1385-7205-00_V8:_
230V Interconnectable Mains Operated Alarms For models:
COMPATIBLE
Your home is protected with a KIDDE Fyrnetics alarm/s
Please read through our guide in full. It should be retained for future reference.
Cut out page 6 and pin up near your Consumer Unit/Fuse Box.
Kidde Fyrnetics recommends for maximum protection that both ionisation and photo-electric
(optical) smoke alarms be installed. Ionisation sensing alarms may detect invisible fire
particles (associated with fast flaming fires) sooner than photoelectric alarms. Photoelectric
sensing alarms may detect visible fire particles (associated with slow smouldering fires)
sooner than ionisation alarms. Home fires develop in different ways and are often
unpredictable. For maximum protection, Kidde recommends that both Ionisation and
Photoelectric alarms be installed.Heat alarms are useful in areas with
condensation/dust/high humidity, such as kitchens and lofts.
Heat alarms MUST ALWAYS be interconnected to smoke alarms.
Electrical rating 230V AC,
50Hz 80mA max per alarm
(maximum 80mA for originating unit
with 24 Devices interconnected).
These alarms may be used with
the Kidde Wireless base accessory,
enabling interconnection between
alarms, wirelessly. The Remote,
Test & Hush accessory will also
work with alarms on Wireless bases.
Kidde Safety Europe, Mathisen Way, Colnbrook, SL3 0HB, UK.
INSTALLER, PLEASE LEAVE IN SAFE PLACE FOR HOUSEHOLDER
Contents
Alarm Range
Section
1.
Section
2.
Types of Alarm
Section
3.
Section
4.
Section
5.
Section
6.
Maintenance
Section
7.
Section
8.
Troubleshooting
Section
9.
Useful Hints
Section 10.
Good Safety Habits (Cut off Section)
Section 11.
What to do when the Alarm Sounds (Cut off Section)
Section 12.
Section 13.
Section 14.
Read this manual thoroughly and follow its instructions regarding
2011.3.14
5:20 PM
Smoke and Heat alarm
EN14604: 2005
Licence No. KM524754
BS 5446: Pt. 2: 2003
Lic No: KM503753
*Applicable to 1SF & 2SF Series
www.kiddefyrnetics.co.uk
© Kidde Fyrnetics 2008
SAVE THIS MANUAL FOR FUTURE REFERENCE
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
regular maintenance. - it could save your life.
1
Page 1
Ownerʼs Manual
1SFW, 1SFWR, 2SFW, 2SFWR,
3SFW and 3SFWR
*
0086-CPD-535595
+
+Applicable to 3SF Series
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
. . . . . . . . . . . . . . . . . . . . . . . . . .6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
1
®
. .8
. . . . . . . . . .6
1385-7205-00
Advertisement
Table of Contents
Related Manuals for Kidde Fyrnetics Slick 1SFW
Summary of Contents for Kidde Fyrnetics Slick 1SFW
-
Page 1: Table Of Contents
Please read through our guide in full. It should be retained for future reference. Cut out page 6 and pin up near your Consumer Unit/Fuse Box. Kidde Fyrnetics recommends for maximum protection that both ionisation and photo-electric (optical) smoke alarms be installed. Ionisation sensing alarms may detect invisible fire particles (associated with fast flaming fires) sooner than photoelectric alarms. -
Page 2: Important Information
3SFW: Mains heat alarm with alkaline back-up cell Also interconnectable to all Kidde Fyrnetics, Hard Wired 230V Smoke, Heat & CO Alarms. Models with RF reference “ -i ” are compatible with the RF-SFTP wireless base and remote KN-RTH-RF for wireless interconnect, remote test and Hush operations. -
Page 3: How To Operate/Test The Alarm
1385-7205-00_V8:_ 2011.3.14 5:20 PM Page 3 b. Alarm Types Ionisation (Ion) alarms are the most common type and provide early detection against • fast flaming fires and other fires. Most suitable for dining and living room areas. Ion alarms contain 0.9 microcurie of Americium 241, a radioactive material. BS5839 Pt6 recommend however, that optical alarms are also used especially in locations where steam or cooking fumes, from a nearby room could cause nuisance alarms. -
Page 4: Battery Checking/Changing
1385-7205-00_V8:_ 2011.3.14 5:20 PM Page 4 b. Testing • Utilise the test button to test the alarm. Do not use naked flames as this does not replicate smoke and may cause physical damage to the alarm or ignite combustible materials and start a structure fire. Test all your alarms weekly –... - Page 5 1385-7205-00_V8:_ 2011.3.14 5:20 PM Page 5 ii. Slide screwdriver blade in recess to unlock from base, as indicated by arrow to release locking tab iii. With screwdriver still inserted push alarm hard with palm of hand in direction of arrow, to slide off it's base.
-
Page 6: Develop And Practice A Plan Of Escape
1385-7205-00_V8:_ 2011.3.14 5:20 PM Page 6 Good Safety Habits (Section 11) Develop and practice a plan of escape: • Install and maintain Fire extinguishers on every level of the home and in the kitchen, basement and garage. Know how to use a fire extinguisher prior to an emergency. -
Page 7: Checking Battery Back-Up On Rechargeable/Long Life Models
1385-7205-00_V8:_ 2011.3.14 5:20 PM Page 7 6. Checking Battery Back-up on Rechargeable Long Life Models • There is no user replaceable battery on rechargeable models. This will be indicated on the product; additionally there is no battery compartment. To check charge on these models, switch off the alarms AC supply at the Consumer Unit/Fuse Box. -
Page 8: Section 9. Troubleshooting
1385-7205-00_V8:_ 2011.3.14 5:20 PM Page 8 9. Troubleshooting • Always turn off the mains supply to AC alarms before checking connections etc.. Symptom Possible cause/solutions 1. Green L.E.D. not lit a. Loss of mains power – check at Consumer Unit for Blown Fuse or tripped Circuit Breaker. -
Page 9: Limitation Of Smoke/Heat Alarms
14. Service and Guarantee Guarantee Kidde Fyrnetics guarantees to you as a purchaser that the enclosed alarm will be free of defects in material, workmanship or design under normal use and service for a period of 6 years, excluding any loose batery supplied. This extends to 10 years on Hard Wired Rechargeable, products (from the date of purchase) including the back up battery/powercell. - Page 10 5:20 PM Page 10 The liability of Kidde Fyrnetics, arising from the sale of this alarm or under the terms of this guarantee shall not in any case exceed the cost of replacement of the alarm, in no case, shall be...
