Outdoor Firebowl
Model 10501573
CAUTION
Some parts may contain sharp edges - especially as
noted in manual. Wear protective gloves if necessary.
CAUTION
Read and follow all safety statements, warnings,
assembly instructions and care & use directions
before attempting to assemble.
WARNING
All surfaces can be hot during use. Use protection as
required to prevent burning.
For Outdoor Use Only
WARNING
Do not use this unit on or near combustible surfaces
or structures such as wood decks, dry leaves or
grass, vinyl or wood siding, etc. SEE OWNERS
MANUAL FOR IMPORTANT SAFETY INFORMATION.
DO NOT place any closer than 20 feet from any
combustible surface during use.
WARNING
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers
can fly out in breezy conditions. Adequate fire
extinguishing material should be readily available.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off
carbon monoxide, which has no odor. NEVER burn
charcoal inside homes, vehicles or tents.
42804557 01/07/10
