Main Trampoline And Front Trampolin (Option) - Hobie GETAWAY Owner's Manual

HOBIE GETAWAY
Slide the main trampoline bolt ropes into the hull trampoline tracks. Soapy water can be used as a lubricant
1
(Do not use an oil or silicon lubricant on the trampoline track or the bolt rope). Sliding the bolt rope into the
track is a 2 person job. One person should pull the trampoline and the other feed the bolt
rope into the track.
Tie a bowline knot to the forward left/port grommet in the trampoline. Pass the line through the opposite grom-
2
met, top/down and then through the lacing flap. Come up through the next (left) grommet and then continue to
lace towards the aft of the trampoline following this pattern (down through the right grommets and up through
the left grommets). Keep the laces loose at this time. Lace as far aft as the line will go.
Locate the aft lace rod. Feed the rod through the rear pocket as shown. Center the rod, from left to right, in the
3
pocket. Locate the aft lace lines. Tie to the rear grommets using a long looped bowline as shown (left and right
sides). Let the tramp hang below the aft crossbar.
Pull the lace lines under the cross bar and tight. Begin the aft lacing by routing the left line up and over the first
4
lace peg. Cross over to the next peg then down and around the rod. Pull the lace line tight then up and over
the peg and then over to the next one and so on... Then start with the right side and work towards the
center. When you reach the center, the pattern must be changed
slightly. Pass up and over the last peg, before the center, and then down around the
rod in the gap between tramp halfs. Then, come up and through the trampoline grom-
met on the opposite side. Once tied off loosely at the center, cinch the line tight from
each side working towards the center. Tie off to the main trampoline grommets just for-
ward of the aft cross bar.
7
TRAMPOLINE
