HD1501
15" Powered Subwoofer
O W N E R ' S M A N U A L

Advertisement

Table of Contents
loading

Related Manuals for Mackie HD1501

Summary of Contents for Mackie HD1501

  • Page 1 HD1501 15” Powered Subwoofer O W N E R ’ S M A N U A L...

  • Page 2: Important Safety Instructions

    Important Safety Instructions 1. Read these instructions. 19. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC 2. Keep these instructions. Rules. These limits are designed to provide reasonable protection 3.

  • Page 3: Table Of Contents

    Integrated protection and limiting circuitry is ideal for small clubs, DJs and rehearsal spaces. It is • Rugged all-wood cabinet (15 mm birch also a great match when paired with the popular Mackie plywood) SRMv2 Series and can easily integrate into nearly any •...

  • Page 4: Hookup Diagrams

    MAIN ProFX12 Mixer This diagram shows the left line level output of a Mackie ProFX12 mixer feeding inputs A and B of one Mackie HD1501 subwoofer. Two SRM450v2 powered loudspeaker inputs are fed from the A and B High Pass outputs from the subwoofer. Experiment with the HD1501’s polarity switch to achieve optimum performance.
  • Page 5 CFX12mkII Mixer This diagram shows the left and right line level outputs of a Mackie CFX12mkII mixer feeding input A of two Mackie HD1501 subwoofers. The High Pass output A of each subwoofer then feeds the input of each Mackie HD1521 powered loudspeaker. Experiment with the HD1501’s polarity switch to achieve optimum performance.
  • Page 6 Onyx 1640i Mixer This diagram shows the left and right line level outputs of a Mackie Onyx 1640i mixer feeding input A of two Mackie HD1501 subwoofers. The Full Range output A of each subwoofer then feeds input A of another pair of Mackie HD1501 subwoofers. The High Pass output A of these subwoofers also feed the input of each Mackie HD1521 loudspeaker.

  • Page 7: Rear Panel Features

    Rear Panel Features OUTPUTS FULL RANGE HD1501 SETTINGS THERMAL 15 -INCH HIGH DEFINITION POWERED SUBWOOFER POWER LIGHT ON SIG/ LIMIT INPUTS HIGH PASS POLARITY INVERT LEVEL SERIAL NUMBER REVISION AVIS: RISQUE DE CHOC ELECTRIQUE — NE PAS OUVRIR WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
  • Page 8 OUTPUTS FULL RANGE HD1501 SETTINGS THERMAL 15 -INCH HIGH DEFINITION POWERED SUBWOOFER POWER LIGHT ON SIG/ LIMIT INPUTS HIGH PASS POLARITY INVERT LEVEL 3. INPUTS 5. FULL RANGE OUTPUTS These female XLR connectors accept balanced Balanced XLR male connectors are provided for the line-level signals from a mixing console or other signal line-level A and B full-range outputs.
  • Page 9 OUTPUTS FULL RANGE HD1501 SETTINGS THERMAL 15 -INCH HIGH DEFINITION POWERED SUBWOOFER POWER LIGHT ON SIG/ LIMIT INPUTS HIGH PASS POLARITY INVERT LEVEL 9. SIG/LIMIT LED 10. THERMAL LED This bi-color LED illuminates green whenever there is The HD1501 is equipped with a thermal protection a signal present at the main inputs.

  • Page 10: Ins And Outs Of Polarity

    Listed below are some recommended configurations rises, the woofer cone pushes out. Likewise, as the sine for pairing a Mackie HD-Series subwoofer (using the High-Pass output) with a Mackie full-range wave falls, the woofer cone pulls into the cabinet. A musical signal is much more complex, of course, but the loudspeaker.

  • Page 11: Placement

    Mackie loudspeakers. Use the optional model. It will continue to operate at lower voltages, but Mackie speaker mounting pole to mount them on the will not reach full power. HD1501. See the hookup diagrams starting on page 4.

  • Page 12: Appendix A: Service Information

    Appendix A: Service Information Poor bass performance If you think your Mackie product has a problem, please check out the following troubleshooting tips and do your best to confirm the problem. Visit the Support • Check the polarity of the connections between section of our website (www.mackie.com/support)

  • Page 13: Appendix B: Connections

    To locate the nearest service center, visit www.mackie.com, click “Support” and select “Locate a Service Center.” Service for Mackie products living outside the United States can be obtained through local dealers or distributors. If you do not have access to our website, you may call...

  • Page 14: Appendix C: Technical Information

    Crossover Frequency: 100 Hz specifications at any time without notice. “Mackie” and the “Running Man” figure are registered trademarks of LOUD Technologies Inc. 1 Calculated from peak driver sensitivity and amplifier power, half space. 2 Measured with swept sine at 1 W within operating range, scaled for max power, half All other brand names mentioned are trademarks or registered space.

  • Page 15: Hd1501 Graphs And Dimensions

    Frequency Response 1000 Frequency (Hz) HD1501 Dimensions 18.25 in/ 464 mm WEIGHT 18.25 in/ 25.0 in/ 80.0 lb 464 mm 635 mm 36.3 kg 25.0 in/ 20.0 in/ 20.0 in/ 635 mm 508 mm 508 mm Correct disposal of this product. This symbol indicates that this product should not be disposed of with your household waste, according to the WEEE Directive (2002/96/EC) and your national law. This product should be handed over to an authorized collection site for recycling waste electrical and electronic equipment (EEE).

  • Page 16: Hd1501 Block Diagram

    HD1501 Block Diagram HD1501...

  • Page 17: Hd1501 Limited Warranty

    The Product Warranty will not extend to anyone other than the original purchaser of the product (hereinafter, “Customer,” “you” or “your”). For products purchased outside the U.S. or Canada, please visit www.mackie.com/warranty to find contact information for your local distributor, and information on any warranty coverage provided by the distributor in your local market.
  • Page 18 16220 Wood-Red Road NE • Woodinville, WA 98072 • USA United States and Canada: 800.898.3211 Europe, Asia, Central and South America: 425.487.4333 Middle East and Africa: 31.20.654.4000 Fax: 425.487.4337 • www.mackie.com E-mail: sales@mackie.com OUTPUTS FULL RANGE HD1501 SETTINGS THERMAL 15 -INCH HIGH DEFINITION POWERED SUBWOOFER...
