INSTALLATION GUIDE

CONTENTS
System Features .......................................
System Components .....................................
Required Tools ........................................
Technical Assistance ..................................
Before You Begin ....................................
Precautions ...........................................
Making Wiring Connections............................ 2-4
Locating & Making Connections ........................ 4-5
Neutral Safety Switch ................................. 6
Factory Anti-Theft System.............................. 7
Operating Instructions ................................ 7
Programming Instructions .............................. 7
Technicians are available Monday through Friday from 9:00 a.m. until 8:00 p.m. and Saturday 10:00 a.m. until 4:00 p.m.
Downloaded from: http://www.guardianalarms.net
OWNER'S GUIDE
REMOTE STARTER MODEL RS82
Technical Assistance
All tech personnel are expertly qualified to answer any technical questions.
288 Canton Avenue • Wintersville, Ohio 43953
Phone: 740-264-4710 • 800-878-8007 • Fax: 740-264-7306
•
Address
Telephone
1
1
1
1
1-2
2

Advertisement

Table of Contents
loading

Related Manuals for Bulldog Security RS82

Summary of Contents for Bulldog Security RS82

  • Page 1: Table Of Contents

    INSTALLATION GUIDE • OWNER’S GUIDE REMOTE STARTER MODEL RS82 CONTENTS System Features ........System Components ........Required Tools ........Technical Assistance ........Before You Begin ........Precautions ........... Making Wiring Connections......2-4 Locating & Making Connections ......4-5 Connecting the 11-Pin Harness and the 4-Relay Harness...6 Neutral Safety Switch .........

  • Page 2: System Features

    SYSTEM FEATURES Two-Button Extended Range Remotely start your car to run the heater or air conditioning from an extended distance. Remote Control Parking Light Confirmation signal and will remain on if the engine is remotely Confirms that your vehicle has received a remote signal and will remain on if the engine is remotely started.

  • Page 3: Precautions

    Since there are many different makes and models of vehicles, look at the wiring chart on or our website, www.bulldogsecurity.com/wires.htm. Read this manual thoroughly before starting the installation. You must decide if the parking light option is desired. An optional part #775 will be needed. Please do not skip any steps. TACH/TACHLESS OPERATION In most cases the decision to go with tachless mode will save time during the installation.
  • Page 4 4. Insert the wire from the unit through the hole as shown. 5. Wrap the wire around one side then the other and finally around itself as shown. 6. Use electrical tape to wrap. Be sure to cover the wire about two inches on either side of the connection.

  • Page 5: Locating & Making Connections

    4. Use electrical tape to wrap, be sure to cover about 2 inches on either side of connection. Secure with wire ties as shown. Electrical Tape Wire Tie Wire Tie Use this method ONLY when connecting two separate wires end to end. LOCATING &...
  • Page 6 YELLOW Parking Light Output (-) (Optional part #775 required) To parking Turn the parking lights to the ON position. (NOT YOUR HEADLAMPS). light circuit Probe the wire(s) coming from your headlamp switch. Find the wire that will show +12V only when the parking lights are ON and ground when the lights are OFF.

  • Page 7: Connecting The 11-Pin Harness And The 4-Relay Harness

    CONNECTING THE 11-PIN HARNESS & 4-RELAY HARNESS CAUTION: Before connecting the 11-pin harness to To +12V constant the module, double check all connections to be BLACK Ground sure they are secure and properly wrapped with electrical tape. Plug the 11-pin harness into the BROWN (-) Parking Light Output 250ma (Requires optional part #775)

  • Page 8: Factory Anti-Theft System

    FACTORY ANTI-THEFT SYSTEMS FOR GENERAL MOTORS CARS ONLY System 1: PASSKEY I and II system (1985 and up). This system has a resistor pill in the key. Measure resistance of the pill using a volt/ohm meter. A bypass module is available, part #VATS-WR module. System 2: PASSLOCK I and II system (1995 and up).
