Page 1: Operating Instructions
Operating Instructions LCD TV TX-22LT3 Model No. Please read these instruction before operating your set and retain them for future reference. English TQBC0635... -
Page 2: Table Of Contents
Welcome Dear Panasonic Customer, We hope that you have many years of enjoyment from your new TV. The Quick Start Guide section at the beginning of this instruction book will allow you to use the TV as quickly as possible.We recommend that you then read the complete instruction book, and keep it to refer to as you explore the range of advanced features that this LCD TV offers. -
Page 3: Warnings And Precautions
This type of LCD panel damage, is not an operating defect, sources of heat. and as such is not covered by the Panasonic warranty. FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT CAREFULLY This appliance is supplied with a fitted three pin mains plug for your safety and convenience. A 5 amp fuse is fitted in this plug. If the fuse is replaced then the replacement fuse must be 5 amp rated and should be approved by ASTA or BSI to BS1362. -
Page 4: Fitting Remote Control Batteries
Fitting remote control batteries Two “R6 (UM3)” size Insert batteries - note correct Slide off the battery cover Replace the cover polarity (+ and -) • Make sure that the batteries are fitted the correct way round. • Do not mix old batteries with new batteries. Remove old, exhausted batteries immediately. •... -
Page 5: How To Use The Lcd Stand
How to use the LCD stand Adjust the stand to your desired angle. The stand angle can be adjusted 15 backward. Quick Start Guide Choose Your Connection Type Connection and setting up options • If connecting the TV using an RF lead only, see below. •... - Page 6 Quick Start Guide 2. Connection of TV and VCR/DVD recorder using Scart and RF leads RF connection Connect the ANTENNA to the Antenna Input terminal of the VCR and an RF lead from the VCR Antenna Output terminal to this set Antenna Input socket ( Scart Connections The VCR can also be connected to the TV using a Scart lead.
- Page 7 Quick Start Guide 4. Q-Link connection of TV, VCR/DVD recorder and Satellite Receiver using Scart and RF leads For Q-Link to function correctly this set, VCR and Satellite Receiver must be connected as shown in the diagram. RF connections • Connect an RF lead to the Antenna Input terminal of the Satellite Receiver.
-
Page 8: Connecting The Ac Adaptor
Quick Start Guide Connecting the AC Adaptor Connect the external equipments. Connect the AC Adaptor DC plug to the DC IN socket. Plug into household mains socket. • Be sure to use the power cord and AC adaptor included in the accessories. •... - Page 9 Quick Start Guide Auto set up First, ensure that the recording device is in Standby mode, if it CH44 has Q-Link function and Satellite receiver is switched ON. If the TV has not been programmed for you then Auto setup will begin, your stations will be located, sorted into order and stored ready AUTO SETUP IN PROGRESS for use (refer to page 20).
- Page 10 Quick Start Guide Owner ID As an added feature, this TV has the option of entering Y o u n o w h a v e t h e o p p o r t u n i t y t o e n t e r y o u r d e t a i l s a n d a security code (Owner ID) and personal details into its h e l p t h e p o l i c e c r a c k c r i m e...
-
Page 11: Basic Controls: Top Panel And Remote Control
Basic controls: top panel and remote control TV/AV On / Off switch TV/AV switch STR (Normalization store) (see page 30) Used to store tuning and other function settings Increases or decreases the programme F (Function select) position by one. When a function is already Displays the On Screen Display functions, use repeatedly to displayed, press to increase or decrease the select from the available functions - Volume, Backlight,... -
Page 12: Using The On Screen Displays
Using the On Screen Displays Many features available on this TV can be accessed via the On Screen Display menu system. Use the remote control as shown below to access and adjust features as desired. The PICTURE, SOUND and SET UP buttons are used PICTURE SOUND SET UP... -
Page 13: Q-Link
Q-Link Q-Link allows the television to communicate with a compatible VCR or DVD Recorder. For Q-Link communication to work, the TV must be connected to a recording device with the “Q-Link”, “NEXTVIEWLINK”, “DATA LOGIC”, “Easy Link”, “Megalogic” or “SMARTLINK” logo using a “fully wired” Scart cable between the AV1/AV2 socket of the television and the appropriate socket on your VCR or DVD Recorder. -
Page 14: Picture Menu
PICTURE Picture menu PICTURE Press the PICTURE menu button Move to choose menu option Adjust chosen option or access chosen menu TV/AV Press the TV/AV button at any time to go back to watching TV Viewing Mode The Viewing mode menu allows you to select three different screen settings - Dynamic, Normal and Cinema. -
Page 15: Sound Menu
SOUND Sound menu SOUND Press the SOUND menu button Move to choose menu option Adjust chosen option or access chosen menu TV/AV Press the TV/AV button at any time to go back to watching TV Pressing the STR button after having adjusted a feature will store the setting as the default (replacing the factory setting). -
Page 16: Setup Menu
SET UP Setup menu SET UP Press the SETUP menu button Move to choose menu option Adjust chosen option or access chosen menu TV/AV Press the TV/AV button at any time to go back to watching TV Q-Link Allows you to select which AV socket is to be used Setup menu for data communication between this TV and a Q-Link... -
Page 17: Tuning Menu - Overview
Tuning menu - overview SET UP Press the SETUP menu button Move to Tuning menu option Access Tuning menu Move to choose menu option Adjust chosen option or access chosen menu TV/AV Press the TV/AV button at any time to go back to watching TV Pressing the STR button after having adjusted some features will store the setting as the default (replacing the factory setting). -
Page 18: Tuning Menu - Programme Edit
