Summary of Contents for Smeg SR610X
- Page 1 User Guide Manual SR610X SR620X Code : MRY6012-13...
-
Page 2: Table Of Contents
Disposal of Used Electrical & Refrigerant Information Electronic Equipment (R-134a Models Only) Refrigerant R-134a The meaning of the symbol on the product, its accessory or packaging indicates that this product Charge 0.190kg shall not be treated as household waste. Please, Global Warming Potential 1300 dispose of this equipment at your applicable... -
Page 3: Be Sure To Keep For Safety
Be sure to ground. Check if your wall outlet Be sure to keep for safety! is grounded (earthed). There is a risk of electric shock hazards. Read these safety instructions thoroughly and carefully before using. Please keep this user guide on hand for future Never unplug by pulling only the power cord reference. -
Page 4: Installation Guide
Never store any flammable gas or liquid CAUTION in the refrigerator. Be sure to unplug the refrigerator when it is Never use flammable gas, benzene, thinners, not going to be used for a long time. gasoline, spray etc. near the refrigerator. There is a risk of fire, explosion and personal injury or damage. -
Page 5: Control Panel
Do not let the power cord be crushed by other LIGHT/FILTER button 1) Button for dispenser light on. (heavy) objects . 2) Button for filter exchange or reset. If you hear a strange noise, strong chemical odour After exchanging or to reset press the button or find smoke etc. -
Page 6: Temperature Control
Displays the button 'Lock' Faster Cooling or FRZ.SET button Refrigeration Selection button for freezer compartment Lock button for control panel When you want faster cooling or refrigeration , push the Press button to prevent settings from being REF.SET button, until 'Super' LED turns on. Just push the unintentionally changed. -
Page 7: How To Use The Interior Parts
How to use the interior parts Non Dispenser Model Dispenser Model This instruction manual refers to several models. The real features are model dependent. 1. Door storage compartment 7. Xpress Can Chiller 13. Water filter (not all models) for short-term storage of food and for storing beverage ice cream. -
Page 8: Food Storage Tips
Food Storage Tips Refreshment compartment (Not all models) Wash foods before storing. Divide and separate foods into smaller pieces. 1. Softly press the upper centre of Home Bar to open (one-touch push type). - You can access the refreshment compartment without Place watery foods or foods with a lot of moisture in front opening the door thus saving electricity. -
Page 9: Magic Cool Zone (Option)
Magic cool zone How to use the Automatic (Option) Icemaker (For dispenser models) Magic cool zone Control graphic and Control function About 10 icecubes (14~15 times a day) are made at one time. If the ice storage case is full, icemaking stops. It is normal for the icemaker to make banging sounds when the icecubes are falling into the ice storage case. -
Page 10: Care & Cleaning
Care & Cleaning Be sure to unplug first Dispenser Water Shelf Freezer & Refrigerator Pockets Remove the spill grill and clean the water shelf Hold both ends and pull up. regularly. (The spill shelf is not self-draining.) Freezer & Refrigerator Shelves Open the doors fully, then pull the shelves forward to remove. -
Page 11: Before You Call For Service
How to Clean Problem Foods in the Interior Parts refrigerator get frozen. Use cloth with water and mild detergent to clean. Checkup Point Is temperature set to [High]? Is the room temperature too low? Is food with moisture stored close to the cold air spout ? Action Set the temperature to [Middle] or [Low]. -
Page 12: Something Strange? Don't Worry. Here Is The Answer
Something strange? Don’t worry. Here is the answer. Case Explanation Pipes (refrigerant vessel) are placed beneath the Front and side of refrigerator feels Heat warm or hot. surface to prevent moisture forming on it. When you close the door and then open again immediately, the door is not easy to open. -
Page 13: Installation Preparation
Installation Preparation If the refrigerator can not pass through a door Check if the refrigerator can pass a during installation, follow doorway or enter a door first. these steps. (This guide refers to several models. The real features are Dimensions (including Door Handles) 905mm 720mm 1770mm (Width*Depth*Height) model dependent.) -
Page 14: Replacing Refrigerator Door
Turn the hinge fastener tightly to the end. Removing Refrigerator Door Connect harness wirings and screw down the ground wire. Unscrew top hinge cover with a screwdriver. Insert a thin screwdriver into the side groove of the cover to remove. Fasten the bending tube guide and insert the water tube far into the coupling. -
Page 15: Refrigerator Leveling & Door Adjustment (If Needed)
Refrigerator Leveling & If the refrigerator door is not balanced by step 1, then follow the next steps. Door Adjustment (If needed) The refrigerator must be level in order to maintain optimal Insert a spanner (A part) into the hinge nut (1 part) and performance and desirable front appearance. -
Page 16: How To Install Water Line
Information concerning the water filter WATER SUPPLY KIT Check the parts below for installing water supply. Some other necessary parts are available at your local - After use, the water system is subject to low pressure. service agents. Proceed with caution when removing the filter. - Flush the water system if the appliance has not been in use for a long period of time, or if the ice/water has an unpleasant taste or smell.
