically shut off. Clean out/hose connect port Hose cuff (Small) Insert the smaller hose cuff such that corresponding To connect the hose, open clean out / hose connect arrows on the cuff and port align (Arrow on port to port door.
- Page 11 Dusting Fabric Brush Brush -11-...
- Page 12 Always follow all safety precautions when cleaning and servicing the vacuum cleaner. Place the handle in the upright position. Unplug the mains lead from the mains socket. Gather the mains lead and wrap it loosely around the upper cord hook and carry handle. Mains Lead Cord Hook Lock the plug onto the mains lead.
- Page 13 : Always operate vacuum cleaner with genuine Panasonic Type U-13 dust bag. Use replacement dust bag AMC-D1EP (TYPE U-13). Dust Bag Collar Dust Bag Cover Grasp the dust bag collar and pull gently, carefully Insert fingers in the latch recess at the top of the dust removing the dust bag from the dust bag holder.
- Page 14 Place Seal Side Against Vacuum Cleaner Body Press Filter Exhaust Cover Filter Release Exhaust Filter Cover The HEPA exhaust filter must be replaced when Remove the filter cartridge from cover. dirty. It should be replaced regularly depending on use conditions. be washed as it Place new filter cartridge into cover making sure that will lose its dust trapping ability.
- Page 15 Clean Out/Hose Connect Port Open clean out/Hose connect port door. Locate clean out/hose connect port. Remove any clog seen from dirt path. After dirt path is cleared close door until it snaps. -15-...
- Page 16 Always follow all safety precautions when performing maintenance to the nozzle. Screws Handle Release Pedal Turn nozzle upside down and unscrew four (4) Press release pedal and lower the handle. nozzle cover screws. Turn nozzle top side up. Rear Latches Side Latch Side...
- Page 17 In order to keep cleaning efficiency high and to prevent damage to your vacuum cleaner, the agitator End Cap Belt Path must be cleaned every time the belt is changed. The agitator must also be cleaned according to the following schedule: End Cap Agitator every week...
- Page 18 Motor Drive Agitator Belt Path End Cap Place agitator assembly into nozzle base. Install new belt over motor drive, then over belt path. Rest cover on front edge of base as shown. Rotate cover back. Press cover firmly until side latches snap into place.
- Page 19 Before contacting your Panasonic service centre, check the following points: Failure to correctly maintain your product, for example regular cleaning and unblocking, may result in a charge if referred to a service agent for attention. Vacuum cleaner won’t run. 1. Unplugged at mains socket.
- Page 20 POWER SOURCE 230-240V / 50Hz MAX. INPUT POWER 1000w MOTOR PROTECTION HOSE TURBINE UNIT DUSTING BRUSH CREVICE TOOL EXHAUST FILTER HEPA Material DIMENSIONS (W x L x H) 311x422x930 mm NET WEIGHT 6.0 kg -20-...
- Page 21 Or go on line through our Internet Accessory ordering application at www.pas-europe.com · Most major credit and debit cards accepted. · All enquiries transactions and distribution facilities are provided directly by Panasonic U.K. · It couldn’t be simpler! · Also available through our Internet is direct shopping for a wide range of finished products. Take a browse on our website for further details.
- Page 22 This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these products to designated collection points, where they will be accepted on a free of charge basis. Alternatively, in some countries you may be able to return your products to your local retailer upon the purchase of an equivalent new product.
- Page 23 -23-...
- Page 24 Pursuant to the directive 2004/108/EC, article 9 (2) Panasonic Testing Centre Panasonic Service Europe, a division of Panasonic Marketing Europe GmbH Winsbergring 15, 22525 Hamburg, F.R. Germany http://www.panasonic.net/ CØ1ZDRR3ØEØØ...
