Model No. WLEVEX1916.0
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, please call:
08457 089 009
Or write:
ICON Health & Fitness, Ltd.
Customer Service Department
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
email: csuk@iconeurope.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USER'S MANUAL
Visit our website at
www.iconeurope.com

Advertisement

Table of Contents
loading

Related Manuals for Weslo Pursuit T 169 Bike

Summary of Contents for Weslo Pursuit T 169 Bike

  • Page 1 USER'S MANUAL Model No. WLEVEX1916.0 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, please call: 08457 089 009 Or write: ICON Health &...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN .

  • Page 3: Before You Begin

    BEFORE YOU BEGIN Congratulations for selecting the new WESLO after reading this manual, please see the front cover ® PURSUIT T 169 exercise cycle. Cycling is one of the of this manual. To help us assist you, note the product...

  • Page 4: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the includ- ed tools and your own adjustable wrench and Phillips screwdriver Use the drawings below to identify the small parts used for assembly.
  • Page 5 3. Attach the Left and Right Frame Covers (19, 3) around the Frame (1) with an M4 x 15mm Round Head Screw (58) and two M5 x 15mm Round Head Screws (59) as shown. 4. Attach the Seat (12) to the Seat Carriage (29) with four M8 Split Washers (42) and four M8 Nylon Locknuts (10).
  • Page 6 6. While another person holds the Upright (13) near the Frame (1) as shown, connect the Extension Wire (23) to the Reed Switch Wire (39). Then, push the wires downward into the Frame (1). Next, insert the Upright (13) into the Frame (1). Be careful to avoid pinching the wires.
  • Page 7 8. Attach the Pivot Bracket (53) to the Upright (13) with the Pivot Clamp (54) and the Pivot Handle (55). Note: The Pivot Handle functions like a ratchet. Turn Be careful to the Pivot Handle clockwise, pull it away from the avoid pinching Upright, turn it counterclockwise, push it toward the the wires.

  • Page 8: How To Operate The Exercise Cycle

    HOW TO OPERATE THE EXERCISE CYCLE HOW TO ADJUST THE SEAT POST HOW TO ADJUST THE SEAT For effective exer- To adjust the hori- cise, the seat zontal position of should be at the the seat, loosen the Seat proper height. As seat knob on the Seat you pedal, there...
  • Page 9 CONSOLE DIAGRAM Select the manual mode. When you turn on the console, the manual mode will be selected. If you have selected a program, rese- lect the manual mode by pressing the Smart Programs button repeatedly until zeros appear in the display. Change the resistance of the pedals as desired.
  • Page 10 When you turn Note: The console can display speed and dis- Indicator tance in either miles or kilometers. The letters the power on, the scan dis- “mph” or “km/h” will appear in the display to show play will be which unit of measurement is selected. To change selected auto- the unit of measurement, hold down the On/Reset matically.
  • Page 11 As the target pace meter changes in height dur- HOW TO USE A SMART PROGRAM ing the program, adjust your pedaling pace so that the same number of bars appears in both Turn on the console. meters. If your pedaling pace is slower than the current target pace setting, an arrow will appear See step 1 on page 9.

  • Page 12: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the exercise cycle reg- Switch slightly closer to or away from the Magnet, and ularly. Replace any worn parts immediately. then retighten the Screw. Turn the Crank for a moment. Repeat until the console displays correct To clean the exercise cycle, use a damp cloth and a feedback.

  • Page 13: Conditioning Guidelines

    CONDITIONING GUIDELINES The following guidelines will help you to plan your During the first few minutes of exercise, your body uses easily accessible carbohydrate calories for ener- exercise program. Remember that proper nutrition and adequate rest are essential for successful results. gy.

  • Page 14: Part List

    PART LIST—Model No. WLEVEX1916.0 R1006A Key No. Qty. Description Key No. Qty. Description Frame M6 Nylon Locknut Front Stabilizer M8 x 73mm Button Screw Right Frame Cover M8 x 15mm Button Screw Front Stabilizer Endcap Belt Seat Post Crank Bearing Set Rear Stabilizer Flywheel Handlebar Endcap...

  • Page 15: Exploded Drawing

    EXPLODED DRAWING—Model No. WLEVEX1916.0 R1006A...

  • Page 16: Ordering Replacement Parts

    To help us assist you, please be prepared to give the following information: • the MODEL NUMBER of the product (WLEVEX1916.0) • the NAME of the product (WESLO PURSUIT T 169 exercise cycle) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
