- Page 1 SBC Series Full Size 11-slots Chassis FA-UNIT-F11BE Full Size MicroATX Chassis FA-UNIT-F11ME User’s Manual CONTEC CO.,LTD.
-
Page 2: Check Your Package
Check Your Package Thank you for purchasing the CONTEC product. The product consists of the items listed below. Check, with the following list, that your package is complete. If you discover damaged or missing items, contact your retailer. Product Configuration List <FA-UNIT-F11BE>... -
Page 3: Copyright
No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document. The information in this document is subject to change without notice. -
Page 4: Table Of Contents
Parts of the Chassis ..........................7 Front Side View ..........................7 Rear Side View ..........................7 Dimensions .............................. 8 FA-UNIT-F11BE ..........................8 FA-UNIT-F11ME .......................... 10 Positions of backplane or motherboard installation holes............12 INSTALLING THE MOTHERBOARD Installing the backplane/motherboard ....................13 Preparation ............................. - Page 5 Installing/Removing a fan and filter .....................18 Installation conditions ...........................19 Installing the wall mount bracket......................20 CONNECTORS Power Supply ............................21 Backplane or motherboard power supply connectors ..............21 HDD/FDD power supply connectors.....................21 Switches and LEDs..........................22 USB Connector ............................23 SYSTEM REFERENCE Specification ............................25 FA-UNIT-F11BE, FA-UNIT-F11ME...
-
Page 6: Chassis [Fa-Unit-F11Be]
This chapter provides information you should know before using the product. About the Chassis FA-UNIT-F11BE is a chassis used to mount a backplane and SBC and configure a computer system in combination with expansion boards and various drives. FA-UNIT-F11ME is a chassis used to mount a motherboard and configure a computer system in combination with expansion boards and various drives. -
Page 7: Option
BPC-1111 PCI Backplane with 10-Slots(PCI x 10) Other FA-CLAMP-01 Clamp for PCI/ISA board (5 pcs) * Check the CONTEC’s Web site for more information on these options. Available Replaceable Parts for Maintenance POW300X 300W ATX Power Supply FAN1225S Fan 120 x 25 with Sensor... -
Page 8: Customer Support
You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited One-Year Warranty CONTEC products are warranted by CONTEC CO., LTD. -
Page 9: Safety Precautions
Operation of this equipment in a residential area is likely to cause harmful interference at his own expense. WARNING TO USER Change or modifications not expressly approved the manufacturer can void the user's authority to operate this equipment. FA-UNIT-F11BE, FA-UNIT-F11ME... -
Page 10: Power Cable
Even when using the product continuously, be sure to read the manual and understand the contents. Do not modify the product. CONTEC will bear no responsibility for any problems, etc., resulting from modifying this product. Regardless of the foregoing statements, CONTEC is not liable for any damages whatsoever (including damages for loss of business profits) arising out of the use or inability to use this CONTEC product or the information contained herein. -
Page 11: Environment
Inspect the product periodically as follows to use it safely. - Ventilating slits must neither be blocked nor have dust or foreign matters adhering. Front side view Rear side view (FA-UNIT-F11BE) RESET Rear side view (FA-UNIT-F11ME) - Ventilating slits must neither be blocked nor have dust or foreign matters adhering. -
Page 12: Name Of Each Part And Dimensions Diagram
HDD access LED RE SET USB port Fan replacement hatch Figure 2.1. Front Side View Rear Side View Connector plate Figure 2.2. Rear Side View of FA-UNIT-F11BE FAN cover Connector plate Figure 2.3. Rear Side View of FA-UNIT-F11ME FA-UNIT-F11BE, FA-UNIT-F11ME... -
Page 13: Dimensions
2. Name of Each Part and Dimensions Diagram Dimensions FA-UNIT-F11BE R2.5 R4.5 8-φ5 [mm] RESET Figure 2.4. Dimensions < FA-UNIT-F11BE, Horizontally placed > FA-UNIT-F11BE, FA-UNIT-F11ME... - Page 14 2. Name of Each Part and Dimensions Diagram R4.5 R2.5 8- φ 5 [mm] Figure 2.5. Dimensions < FA-UNIT-F11BE, Vertically placed > FA-UNIT-F11BE, FA-UNIT-F11ME...
-
Page 15: Fa-Unit-F11Me
2. Name of Each Part and Dimensions Diagram FA-UNIT-F11ME R2.5 R4.5 8-φ5 [mm] RESET Figure 2.6. Dimensions < FA-UNIT-F11ME, Horizontally placed > FA-UNIT-F11BE, FA-UNIT-F11ME... - Page 16 2. Name of Each Part and Dimensions Diagram R4.5 R2.5 8-φ5 (16) [mm] Figure 2.7. Dimensions < FA-UNIT-F11ME, Vertically placed > FA-UNIT-F11BE, FA-UNIT-F11ME...