Tuning menu - Programme edit SET UP Press the SETUP menu button Move to Tuning menu option Access Tuning menu Move to Programme edit option Access Programme edit Move to choose programme position (eg: Prog. 3) Make required change, eg: moving a programme channel (see the relevant procedure below) TV/AV Press the TV/AV button at any time to go back to watching TV... -
Page 19: Renaming A Programme Channel
Tuning menu - Programme edit Renaming a programme channel Move to the Name column Programme edit Prog. Chan. Name Lock Choose the new character. The box at the bottom of CH44 CH51 the screen shows the character currently selected. CH41 CH47 CH37 Move to the next character position... -
Page 20: Tuning Menu - Auto Setup
Tuning menu - Auto setup Auto setup automatically retunes your TV. This feature is useful if, for example, you move house and wish to retune your TV to receive the local stations. SET UP Press the SETUP menu button Move to Tuning menu option Access Tuning menu Move to Auto setup Access Auto setup... -
Page 21: Tuning Menu - Manual Tuning
Tuning menu - Manual tuning It is possible to retune individual programme positions: SET UP Press the SETUP menu button Move to Tuning menu option Access Tuning menu Move to Manual tuning Access Manual tuning Select the programme position to be tuned Press repeatedly until required station is found When the desired station is found, press STR to store. -
Page 22: Shipping Condition
Shipping condition Shipping condition allows you to reset the TV to its original condition, i.e. no channels tuned in. This is useful, for example, if you move to a different area when you will probably want the TV to tune itself to your new local stations. -
Page 23: Owner Id
Owner ID Owner ID allows you to enter a security code(Owner ID) and personal details into its memory, so that in the unfortunate event of theft it will help the police to trace the owner. If you wish to check the personal details already entered into the TV, press the F button(Top panel) and hold for 6 seconds(initially the volume level function will appear, as you continue to hold down the F button it will... -
Page 24: Aspect Controls
Panasonic Auto switches to the appropriate 16:9 or 14:9 widescreen ratio. Panasonic Auto ‘Panasonic Auto’ appears in the top left of the screen if black stripes above and below the picture are detected. Panasonic Auto chooses the best ratio and expands the picture to fill the screen. - Page 25 Aspect Controls 16 : 9 16:9 will display a true 16:9 (anamorphic) picture with no aspect 16 : 9 distortions. << >> 16 : 9 14 : 9 14:9 will display a 14:9 letterbox or 4:3 picture with no aspect distortions. 14 : 9 Black stripes will be visible down the left and right sides of the picture.
-
Page 26: Vcr / Dvd Operation
VCR / DVD operation The Remote Control is capable of operating some functions of selected Panasonic VCRs and DVD (Digital Versatile Disc) equipment. Some VCR and DVD equipment have different functions, so to ensure compatibility please refer to the equipment’s instruction book or consult your dealer for details. -
Page 27: Teletext Operation
Teletext operation • Teletext features may vary depending on the Broadcasting Companies and is only available if the channel selected is transmitting Teletext. • Pressing the Picture button whilst in Teletext operation will display the backlight function with a white bar and the contrast function with a cyan bar, press to alter the setting as required. - Page 28 Teletext operation It is not possible to change the programme position when in News flash, Update or Sub Coded Page Access operation. Favourite Page (F.P.) Stores a favourite page in memory for instant recall. To store such a page, the TV must be in List mode, and the programme position must be from 1 - 25.
- Page 29 Teletext operation • If you have cleared the special function keys from the screen and then used the left and right cursor buttons to select a sub page, whilst still viewing the TV picture, you must press the SETUP button then the Yellow button to display the Teletext page SET UP again.
-
Page 30: Audio / Video Connections
Audio / video connections It is possible to connect a variety of additional equipment to this TV. The following pages detail how to connect external equipment to the rear of the TV. Once your equipment is connected, use the following procedure to view the input: Press the TV/AV menu button TV/AV Press the relevant on screen selector key to select the AV source... -
Page 31: How To Connect The Input Terminals
Audio / video connections How to connect the input terminals Scart cable S-VIDEO cable Connect the S-VIDEO or VIDEO Terminal VIDEO AUDIO Video S-Video Audio (Examples:) VCR/S-VIDEO VCR VCR/S-VIDEO VCR SET TOP BOX Q-Link COMPATIBLE VCR DVD PLAYER SET TOP BOX CAMCORDER DVD PLAYER S-VIDEO CAMCORDER... -
Page 32: Troubleshooting
If there is a problem with your TV please refer to the table below to determine the symptoms, then carry out the suggested check. If this does not solve the problem, please contact your local Panasonic dealer, quoting the model number and serial number (both found on the rear of the TV). -
Page 33: Maintenance
Maintenance To clean this unit, wipe with a soft, dry cloth. Neutral If the surfaces are extremely dirty, use a soft cloth dipped in soap-and-water solution detergent or a weak detergent solution. • Use eyeglass cleaner to remove stubborn dirt from the LCD. •... -
Page 34: Specifications
Specifications Power Source AC 100 - 240 V, 50 / 60 Hz Average use : 67 W Power Consumption Stand-by condition : 1.8 W TV set DC 15 V, 3.8 A max. 22-inch (558 mm) 16 : 9 aspect ratio LCD panel Screen Size 486.8 mm (W) 273.6 mm (H) - Page 36 ¥ Most major credit and debit cards accepted. ¥ All enquiries, transactions and distribution facilities are provided directly by Panasonic UK Ltd. ¥ It couldn’t be simpler! ¥ Also available through our internet is direct shopping for a wide range of finished products, take a browse on our website for further details.
