- Page 1 40000518.qxd 07/11/2003 12:13 Page 1 ® Washer Dryer Instructions for use HW6313M, HW6316M...
-
Page 2: Table Of Contents
40000518.qxd 07/11/2003 12:13 Page 2 Contents Page Introduction General delivery notes Safety notes Quick start Installation & testing Useful advice for the user Description of controls Detergent drawer Detergents, washing aids and amounts to use Programme selector The main wash Tumble drying Consumption data Programme Table... -
Page 3: Introduction
40000518.qxd 07/11/2003 12:13 Page 3 Introduction Please read and follow these instructions carefully and operate the machine accordingly. This booklet provides important guidelines for safe installation, use, maintainance and some useful advice for best results when using your machine. Keep all documentation in a safe place for future reference or for any future owners. -
Page 4: General Delivery Notes
A) Disconnect the plug from the mains supply. B) Turn off the water supply. C) Hoover equips all its appliances with earthing. Ensure that the mains power supply is earthed, if not, seek assistance from a qualified electrician. D) Do not touch the appliance when hands or feet are wet or damp. Do not use the appliance when bare-footed. - Page 5 40000518.qxd 07/11/2003 12:13 Page 5 J) The appliance must not be exposed to weather conditions (rain, direct sun, etc...) K) When moving the appliance never lift it by the controls, the detergent drawer, the hoses or the power cable. To avoid damaging the door when moving the appliance never rest the door against objects e.g a trolley.
-
Page 6: Quick Start
40000518.qxd 07/11/2003 12:13 Page 6 Quick start Washing – Open the door by pressing the DOOR button – Select the laundry and put it in the machine – Close the door – Put detergent in the dispenser compartments. Please refer to the programme guide table within this manual. -
Page 7: Installation & Testing
40000518.qxd 07/11/2003 12:13 Page 7 Installation & testing Note: when lifting the machine always use two people to avoid injuries. Remove the machine from the packaging – close to where it will finally be positioned remembering the plug must be easily accessible after installation – and proceed as follows: On the back of the machine 1) Remove the central screw A and side screws... - Page 8 40000518.qxd 07/11/2003 12:13 Page 8 Note: we recommend you keep the transit bracket and screws to protect the machine for future transit. The Manufacturers will not be responsible for any damage to the machine caused by not following the instructions relating to releasing the transit protection. The user is responsible for all installation costs.
-
Page 9: Water Supply Requirements
40000518.qxd 07/11/2003 12:13 Page 9 If you have no hot water supply or your hot Cold Water Supply water pressure is low: A cold fill adapter , allowing the installation of the machine with a cold water supply only can be purchased from Gias Service (Tel. -
Page 10: Testing The Installation
40000518.qxd 07/11/2003 12:13 Page 10 Testing the installation Refer to the programme guide for details of how to select programmes. 1. Turn on the water supply and check for leaks from fill hoses. 2. Switch on the electricity supply. 3. Select a spin programme and then press the on/off button to start the machine. - Page 11 Blue – NEUTRAL Brown – LIVE Green and Yellow – EARTH. If the mains cord on this appliance is damaged, it must be replaced by a special cord which is only obtainable from the Hoover spares service, GIAS (01204 556111).
-
Page 12: Useful Advice For The User
ARIEL – Chosen and recommended by Hoover When we produce a new washing machine we subject it to every test possible. And one of the most important tests is the one that enables our experts to identify the most suitable detergent for solving laundry problems. -
Page 13: Description Of Controls
40000518.qxd 07/11/2003 12:13 Page 13 Description of Controls All the controls on your product’s control panel are listed as follows. The button options are selected when the buttons are pressed in. Carefully read the relevant descriptions detailed below: On/Off After selecting the programme press the on/off button to start the machine. At the end of the cycle press again to reset the button and switch off the appliance. -
Page 14: Detergent Drawer
40000518.qxd 07/11/2003 12:13 Page 14 PROGRAMME Selector Note: never turn the knob anti-clockwise (Turn it clockwise and do not press the on/off button before selecting the programme). The tables in the washing section describe the various programmes and illustrate the number or symbol to select for them. DRYING TIME Selector For tumble drying select the appropriate drying programme via the drying time selector. -
Page 15: Detergents, Washing Aids And Amounts To Use
40000518.qxd 07/11/2003 12:13 Page 15 Note: some forms of detergents are difficult to dispense from the drawer e.g. concentrated powders. For these, we suggest you use the recommended dispenser which is placed inside the drum. This ensures that the liquid detergent is dispersed in the drum only when needed. –... - Page 16 40000518.qxd 07/11/2003 12:13 Page 16 Do not put solvents in the washing machine! Keep detergents and other laundry products out of children’s reach. Before pouring in the detergent check that there are no foreign bodies in the detergent drawer. Dosage details are usually shown on the detergent packaging. Follow those instructions! Dosages Only use detergents which are suitable for use in a washing machine.
