JVC CS-BGS5120 Instructions Manual
  1. Manuals
  2. Brands
  3. JVC Manuals
  4. Subwoofer
  5. CS-BGS5120
  6. Instructions manual

JVC CS-BGS5120 Instructions Manual

Active subwoofer system
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

For Customer Use:
Enter the Model No. and Serial No.
which are located on the top or
bottom of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT1756-001A
[U]

Advertisement

Table of Contents
loading

Related Manuals for JVC CS-BGS5120

Summary of Contents for JVC CS-BGS5120

  • Page 1 For Customer Use: Enter the Model No. and Serial No. which are located on the top or bottom of the cabinet. Retain this information for future reference. Model No. Serial No. LVT1756-001A...

  • Page 2: Cautions And Notes

    Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. For safety..Do not raise the volume level too much, as this will block outside sounds, making driving dangerous.

  • Page 3: Installation

    INSTALLATION Mount this unit on a firm surface, such as on the floor. Since heat is generated in this unit, do not mount near flammable objects. In addition, mount in an area that will not prevent the unit from dissipating heat. CAUTIONS When mounting this unit, be sure to use the screws provided.
  • Page 4 CONNECTIONS If your receiver is equipped with Line Output, connect as in A. If your receiver is NOT equipped with Line Output, connect as in B. Insulation tape (supplied) After connection ,wrap the insulation tape around the terminals. Audio cord (not supplied) (not supplied) Remote output wire of receiver...
  • Page 5 When using speaker input terminal [HIGH INPUT] NOTE: If your receiver is equipped with the DSP (Digital Signal Processor), connect this unit to the front speaker output of the receiver. When using LINE IN jacks [INPUT] NOTES: If your receiver is equipped with the DSP (Digital Signal Processor), connect this unit to the Front Line Output jacks of the receiver.

  • Page 6: Phase And Sound Adjustment

    PHASE AND SOUND ADJUSTMENT Use CD with rich bass sound and adjust phase and sound. A PHASE switch Select either normal (NOM) or reverse (REV), which reproduce a better sound. This switch is preset to NOM when the unit is shipped. B POWER/PROTECTOR lamp The lamp lights in green while the unit is turned on.

  • Page 7: Troubleshooting

    TROUBLE SHOOTING For more details, consult JVC IN-CAR ENTERTAINMENT car audio dealer. No sound is heard. Is the REM wire connected correctly? Is audio cord connected to the LINE IN jacks? Is the speaker input connector connected correctly? Is this subwoofer system grounded? Alternator noise is heard.

  • Page 8: Specifications

    SPECIFICATIONS Type Active Subwoofer System (Built-in amplifier) Speaker Unit 30 cm (11-13/16 inch) cone Input Terminal LINE IN (1 system), 0.18 V – 4 V SPEAKER (1 system), 3.9 V – 12 V 350 W Maximum Amplifier Power Output Cut-off Frequency 50 Hz –...
  • Page 9 EN, CT, TH 0507SKMSANTKC 2007 Victor Company of Japan, Limited...
