- Page 1 User's manual Twin-tub Washing Machine with Pump This manual is for HWM75-276S Please read this manual carefully before using. Retain it for future reference. 0030806004E...
-
Page 2: Table Of Contents
Contents Names of the parts Safety precautions Installation and adjustment Preparation before washing The musts in washing Usage of the detergent Washing sequence Disposal after washing Trouble-Shooting *Answer to question Packing list *Specification... -
Page 3: Names Of The Parts
Names of the parts Buzzer Water-filling entrance Water inlet selector handle Wash selector Wash timer Control panel Overflow filter Water level adjusting lever Lint filter Installed by user) Valve cover Pulsator Wash tub Drain hose Wash tub cover Base frame Meaning and description of the symbols Warning sign Forbidding sign... -
Page 4: Safety Precautions
Safety precautions Please insert the power cord into special receptacle with rated vol- tage.Be sure to use single-phase three pins receptacle.The earthing terminal of the receptacle must be earthed reliably.If possible,please adopt electric leakage protector. If the power cord is bad, to avoid risk it is required to replace it by the technicians ofour special shop or the after-sale service department. - Page 5 Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items ( such as the kettle with hot water ) on the washing machine.
-
Page 6: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Usage of the drain hose The drainage shall be smooth with the drain hose. 1.The height of the drain hose shall be less than 1.2m , or the drainage will not be smooth enough and cause incomplete drainage. -
Page 7: How To Change The Direction Of The Drain Hoses
How to change the direction of the drain hoses Figure 1 indicates the ex factory installation position of the drain hose. Extend the drain hose from the side of spin tub. Take off the drain hose from the hanging hole of the cabinet. Pull the drain hose fixing hook outwards gently to take out the drain hose from the two fixing hooks. -
Page 8: Preparation Before Washing
Preparation before washing Pay attention to followings before washing the laundries Check if Clear the the laundries pocket. Take has special out the coins, requirement sand, hairpins on washing etc. a. Check if the laundries are applicable for washing with machine. b. -
Page 9: The Musts In Washing
The musts in washing Usage of the detergent How to use the whitener Fill water to decided level. Dilute the whitener with container. Pour it slowly into the washing tub. Avoid using whitener on laun- dries with color or pattern as they are prone to lose color. -
Page 10: Washing Sequence
Washing sequence Wash selector (standard current, gentle current) Wash timer (To set to below 2 minute, first set to 5 minute then turn it back. it can increase the service life of the timer). STANDARD GENTLE DRAIN WASH SELECTOR WASH TIMER Wash 1.Water-filling selector (1) Set the water-filling selector at the "WASH"... - Page 11 Midway spinning 1.Put the laundries into the spin tub evenly and smoothly. 2.Spin (1) Put the gland in properly. Please put in the gland properly even if the laundries quantity is small. Push Gland Proper The laundries are slanting (2) Close the inner and outer cover of the spin tub. (3) Spin for 1-2 minutes.
-
Page 12: Rinse With Water-Filing
Rinsing Rinse with water-filing 1.Put the laundries into the wash tub. Select suitable current according to the laundries. 2.Adjust the water level Set the water level with water level adjusting lever according to the laundries quantity. Then fill suitable water continuously. 3.Rinse Adjust the wash timer to 5-7 minutes to do rinsing. - Page 13 Spinning 1. Put the laundries into the spin tub evenly and smoothly. 2. Press the gland in the tub properly. Close the inner and outer cover of the spin tub. 3. Spin Select suitable spin time according to the laundries, and do spinning. During spinning, if there's abnormal sound, it is generally owing to slanting placement of the laundries.
-
Page 14: Disposal After Washing
Disposal after washing After using, please clean the lint and foreign materials of the lint filter and overflow filter in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Cleaning the lint filter The lint filter must be used during washing. -
Page 15: Cleaning The Overflow Filter
Cleaning the overflow filter 2. Take off the corrugation pipe. Dismantle the upper part of the corrugation pipe overflow filter ( as indicated in Figure 1). 3. Cleaning the overflow filter Clean the lint around the filter and flush with tap water. 4. -
Page 16: Trouble-Shooting Answer To Question
Trouble-shooting Answer to question When the remained water is frozen Prevent the freezing (be sure to discharge the water completely after using) After complete draining, set the "WASH SELECTOR" at "GENTLE" or "STANDARD". If it is set at "DRAIN", it will be rather difficult for the frozen water to melt. When the water is frozen Pour hot water below 50 to soak it completely. - Page 17 Trouble-shooting Answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
-
Page 18: Packing List
Packing list Name User's manual Water inlet hose Lint filter Gland Twin-tub washing machine Specification Water level/Water quantity (about) Rated washing capacity(kg) Rated spinning capacity(kg) Injection pressure(MPa) Quantity One piece One piece One piece One piece One set Maximum/55L Medium/46L Minimum/36L 0.02~0.2...
