28
Satellite Name
LNB Frequency
LNB Power
22 kHz
DiSEqC 1.1
For the LNB Setting, move the cursor to Installation item and
£
¢
¡
press
button. Then, move the cursor to the LNB Setting
OK
£
¢
item and press
OK
£
¢
¡
Press
button to display the Satellite List. The list of Satel-
OK
lite is put in alphabetical order. Select one of the preprogrammed
satellites that corresponds to the direction of the antenna. If
the desired satellite name is not in the list, then select Other.
Select the L.O. Frequency of the LNB. The LNB Frequency of
5150, 9750, 10600, 10750, 11250, 11475, 9750/10600, 9750/10700
or 9750/10750 can be selected by
can insert LNB frequency by using Numeric key on the RCU.
Select LNB power On to output the LNB voltage.
If you are using a 22 kHz tone switch box, make 22 kHz tone
switch enable or disable to select LNB or antenna.
Note If the LNB Frequency is set to Universal LNB
(9750/10600, 9750/10700 or 9750/10750), it is not
possible to set 22 kHz because high or low band is
selected by 22 kHz.
The STB is designed to be DiSEqC 1.1 compatible. This allows
multiple antennas to be connected to the STB at the same time.
If you are using two or more fixed antennas or LNBs, then it
is recommended to use a DiSEqC 1.1 switch.
¡
button.
£
¢
V−
Operation
£
or
button. Also you
¡
¢
¡
V+
