- Page 1 Installation Instructions / Warranty Terrano 37001XX1 Terrano 37020XX1 37028XX1 Terrano 37200XX1...
-
Page 2: Technical Information
37001XX1 Technical Information Recommended water pressure Max. water pressure Recommended hot water temp. Max. hot water temp Hole size in mounting surface Max. mounting surface depth Flow rate – lavatory Flow rate – bidet ⅜" supply hoses *Please know and follow all applicable local plumbing codes when setting the temperature on the water heater. -
Page 3: Installation Considerations
Installation Considerations • For best results, Hansgrohe recommends that this unit be installed by a licensed, professional plumber. • Please read over these instructions thoroughly before beginning installation. Make sure that you have all tools and supplies needed to com- plete the installation. - Page 4 Connect the hot and cold supply hoses to the stops. Use two wrenches, as shown in the diagram, to prevent hose twisting. Install the pop-up drain*. Turn on the water and check all connections for leaks. * Drain not included with 37028XX1...
-
Page 5: Install The Pop-Up Drain
Install the pop-up drain Remove the plunger assembly. Unscrew the drain outlet flange from the tee. Unscrew the tailpiece from the tee. Wrap the threads with Teflon tape and replace. Install the white, flexible sealing gasket to the flange. Place it in the sink outlet. Install the black mack gasket, white friction ring and retainer nut on the flange. -
Page 6: Replacement Parts
User Instructions Pivot the handle up to turn the water on, down to turn it off. Pivot the handle to the left for warmer water, to the right for cooler water. Replacement Parts handle 1.1 screw cover flange cartridge aerator fixation connection hose lift rod... -
Page 7: Limited Lifetime Consumer Warranty
Cleaning Recommendation for Hansgrohe Products Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when cleaning. -
Page 8: Exclusions And Limitations
THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR: A. Conditions, malfunctions or damage not resulting from defects in material or workmanship. Conditions, malfunctions or damage resulting from (1) normal wear and tear, improper installation, improper mainte- nance, misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or caustic cleaning agents or “no- rinse”...
