DUAL MOTOR VACUUM
OWNERS MANUAL
MODEL#
SERIAL#
BARRACUDA
CUDA26
VIPER ...exceptional
value
REV.02(08-07)
VA51063
Advertisement
Table of Contents
Related Manuals for Viper BARRACUDA
Summary of Contents for Viper BARRACUDA
-
Page 1: Owners Manual
DUAL MOTOR VACUUM www.usviper.com OWNERS MANUAL IMPORTANT: READ OWNERS MANUAL CAREFULLY Please fill out & return your warranty card! CUDA26 MODEL# SERIAL# VIPER NORTH AMERICA VIPER ...exceptional P.O. BOX 104 value HAMILTON, MI 49419 (866) 418-4737 REV.02(08-07) (866) 41 - VIPER VA51063... -
Page 2: Table Of Contents
CONGRATULATIONS on your purchase of a Viper product, and welcome to the V.I.P. family. We appreciate your business and will do everything in our power to keep you happy with your purchase for many years to come. As part of the V.I.P. family, you are entitled to the best protection by one of the most comprehensive warranties in the industry. -
Page 3: Safety Precautions
1) Do not operate machine: - Unless trained and authorized - Unless you have read and SAFETY PRECAUTIONS understand operators manual - In flammable or explosive areas. GROUNDING INSTRUCTIONS - With damaged or modified cord or General – This carpet vacuum shall be plug. -
Page 4: Machine Components
MACHINE COMPONENTS 1) Handle 2) Power cord 3) Door latch 4) Power switch 5) Attachment tool intake & cord wrap 6) Vacuum hose 7) Brush housing 8) Brush height adjustment 9) Rear wheels 10) Exhaust vent 11) Handle height adjustment 12) Brush circuit breaker (bottom side) 13) Brush assembly (bottom side) 14) Rear door... -
Page 5: Machine Operation
MACHINE OPERATION 3) Occasionally check the bag for fullness & replace as necessary. 4) If brush stops spinning, there may be PRIOR TO VACUUMING CARPETS an obstruction in the brush. Unplug the 1) Inspect power cable and extension power cable, raise the brush off the cable for damage. -
Page 6: Machine Maintenance & Storage
NOTE: Be sure the bag / filter is 9) Inspect gaskets and seals for air leaks properly placed in bag housing to and replace as needed. ensure proper air flow. 10) Check vacuum hose for clogs and holes 5) To remove bag, simply reverse steps 1- and replace as needed. -
Page 7: Troubleshooting
Power cord is faulty Replace with approved power cord Building circuit breaker tripped Reset circuit breaker Faulty wiring Contact Viper Distributor Faulty on / off switch Contact Viper Distributor Check brush and belt for obstructions and Brush does not work... -
Page 9: Parts Lists
PARTS LIST PART DESCRIPTION NUMBER REQ'D VA51009 HANDLE HOUSING VA51025 BAG,PAPER,DUST,10.5qt. VA51007 REAR COVER AND BAG HOLDER GT13022 NUT, M5, NYLON INSERT VA51034 GASKET,ADAPTER VA51008 ELBOW ADAPTER,HOSE VA51022 PLUG AND CORD HOOK VV20501 SCREW,M5x14 VA51023-1 HOSE END VA51023-2 HOSE, 2" VA51029 COVER, EXHAUST FILTER VA51030... - Page 10 BOTTOM SHOE PLATE,26" VA51005 BRUSH,26" VA51047 BRACKET,RECTIFIER VA51003 BRUSH HOUSING,26" VA51006 SHAFT,BRUSH,26" VA51017 STRING GUARD,BRUSH VA51016 BLOCK,BRUSH SHAFT,RIGHT VV20502 SCREW,FLAT, M5X16 VA51048 LABEL, "BARRACUDA" VA51001 BASE HOUSING,26" VA51010 LATCH,HANDLE VA13476 SCREW,M5x40 VA51040 SHULDER BOLT,PIVOT VA51052 LABEL VA51012 TUBE,BASE HOUSING VV13635 SCREW,M5x20 VA51032...
-
Page 11: Accessories
ACCESSORIES PARTS LIST (VA51061) PART DESCRIPTION NUMBER REQ'D VA51060 HOSE ASSY VA20803 DUSTING TOOL VA20806 CREVICE TOOL...
