RS-330-EDP
Deluxe Keyless Entry & Remote Start
Operation Guide
July 26, 2010
Temporary cover. Color cover is in a separate file.

Advertisement

Table of Contents
loading

Summary of Contents for Excalibur RS-330-EDP

  • Page 1 RS-330-EDP Deluxe Keyless Entry & Remote Start Operation Guide July 26, 2010 Temporary cover. Color cover is in a separate file.
  • Page 2: Table Of Contents

    Table Of Contents Introduction ���������������������������������������������������������������������������������������������� 3 The Transmitter���������������������������������������������������������������������������������������� 4 Transmitter Functions Reference Guide ����������������������������������������������� 4 Other Remote Start Features������������������������������������������������������������������ 7 Low Battery/Low Temp Automatic Starting �������������������������������������������� 7 Turbo Timer Feature ������������������������������������������������������������������������������ 7 Pit-Stop Feature ������������������������������������������������������������������������������������ 7 Manual Transmission Starting ��������������������������������������������������������������� 7 Using The Valet Switch ���������������������������������������������������������������������������...
  • Page 3: Introduction

    Each one has 4 different buttons which are labeled to indicate their primary function� The RS-330-EDP is also compatible with our ECHO 2-way upgrade kits. This popular upgrade gives you confirmation to the systems operations which are displayed on a LCD screen for easy reference�...
  • Page 4: The Transmitter

    The Transmitter Transmitter part numbers: 147-03 text buttons 147-03B icon buttons “lock” “unlock” Call your dealer or visit button button www.caralarm.com to order replacement transmitters. “trunk” “start” Transmitter battery replacement: button button Remove the small screw from the lower back case, and separate the transmitter halves�...
  • Page 5 Controlling The System (cont’d) TRUNK RELEASE/ CHANNEL 2: Press and hold the “TRUnK” button for 3 seconds� • THE TRUnK wILL OPEn, THE DOORS wILL UnLOCK, THE PARKIng LIgHTS wILL FLASH TwICE THEn ILLUMInATE FOR 30 SECOnDS, AnD THE HORn wILL HOnK TwICE� •...
  • Page 6 Controlling The System (cont’d) Panic Mode: Press & Hold the LOCK or UnLOCK button for 3 seconds� • THE HORn wILL SOUnD, THE PARKIng LIgHTS wILL FLASH AnD THE DOORS wILL LOCK OR UnLOCK, DEPEnDIng On THE TRAnSMITTER BUTTOn USED� •...
  • Page 7: Other Remote Start Features

    Other Remote Start Features LOw BATTERY/LOw TEMP AUTOMATIC STARTING This feature will automatically start the engine should the vehicle battery drop below 11 volts or the interior temperature drop to 15 (or 32) degrees fahrenheit� This feature is very useful when the vehicle is parked for a long period of time in cold climates�...
  • Page 8: Using The Valet Switch

    Other Remote Start Features (cont’d) 4) Press LOCK on the transmitter� The engine will shut down (unless turbo timer is on) and the status light will flash every 2 seconds to indicate it is ready to be remote started� NOTE: Manual transmission starting is canceled if you enter the vehicle after per- forming the setup procedure�...
  • Page 9 The Status Light (cont’d) 5) Flashing Fast (after activating remote start): The system is in the process of start- ing the engine� Remote Starting Diagnostics whenever the system is placed into Valet Mode, the Status Light illuminates solid. However, when this first occurs, the Status Light will flash 1 to 6 flashes be- fore resuming solid illumination�...
  • Page 10: Programming Transmitters

    Programming Transmitters Standard Programming: Using this method to program additional or replacement transmitters does not turn on or otherwise affect the Unauthorized Transmitter Alert (UTA) feature� Step 1 Have all transmitters which are to operate the system at hand� Then, turn the ignition “on”�...
  • Page 11: User Programmable Features

    Programming Features (cont’d) ~ The horn will honk, the status lights, and the parking lights will flash equal to the selected setting. Step 5 If you wish to change more features, repeat steps 3 & 4 at this time� Step 6 To exit programming, turn the ignition key “On” then “OFF”� Or, you can wait 10 seconds for programming mode to expire�...
  • Page 12: Installer Programmable Features

    User Programmable Features (cont’d) Feature #5 Doors Lock with Ignition On (press “unlock” button to program) - DEFAULT (press “lock” button to program) This feature configures the system to automatically lock the vehicle’s doors every time that the ignition switch is turned on� The following feature #6 controls the automatic unlocking operations�...
  • Page 13 Installer Programmable Features (cont’d) Before using, make sure this function is supported by the Databus Interface module� “Crank Only” AKA “blind start” is similar to the “Tachless” settings however, it only makes one start attempt and does not monitor engine running conditions� This is useful for many “push-to-start”...
  • Page 14 Installer Programmable Features (cont’d) Feature #6 Low Temp Crank Extender 0ms (Off) (press “lock” button to program) 200ms (press “unlock” button to program) - DEFAULT 300ms (press “trunk” button to program) 400ms (press “start” button to program) when the vehicle’s interior temperature is below freezing, this feature adds extra crank time to the base timing (see installer feature #5)�...
  • Page 15: Programmable Features Matrix

    Programmable Features Matrix User Feature Programming: Ignition on, off, press valet 5 times # Feature Lock Button Unlock button Trunk button ”START” button 1 Engine Run Time 10 min 5 min 15 min 20 min 2 Steady/Flashing lights for RS Steady Flashing 3 Horn Honk Volume...
  • Page 16 Back Cover Color cover is in a separate file.
