QuickSpecs

Overview

1. Monitor (sold separately)

2. 2-Button Scroll Mouse (PS/2) or Optical Scroll Mouse (PS/2 or

USB)

3. HP Standard Keyboard (PS/2 or USB) or HP USB Smartcard

Keyboard

4. Front I/O: (2) USB 2.0, headphone and microphone

5. (1) Slimline Drive Bay

* Only one optional PCI riser card (the PCI riser or the PCI Express x16 riser) or one PCI Serial and parallel I/O adapter is allowed.

Ultra-slim Desktop

DA - 12543

North America — Version 17 — April 30, 2007

HP Compaq dc7700 Business PC

HP recommends

Windows Vista™ Business

6. (1) 3.5" internal bay

7. 200-watt Active Power Factor Correction (PFC) power supply

8. (1) full-height PCI slot (requires optional PCI riser), (1) low

profile PCI Express x16 slot (requires optional PCIe x16 riser)*

9. Rear I/O: (6) USB 2.0, (1) optional serial port (available via

adapter), (1) optional parallel port (available via adapter), (1)

optional DVI graphics port (available via DVI ADD2 adapter),

(2) PS/2, (1) RJ-45, (1) VGA, audio in/out

Page 1
