Char-Broil Alpine User Manual

4501134
Hide thumbs

Advertisement

Quick Links

Download this manual
Alpine
For Outdoor Use Only
CAUTION
THIS UNIT IS HEAVY!
DO NOT assemble without a helper.
CAUTION
Some parts may contain sharp edges – especially as
noted in manual. Wear protective gloves if necessary.
CAUTION
Read and follow all safety statements, warnings,
assembly instructions and use & care directions before
attempting to assemble.
WARNING
All surfaces can be hot during use. Use protection as
required to prevent burning.
Outdoor Fireplace
WARNING
Do not use this unit on or near combustible surfaces or
structures such as wood decks, dry leaves or grass, vinyl
or wood siding, etc. SEE OWNER'S MANUAL FOR
IMPORTANT SAFETY INFORMATION.
WARNING
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers can
fly out in breezy conditions. Adequate fire extinguishing
material should be readily available.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal
inside homes, vehicles or tents.
04501134
04201101
42804047 (12-14-05)

Advertisement

loading

Related Manuals for Char-Broil Alpine

Summary of Contents for Char-Broil Alpine

  • Page 1 04201101 04501134 Outdoor Fireplace Alpine For Outdoor Use Only CAUTION WARNING Do not use this unit on or near combustible surfaces or THIS UNIT IS HEAVY! structures such as wood decks, dry leaves or grass, vinyl DO NOT assemble without a helper.

  • Page 2: Parts List

    STOP! Missing a part? Call Our Help Line No need to go back to the store! The store where you made your purchase does not stock parts for this item. If you need parts, whether they are missing or damaged, call the Customer Service toll free Help Line.
  • Page 3 HARDWARE Hardware is shown actual size. You may have spare hardware after assembly is complete. #10-24x1/2” #10x1/2” Hex-Head Machine Screw Self-Tapping Screw Qty. 8 Qty. 1 #10-24x1/2” #10-24x3/8” Machine Screw Machine Screw Qty. 10 Qty. 8 #10-24 #10-24 Flange Hex-Keps Nut Qty.
  • Page 4 Attach door frames to front and rear edge of ash pan using three #10-24x1/2” machine screws and three #10-24 flange nuts per side. Hinge mounts should face inward. Hinge mounts facing inward. Door frame #10-24x1/2” Machine screw #10-24 Flange nut...
  • Page 5 Attach side panels to side edges of ash pan using two #10-24x1/2” machine screws and two #10-24 flange nuts per panel. When assembled, side panels will lean against door frames. Side panel #10-24x1/2” Machine screw #10-24 Flange nut...
  • Page 6 Attach tabs beneath top to tabs on side panels and doors frames using eight #10-24x1/2” hex-head machine screws and eight #10-24 flange nuts #10-24x1/2” Hex-head machine screw Side panel Door frame #10-24 Flange nut...
  • Page 7 Attach door hinges to hinge mounts on door frames using two #10-24x3/8” machine screws and two #10-24 hex- keps nuts per hinge. Door Door frame #10-24 Hex-keps #10-24x3/8” Machine screw Door...
  • Page 8 Align hole in chimney pipe with hole in top and secure using one #10x1/2” self- Chimney top tapping screw . Place chimney top onto pipe. Place log rack inside of fireplace on ash pan. #10x1/2” Self-tapping screw Chimney pipe Log rack...

  • Page 9: Use And Maintenance

    If you notice any of these surface conditions before the outdoor fireplace is used, contact the Char-Broil Service Center for a replacement of the defective component. Manufacturing defects are covered under Char-Broil's 90 Day Limited Warranty.

  • Page 10: Limited Warranty

    Limited Warranty Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning with the date of purchase. Upon proof of purchase as provided herein, Manufacturer will repair or replace the parts listed below which are proven defective during the applicable warranty period.
  • Page 11 Please register your product online at: www.grillregistration.com (If you register online, you do not need to send in this registration card.) WITHIN FAILURE TO RETURN MAY AFFECT YOUR WARRANTY COVERAGE PLEASE FILL OUT THIS CARD AND RETURN IT 10 DAYS OF PURCHASE. .
  • Page 12 Char-Broil, LLC • Columbus, GA 31902 • Assembly Instructions © 2005...

This manual is also suitable for:

Alpine 04501134
