- Page 1 Invented for life...
-
Page 2: Table Of Contents
Table of Contents Important Safety Instructions ........Installation ..........Before You Begin ............Tools and Parts Needed ............Parts Included ..............Cabinet Requirements ............Countertop Requirements ............Gas Requirements Supply Pressure ..........Propane Gas Installation (NGT Models only) ......... Installation Procedure ........... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE APPLIANCE AFTER INSTALLATION IS COMPLETE. IMPORTANT: SAVE FOR THE LOCAL INSPECTOR'S USE. Important Safety WARNING: Improper installation, adjustment, alteration, service or Instructions maintenance can cause injury or property damage. Refer to this man- ual. - Page 4 Gas Supply Pressure • Natural Gas - 6 inches water column (14.9 Millibars) minimum. • Propane Gas -11 inches water column (27.4 Millibars) minimum. The maximum supply pressure to this appliance shall not exceed 14.0 inches water column (34.9Millibars). Gas Appliance Safety WARNING: If the information in this manual is not...
-
Page 5: Installation
Installation Before You Begin Tools and Parts Needed Phillips Head Screwdriver Drill with 1/4" (6.35mm) bit Tape Measure Parts Included 1) Foam tape Hold down brackets (4) Screws, #10-32 x 2 1/2" (63.8mm) (4) Sheet Metal Screws, #8 x 3/8" (9.5mm) (4) Washers (4) Rubber Grate Foot (1 extra foot is included for future use if required) If parts are missing or damaged, call the number or write to the address listed... -
Page 6: Countertop Requirements
Countertop Requirements Figure 2 - Cutout Dimensions 3 _ (76.2 mm) Min. to_: Right Side Wail 1-3/4" (44.5 mm) Min. to Combustible Walt mm) cooktop depth to Left Side Wall (101.6mm) Below Countertop 1/8" Min Clearance from Cooktop to 4 3/8" (111 6mm) Start of Radius... -
Page 7: Installation Procedure
Installation Procedure WARNING: To avoid electrical shock hazard, before installing the cooktop, switch power off at the service panel and lock the panel to prevent the power from being switched on accidentally. 1) Seal the Cooktop with Apply the foam tape packaged with the cooktop to underside of the cooktop along Foam Tape the perimeter before installing. - Page 8 Figure 5 - Rough-in Box Area Opelfing for Gas Conl_ection and --. Electrical Cord u_tout for 30" models - 12-5/8" (3208 ram) for 36" models - 15-1/2" ( 394 mm) CAUTION: Do not attempt any adjustment of the pressure regulator, except conversion to propane.
-
Page 9: Connect Electrical Supply
• The appliance must be isolated from the gas supply piping system by closing its individual manual shut-off valve during any pressure testing of the gas sup- ply piping system at test pressures equal to or less than 1/2 psi (3.5kPa). 6) Connect Electrical Supply Before connecting 5-foot (1.5 m) supply cord to wall receptacle, make certain that gas shutoff valve and all burner controls are in OFF position. - Page 10 Fortechnical service questions c ontact C ustomer Relations a t 1 (800)944-2904. Forthemostuptodatecritical d imensions byfax,useyourfaxhandset andcall775-833-3600. Usecode# 8317. Wereserve therightto change specifications ordesign without n otice. S omemodels arecertified forusein Canada. BSH Home Appliances C orp. i s notresponsible forproducts w hicharetransported f romthe U.S. f oruseinCanada. C heck with yourlocalCanadian d istributor or dealer Note: T heBosch cooktop referred to throughout thismanual is manufactured by BSHHome Appliances C orp.
