Shure BETA 56 User Manual

MODEL BETA 56
COMPACT SUPERCARDIOID
DYNAMIC MICROPHONE
GENERAL
The compact Shure BETA 56 is a high output supercar-
dioid dynamic microphone designed for professional sound
reinforcement and project studio recording. Its extremely
uniform supercardioid pickup pattern provides high gain
before feedback and excellent rejection of unwanted noise. A
built–in dynamic locking stand adapter with an integral XLR
connector simplifies installation. The stand adapter keeps the
microphone securely in place, even if it is struck by a
drumstick. Typical BETA 56 applications include close miking
of tom–toms and other percussion instruments, as well as
guitar amplifiers, brass instruments, and woodwinds.
FEATURES
Tailored frequency response provides drums, amplified
instruments, and horns with studio quality sound
Built–in stand adapter with dynamic locking system and XLR
connector simplifies setup and provides greater flexibility
Uniform supercardioid pattern for high gain before feed-
back and superior rejection of off–axis sound
Compact design reduces stage clutter
Hardened steel mesh grille resists wear and abuse
Neodymium magnet for high signal–to–noise ratio output
Minimally affected by varying load impedance
Advanced pneumatic shock mount system that minimizes
transmission of mechanical noise and vibration
Legendary Shure quality and reliability
GENERAL RULES FOR MICROPHONE USE
1. Aim the microphone toward the desired sound source and
away from unwanted sources. This may not be obvious or in-
tuitive, since supercardioid microphones such as the BETA
56 have narrow pickup patterns and can pick up sounds from
the rear. Refer to Figure 1 on the following page.
2. Place the microphone as close as practical to the desired
sound source (refer to the table in the opposite column).
3. Work close to the microphone for extra bass response.
4. Use only one microphone to pick up a single sound source.
5. Use the fewest number of microphones as practical.
6. Keep multiple microphones separated by a distance equal
to at least 3X the distance to the nearest sound source.
7. Place mics as far as possible from reflective surfaces.
8. Use a windscreen when using the microphone outdoors.
2001, Shure Incorporated
27C2798 (BA)
Model Beta 56 User Guide
BETA 56 APPLICATIONS AND PLACEMENT
The most common BETA 56 applications and placement
techniques are listed in the following table. Keep in mind that
microphone technique is largely a matter of personal taste;
there is no one "correct" microphone position.
APPLICATION SUGGESTED MICROPHONE
PLACEMENT
Tom–Toms One BETA 56 on each tom, or be-
tween each pair of toms, 2.5 to 7.5
cm (1 to 3 in.) above drum heads.
Aim each mic at top drum heads.
On double head toms, you can also
remove bottom head and place a
mic inside pointing up toward top
drum head.
Snare Drum 2.5 to 7.5 cm (1 to 3 in.) above rim
of top head of drum. Aim mic at
drum head.
If desired, place a second mic just
below rim of bottom head.
Guitar & Bass 2.5 cm (1 in.) from speaker, on–
Amplifiers axis with center of speaker cone.
2.5 cm (1 in.) from speaker, at edge
of speaker cone.
15 to 30 cm (6 to 12 in.) away from
speaker and on–axis with speaker
cone.
60 to 90 cm (2 to 3 ft .) back from s-
peaker, on–axis with speaker cone.
Brass & Brass: 30 to 90 cm (1 to 3 ft.) away,
Woodwinds on–axis with bell of instrument.
Woodwinds: 2.5 to 15 cm (1 to 6 in.)
away, on–axis with bell of instru-
ment.
Bell of instrument 90 off–axis from
front of mic.
MOUNTING THE BETA 56 ON A MICROPHONE STAND
The built–in stand adapter features a dynamic locking sys-
tem that permits adjustments to the microphone's position, but
resists slipping when struck by drumsticks. To mount the BETA
56 on a stand and adjust its position, proceed as follows:
1. Screw the integral stand adapter onto the end of a micro-
phone stand (see Figure 4). Adjust the stand height and
position as necessary. Make sure the adjustment knob on
the adapter is loose.
2. Pivot the BETA 56 until it is in the desired position relative
to the drum head or instrument speaker.
3. Lock the BETA 56 in place by rotating the thumbscrew on
the stand adapter clockwise until it is tight. Do NOT use
tools to overtighten the adjustment knob.
4. If necessary, make minor adjustments to the microphone
position without loosening the adjustment knob.
5. Connect an audio cable to the integral XLR connector.
TONE
QUALITY
Medium attack;
full, balanced
sound.
Medium attack;
full, balanced
sound.
Most "snap"
from drumstick.
More "snare"
sound.
Sharp attack;
emphasized
bass.
Sharp attack;
higher frequency
sound.
Medium attack;
full, balanced
sound.
Softer attack;
reduced bass.
Bright, clear
sound.
Bright, clear
sound.
Softer, mellow
sound.
Printed in Mexico
