Roland MV-8000 Specifications

E n g i n e e r e d f o r F u l l P r o d u c t i o n .
Built-in USB port
64-voice polyphony
Pro-quality effects
&
Mastering Tool Kit
8-track audio recorder
16 Velocity pads
40GB hard drive
linear sequencer
Floppy disk drive CD-R/RW drive
T h e M V- 8 0 0 0 l e t s y o u t u r n s a m p l e s i n t o f i n i s h e d s o n g s
a n d b u r n i t o n C D — a l l w i t h s t r e a m l i n e d o p e r a t i o n .
A r e y o u r e a d y ?
R E A R V I E W
S P E C I F I C A T I O N S
Parts 16 (Patches) + 8 (Audio Tracks / Audio Phrases)
Maximum Polyphony 64 voices
Sampler Section
Audio Data Format 16 bits linear (24 bits processing)
Sampling Frequency 44.1 kHz (fixed)
Wave Memory (RAM) 128 MB (expandable up to 512MB when
internal memory is replaced with a 512MB DIMM)
DIMM: 1 slot (168-pin, PC100 CL=2
or PC133 CL=3, 3.3 V, 128/256/512 MB)
Maximum 128 MB DIMM installed (standard)
Sampling Time mono: 24 min. approx., stereo: 12 min. approx.
512 MB DIMM installed (expanded)
mono: 100 min. approx., stereo: 50 min. approx.
Effects Multi-effects (MFX): 1 (24 types)
Reverb: 1 (2 types)
Chorus: 1 (4 types)
Mastering Tool Kit: 1 (only in Mastering Mode)
Sequencer Section
Tracks MIDI tracks: 128 (1 MIDI channel per track)
Audio tracks: 8 pairs of stereo
Tempo track: 1
Resolution 480 TPQN
Tempo 5 - 300
Note Capacity approx. 150,000 notes
Song Length 9,999 measures
Recording Method Event recording (Realtime / Step)
Audio recording
128-track
M E D I A A N D F I L E F O R M A T C O M PA T I B I L I T Y
Import
from CD-R/RW Drive audio, .wav/AIFF, S-700 (Sample, Partial, Patch), AKAI MPC2000 Sound File ( .SND), ACIDized wave file, SMF (Format 0)
from PC/Mac via USB (or Floppy Disk) .wav/AIFF, AKAI MPC2000 Sound File ( .SND), ACIDized wave file, SMF (Format 0)
Export
to CD-R/RW Drive* MV-8000 native data (project back-up etc), audio
to PC/Mac via USB (or Floppy Disk) .wav/AIFF, MV-8000 native data (project back-up etc, only to PC/Mac via USB)
*CD-R/RW discs only.
M F X A L G O R I T H M L I S T
Isolator & Filter EZ Delay
Center Canceller RSS Delay
Stereo Dynamics Processor Analog Delay & Chorus
Reverb & Gate Digital Chorus
Tape Echo 201 4 Button Chorus 320
O P T I O N S
MV8-OP1
Audio I/O Expansion
FS-5U
DP-2
Pedal Switch Foot Switch
DR-20
Dynamic Microphone
*Shown with the optional MV8-OP1 Audio I/O Expansion.
Others CD-R/RW Drive Built-in type (CD-DA, CD-ROM, CD-R, CD-RW)
Songs: 16 Connectors Phono Input Jacks L, R (RCA pin type)
Project
Patches: 16 (per Song) MIC / Line Input Jacks L, R (1/4 inch phone type,
Partials: 96 (16 pads x 6 banks, per Patch) TRS balanced)
Samples: 9,999 Master Output Jacks L, R (1/4 inch phone type,
Audio Phrases: 512 (16 pads x 32 banks) TRS balanced)
Patch Libraries: 128 Headphones Jack (Stereo 1/4 inch phone type)
MIDI Clips: 100 Digital Out Connector A (Coaxial type)
Multi-effects (MFX) Libraries: 124 Digital Out Connector B (Optical type)
(Preset 24, User 100) MIDI Connectors (IN, OUT A, OUT B)
Chorus Libraries: 52 (Preset 2, User 50) USB Connector (supports file transfer,
Reverb Libraries: 54 (Preset 4, User 50) mass storage class)
Mastering Tool Kit Libraries: 71 Foot Switch Jack (1/4 inch phone type)
(Preset 21, User 50) AC Inlet
*The following are available when the optional
AD Conversion: 24 bits, 64 times oversampling
Signal Processing MV8-OP1 Audio I/O Expansion is installed:
DA Conversion: 24 bits, 128 times oversampling
Analog Multi Output Jacks 1- 6
(1/4 inch phone type, TRS balanced)
Frequency Response MIC / Line Inputs : 20 Hz - 20 kHz (+0 dB/-2 dB)
Digital In Connector A (Coaxial type)
Digital In Connector B (Optical type)
Nominal Input Level MIC / Line Inputs: -50 - +14 dBu
R-BUS Connector (8 channels digital output/
(maximum +26 dBu: balanced,
2 channels digital input, DB-25 type)
maximum +20 dBu: unbalanced)
Phono Inputs: -87 - -27 dBu
Power Supply AC 117 V, AC 230 V or AC 240 V (50/60 Hz)
MIC / Line Inputs: 40 k Ω
Input Impedance Power Consumption 40 W
Phono Inputs: 50 k Ω
Dimension 480 (W) x 482 (D) x 136 (H) mm
+4 dBu (balanced)
Nominal Output Level 18-15/16 (W) x 19 (D) x 5-3/8 (H) inches
600 Ω
Output Impedance Weight 9.8 kg / 21 lbs 10 oz (excluding MV8-OP1)
Master Outputs: 10 k Ω or greater
Recommended Load Accessories Quick Start
Headphones: 8 - 600 Ω
Impedance Owner's Manual
Mixer Block Diagram
Display 320 x 240 dots, graphic LCD (backlit) Sample Data CD-ROM
Backup CD-ROM
Pads 16 Pads Shortcut Stickers
Velocity and Aftertouch sensitive
Short Pin
Power Cord
Effects control knobs: C1 - C3
Controllers
Compatibility with PC and Macintosh Computers
Mixer sliders: 1 - 8
Floppy Disk Drive 3.5 inch Micro Floppy Disk 1.44 MB (2HD), OS Compatibility Windows: Microsoft® Windows® Me/2000/XP
720 KB (2DD)
Macintosh: Mac OS 9.0.4 or later/OS X
3.5 inch, 40 GB
Hard Disk Drive Driver The appropriate USB driver in the computer's OS
will automatically be selected when
the MV-8000 is connected to a computer.
Vintage Flanger 325 Stereo Distortion Vocal Multi
2 x BOSS Flanger Phonograph Modeling Voice Transformer
Stereo Pitch Shifter Radio Tuning Mic Modeling
80s Phaser Lo-Fi Processor Vocoder
Stereo Auto Wah Guitar Multi
Visit us online at www.Roland.com All specifications and appearances are subject to change without notice.
All trademarks used in this catalog are the property of their respective companies.
Printed in Japan OCT. '03 RAM-3742 BE-3 PBL-UPR-N
A C o m p l e t e S t u d i o f o r To d a y ' s P r o d u c e r s .
