- Page 1 WIRED MICROPHONE BETA 53-54 USER GUIDE Le Guide de l’Utilisateur Bedienungsanleitung Guia del Usuario Guida dell’Utente Manual do Usuário Руководство пользователя 日本語 사용자 가이드 繁體中文 © 2015 Shure Incorporated 27A28418 (Rev. 1) Printed in U.S.A.
-
Page 2: General Description
General Description Shure models BETA53 and BETA54 are subminiature, electret condenser headworn microphones. They provide uncompromised sound quality and reliability with minimal visibility in applications such as broadcast, theater, and touring. Despite their small size, each microphone’s condenser element delivers full, clear, and natural reproduction of speech and vocals. - Page 3 • Requires phantom power Wireless Models These models are for use with Shure wireless microphone systems. TA4F Wireless Models connector attaches to wireless bodypacks (in-line preamp not included). These models are for use with Shure wireless microphone systems. TA4F •...
-
Page 4: Protective Caps
Adjusting the Headband and Microphone Windscreen Grip the internal frame of the windscreen firmly when connecting or removing. Do not pull on the foam itself. • To connect, push the windscreen until it snaps into place over the cartridge. • To remove, pull the windscreen directly off of the cartridge. Protective Caps ➀... -
Page 5: Positioning The Microphone
Positioning the Microphone Specifications BETA53/54 BETA 53 / WBH53 / RPM627 Type Electret Condenser Frequency Response 20 to 20,000 Hz Polar Pattern Omnidirectional Output Impedance (RPM627) 160 Ω • Position the omnidirectional BETA53 or directional BETA54 microphone Sensitivity near the corner of the mouth at 1kHz, open circuit voltage •... - Page 6 109.4 dB Cable The CE Declaration of Conformity can be ob- 1.5 m (5 ft) Self Noise tained from: www.shure.com/europe/compliance equivalent SPL, A-weighted, typical [1] 1 Pa=94 dB SPL Authorized European representative: 43.1 dB [2] THD of microphone preamplifier when applied input signal...
- Page 7 Accessories BETA54 BETA53 Component Black Component Black Microphone/Boom Assembly with TA4F RPM646 RPM648 Connector (1 piece) Foam Windscreen (5 pieces) RPM304 RPM306 Standard Protective Cap (gold mesh) (5 RPM208 RPM212 Standard Protective Cap (gold mesh) (5 RPM208 RPM212 pieces) pieces) Snap-fit Foam Windscreen (4 pieces) RPM316 RPM318...
- Page 8 1.0 uf (+5Vdc) Black (audio out) Shield (ground) 100k 2SK1109 +5Vdc – Case (ground) Wireless Test Circuit Microphone Cartridge 1. Rouge 1. Rot 1. Rojo 1. Rosso 1. 赤色 2. Noir (sortie audio) 2. Schwarz (Audioausgang) 2. Negro (salida de audio) 2.
- Page 9 BETA 53 BETA 54 –20 dB –20 dB –20 dB –20 dB –15 dB –15 dB –15 dB –15 dB –10 dB –10 dB –10 dB –10 dB –5 dB –5 dB –5 dB –5 dB 250 Hz 250 Hz 2.5 kHz 2.5 kHz 500 Hz...
- Page 10 Patent Notice: Patent Des. 451,902...