-
Page 17: Programme Selector
40000518.qxd 07/11/2003 12:13 Page 17 Programme selector The washing machine has 3 different programme groups according to type of wash, temperature, spin speeds and duration for handling the various types of fabric and their level of soiling (see wash programme guide). 1. -
Page 18: The Main Wash
40000518.qxd 07/11/2003 12:13 Page 18 Main wash Auto half load The washing machine is fitted with a self adjusting water level system. This system enables the machine to use the optimum amount of water needed to wash and rinse the laundry in relation to the particular load. This results in a reduction of the water and electricity used without in any way compromising the washing and rinsing performance. - Page 19 40000518.qxd 07/11/2003 12:13 Page 19 Note: when sorting laundry – check there are no metal objects in the laundry (such as paper clips, safety pins, pins, coins etc...); In the event of a machine failure during the warranty period and foreign objects are found to be the cause of the failure a labour charge may be made for the...
- Page 20 40000518.qxd 07/11/2003 12:13 Page 20 Putting detergent in machine D) Open the drawer, choose the detergent and put in the correct amount, according to the manufacturer’s instructions and the detergent advice on page 15. Add any other laundry aids (see page 16).
-
Page 21: Tumble Drying
40000518.qxd 07/11/2003 12:13 Page 21 Tumble drying programmes Note: Dispensers used for concentrated powders and liquid detergents must be removed from the drum before commencing the tumble drying programmes Drying Process The load is dried in thermostatically controlled warm air. The drum changes direction during the drying cycle to prevent the laundry from tangling and hence produce even drying. - Page 22 40000518.qxd 07/11/2003 12:13 Page 22 Do Not Tumble Dry Woollens Training shoes ● ● Silk Fabrics with metallic decorations ● ● Delicate fabrics Garments with PVC or leather trimmings ● ● Nylon stockings Bulky items such as sleeping bags ● ●...
-
Page 23: Consumption Data
40000518.qxd 07/11/2003 12:13 Page 23 Safety Features This wash dryer includes a number of features to prevent damage to your laundry 1. During a drying cycle the time cannot be increased only decreased. 2. If the drying time selector is moved to the stop position (vertical) the drying programme cannot be restarted without turning the machine OFF and then back ON. -
Page 24: Programme Table
40000518.qxd 07/11/2003 12:13 Page 24 Programme guide PROGRAMME FABRIC TYPE PROGRAMME FOR DETERGENT LOAD WATER TEMP °C Whites Normal Colourfast fabrics Intensive – heavily 90° * * * & Prewash Cotton, linen, hemp soiled Coloureds Cotton, colourfast Normal soiling 60° Fast mixed fibres Coloureds... - Page 25 40000518.qxd 07/11/2003 12:13 Page 25 *By selecting the 90° Whites option (programme 1) the maximum water temperature can reach 90°C. When the option is not selected the maximum water temperature can reach 60°C. Points to consider: When washing heavily soiled laundry it is recommended the load is reduced by about 1-1.5 kg.
-
Page 26: Cleaning And Routine Maintenance
40000518.qxd 07/11/2003 12:13 Page 26 Cleaning and routine maintenance Do not use alcohol-based scourers and /or thinners on the outside of your washing machine, just a wipe with a damp cloth will suffice. The washing machine needs very little maintenance: –... - Page 27 40000518.qxd 07/11/2003 12:13 Page 27 Cleaning the door glass Regularly clean the door glass with a damp cloth. A build up of soiling and residues from the water may result in water leaking from the door. Do not use abrasive cleaners as they can scratch the surface. Transporting or storing the appliance for long periods when appliance is not in use...
-
Page 28: Trouble Shooting
40000518.qxd 07/11/2003 12:13 Page 28 Trouble shooting What might be the cause of... Defects you can remedy yourself Before calling GIAS Service for technical advice please run through the following checklist. A charge will be made if the machine is found to be working or has been installed incorrectly or used incorrectly. -
Page 29: Power Failure
40000518.qxd 07/11/2003 12:13 Page 29 Power failure If there is a power failure the wash cycle will be interrupted, the wash programme and functions will be suspended. When the power is restored, the wash programme and functions will re-start from the same point and complete the programme. -
Page 30: Customer Service
Your Guarantee Hoover guarantees all parts of this product for 5 years from the date of purchase. During that time Hoover will replace or repair all defective parts free of charge, except for parts subject to fair wear and tear such as belts. - Page 31 Hoover Spares Service Tel: 01204 556111 Hoovercare To maintain your Hoover product in peak condition you may wish to take out a Hoovercare policy, which for an annual payment provides a comprehensive maintenance and repair scheme. For more information please call 08705 400 600.
