Summary of Contents for Jabra SoleMate Mini
- Page 1 JABRA soleMate Mini User Manual jabra.com/solematemini...
- Page 2 ® © 2013 Gn netcom a/s. all rights reserved. Jabra is a registered trademark of Gn netcom a/s. all other trademarks included herein ® are the property of their respective owners. the Bluetooth word mark and logos are owned by the Bluetooth siG, inc. and any use of such marks by Gn netcom a/s is under license.
-
Page 3: Table Of Contents
6.1 tURn VoiCe GUiDanCe on 6.2 tURn VoiCe GUiDanCe oFF 6.3 listen to VoiCe GUiDanCe 7. UPDate FiRMwaRe ......16 8. sUPPoRt ..........17 8.1 Faq 8.2 how to CaRe FoR the JaBRa soleMate Mini 9. teChniCal sPeCiFiCations ...19 jabra solemate mini... -
Page 4: Welcome
1. welCoMe Thank you for using the Jabra Solemate Mini. We hope you will enjoy it! Jabra Solemate mini featureS ƒ Built in rechargable battery for on-the-go music ƒ Ultra portable design ƒ Dual speakers for powerful Sound ƒ Vibration dampening sole ƒ... -
Page 5: Speaker Overview
2. sPeaKeR oVeRView Volume down Answer/End (battery status) Volume up On/Off 3.5mm jack connector USB charging port Microphone 3.5 mm audio cable (under the sole) 3.5 mm audio cable Micro-USB cable (under the sole) jabra solemate mini... -
Page 6: Positioning The Speaker
2.1 pOSITIONING THE SpEAKER The Jabra Solemate Mini functions best when placed flat on any surface, and with the Jabra logo facing forward. 2.2 TURNING ON THE SpEAKER Slide the on/off switch up to turn the Jabra Solemate Mini on. -
Page 7: How To Charge The Battery
3. how to ChaRGe the BatteRy Connect the Jabra Solemate Mini to any available USB slot on your pC using the USB cable to charge the Jabra Solemate Mini. Alternatively, charge using your mobile device’s micro-USB charger (phone charger dependent). -
Page 8: Battery Status
The battery is full The battery is half full The battery is low The battery is critically low and requires immediate charging The battery takes approx. 3 hours to fully charge. The Jabra Solemate Mini can be used during charging. jabra solemate mini... -
Page 9: How To Connect
Bluetooth light flashes. Release the button. 2. Follow the voice-guided pairing instructions..note: If connection is lost (e.g. out of range) tap the Answer/end button when the Jabra Solemate Mini is in range and powered on to reconnect. jabra solemate mini... -
Page 10: Connect Using 3.5 Mm Jack Connector
4.2 CONNECT USING 3.5 MM JACK CONNECTOR Connect the Jabra Solemate Mini to any audio device with a 3.5 mm Jack Connector, using the supplied audio cable. The microphone and speaker volume are disabled on the Jabra Solemate Mini when connected via the 3.5 mm Jack Connector (the volume can still be adjusted using the connected device). -
Page 11: Connect Using Nfc
4.3 CONNECT USING NFC 1. Ensure that the Jabra Solemate Mini is turned on, and NFC is enabled on your mobile device. 2. locate and gently tap the nfC zone on the mobile device against the nfC zone on the Jabra Solemate Mini. -
Page 12: Play Music & Chat
Jabra Solemate Mini. If you cannot hear audio, ensure the device is connected to the Jabra Solemate Mini via 3.5 mm Jack Connector or Bluetooth, or turn up the speaker volume. The volume can be adjusted on the speaker, or on the connected device. - Page 13 Redial last Double-tap the answer/end number button when not on a call Tap the answer/end button Battery status when not on a call Mute/un-mute Tap both Volume up and Volume microphone down buttons at the same time jabra solemate mini...
-
Page 14: Voice Guidance
6.1 TURN VOICE GUIDANCE ON 1. Turn off the Jabra Solemate Mini. 2. press and hold the Volume up button while turning on the Jabra Solemate Mini. Release the Volume up button when you hear ‘Voice on’ . 6.2 TURN VOICE GUIDANCE OFF 1. -
Page 15: Listen To Voice Guidance
What you hear Go ahead and connect me. Use the Bluetooth setting in your phone Solemate is connected Bluetooth off Battery full Battery medium Battery low Recharge battery Muted un-muted Redialing Sound prompts off Sound prompts on Connection cancelled jabra solemate mini... -
Page 16: Update Firmware
7. UPDate FiRMwaRe To update the Jabra Solemate Mini firmware visit jabra.com/solematemini and download the latest firmware in the support section. Follow the on-screen instructions. jabra solemate mini... -
Page 17: Support
Ensure the speaker and the connected device are within range (up to 10 meters or 33 feet). Q What is the range of the speaker? A The Jabra Solemate Mini supports the following maxi- mum ranges: 10m/33ft. Q i am having bluetooth connecting problems A you may have deleted your Jabra Solemate pairing connection in Bluetooth device. -
Page 18: How To Care For The Jabra Solemate Mini
8.2 HOW TO CARE FOR THE JABRA SOlEMATE MINI ƒ Always store the speaker with the power off. ƒ Avoid storage at extreme temperatures (above -20°C/-68°F or below 65°C/149°F). This can shorten battery life and may affect speaker operation. ƒ Do not expose the speaker to rain or other liquids. -
Page 19: Technical Specifications
9. teChniCal sPeCiFiCations Jabra Solemate mini SpeCifiCation Weight: 330g H 60.5mm x W 53mm x D Dimensions: 126mm Microphones: Omni directional microphone 40mm x 25mm 4 Ohm 3W Nd- Speaker: Fe-B Type Round Operating range: 10m/33ft (phone dependent) Bluetooth version:... - Page 20 mini...