-
Page 17: Positions Of Backplane Or Motherboard Installation Holes
Figure 2.8. Positions of backplane installation holes If a backplane or motherboard whose shaded area is not cut off is installed, then a 3.5-inch or 5-inch drive may not be installed properly depending on the height of the installed parts, etc. FA-UNIT-F11BE, FA-UNIT-F11ME... -
Page 18: Hexagon Spacer
In this case, select the positions of fixing holes so that the backplane or motherboard can be fixed in a balanced manner. (3) Return the fall-off prevention bar and cover to their original positions and fix them with screws. FA-UNIT-F11BE, FA-UNIT-F11ME... -
Page 19: Installing An Expansion Board
Insertion of expansion board (1) Remove the screws fastening the top cover, then remove the cover. When loosening the screws, use the appropriate type of screwdriver that fits the screw head. (2) Remove the fall-off prevention bar from the expansion board. FA-UNIT-F11BE, FA-UNIT-F11ME... -
Page 20: Unplugging An Expansion Board
(3) Remove the board by pulling it at a right angle to the expansion slot. (4) Use the screw to fasten the bracket removed when plugging the board. (5) Replace and screw the cover. FA-UNIT-F11BE, FA-UNIT-F11ME... -
Page 21: Replacing The Connector Plate
3. Installing the Motherboard Replacing the connector plate The supplied connector plate has holes for accepting connectors. If necessary, the supplied connector plate can be replaced with another plate of different shape. Figure 3.1. Replacing the connector plate FA-UNIT-F11BE, FA-UNIT-F11ME... -
Page 22: Installing Disk Drives
3. Installing the Motherboard Installing Disk Drives FA-UNIT-F11BE/FA-UNIT-F11ME can have two 5-inch drives and two 3.5-inch drives built in it. Preparation (1) Turn the power switch off. (2) Pull the power plug of the unit from the wall outlet. Installing Disk Drives (1) Remove the screws fastening the top cover, then remove the cover. -
Page 23: Installing/Removing A Fan And Filter
You can install/remove a fan and filter, without removing the top cover. Relay connector Finger guard Filter FAN cover The installation of the fan is obtained in the reverse order of detaching. Figure 3.2. Installing/Removing a fan and filter FA-UNIT-F11BE, FA-UNIT-F11ME... -
Page 24: Installation Conditions
Installation conditions To prevent a temperature rise, install this chassis at a distance of at least 50mm from obstacles such as walls. Front Side View Rear Side View Front Side View Rear Side View [mm] Figure 3.3. Installation conditions FA-UNIT-F11BE, FA-UNIT-F11ME... -
Page 25: Installing The Wall Mount Bracket
Installing the attached bracket enables wall mount. The bracket can be installed in two ways. Install the bracket using an appropriate method in accordance with the use environment. <Horizontally Placed> <Vertically Placed> Figure 3.4. Installing the wall mount bracket FA-UNIT-F11BE, FA-UNIT-F11ME... -
Page 26: Connectors
HDD/FDD power supply connectors 1. 12V YELLOW 2. GND BLACK To HDD or CD-ROM 3. GND BLACK 4. +5V 1. 12V YELLOW 2. GND BLACK To 3.5inch FDD 3. GND BLACK 4. +5V Figure 4.2. HDD/FDD power supply connectors FA-UNIT-F11BE, FA-UNIT-F11ME... -
Page 27: Switches And Leds
These switches and LEDs operate with their respective connector cables connected to the corresponding connectors on the SBC(CPU board). (1)Power SW White Black (2)Power LED Green(+) Black (3)HDD LED Red (+) Black (4)Reset SW Yellow Black Figure 4.3. Switch and LED Connector Cables FA-UNIT-F11BE, FA-UNIT-F11ME... -
Page 28: Usb Connector
USB internal connection connector. (CHASSIS GND) Pin 10 (GND) Pin 8 (USBP2+) Pin 6 (USBP2-) Pin 4 (VCC2) Pin 2 Pin 9 (N.C.) Pin 7 (GND) Pin 5 (USBP1+) Pin 3 (USBP1-) Pin 1 (VCC1) Figure 4.4. USB Connector Cable FA-UNIT-F11BE, FA-UNIT-F11ME... - Page 29 4. Connectors FA-UNIT-F11BE, FA-UNIT-F11ME...
-
Page 30: System Reference
AC Power Voltage *2 115VAC/230VAC(50/60Hz) (SW selection) Input current 10A(115VAC)/5A(230VAC) AC Outlet None Total of +5V and +3V shall not exceed the power of 200W. Input voltage range for AC power supply : 90 - 132VAC / 180 - 250VAC FA-UNIT-F11BE, FA-UNIT-F11ME... - Page 31 - Power supply About 5 years (25°C, 60%, official environment) - Cooling Fan About 5 years (25°C, 60%, official environment) - Fan filter About 1 year (25°C, 60%, official environment) FA-UNIT-F11BE, FA-UNIT-F11ME...
-
Page 32: User's Manual
