Mackie HDI501 Specifications

HD1501
The Mackie HD1501 15-inch powered subwoofer provides
intense low-frequency extension and punch to any Mackie
full-range system.
The ultra-portable HD1501 High-Definition Powered
Subwoofer delivers 1200W of peak system power via Class-D
Fast Recovery™ amplification. Class-D amp design delivers
up to 95% efficiency and, along with the lightweight switch-
mode power supply, drastically reduces this subwoofer's
weight.
EAW custom-designed HD Series transducers maximize
efficiency and performance when matched with the system's
internal amp. The 15-inch woofer uses a ferrite magnet with
a 3-inch voice coil.
Premium circuitry includes a symmetrical Linkwitz-Riley
crossover, precision tuning filters and user-friendly features
such as high pass outputs for stereo operation with a single
sub.
The lightweight and portable 15mm birch plywood
enclosures feature a ported, direct-radiating design. The
professional look of the HD1501 may be further enhanced
by defeating the front panel LED. The integrated pole-cup
accommodates a standard mounting pole. Pair the HD1501
with any Mackie full-range loudspeaker for an extremely
powerful and fully high-definition PA solution.
APPLICATIONS
Small to mid-size club/band PA systems, houses of worship,
DJs, rehearsal spaces, gymnasiums, banquet halls,
A/V rentals and many, many more.
HD1501
FEATURES:
15" High-Definition Powered Subwoofer System
■
600W RMS / 1200W peak of efficient Class-D Fast
■
Recovery amplification
™
15" woofer with 3" voice coil custom designed by EAW
■
High-definition audio processing includes:
■
• Symmetrical Linkwitz-Riley crossover
(100 Hz, 24 dB/octave)
• Precision tuning filters for accurate bass reproduction
• Phase alignment to perfectly complement Mackie
full-range loudspeakers
Ported, direct-radiating design for maximum punch and
■
low-frequency extension
Dual XLR inputs, full-range and high-pass outputs for
■
mono or stereo setups
Integrated limiting and protection circuitry
■
Compact and lightweight (80.0 lb / 36.4 kg)
■
Rugged all wood cabinet (15mm birch plywood)
■
Pole mount receptacle for mounting full-range
■
loudspeaker
HIGH-DEFINITION POWERED
SUBWOOFER
