Huffy Dual Electronic Basketball System Owner's Manual

Dual electronic basketball system
Hide thumbs Also See for Dual Electronic Basketball System:

Advertisement

Quick Links

Download this manual See also: Owner's Manual
WARNING!
READ AND UNDERSTAND
OPERATOR'S MANUAL BEFORE USING
THIS UNIT.
FAILURE TO FOLLOW OPERATING
INSTRUCTIONS COULD RESULT IN
INJURY OR DAMAGE TO PROPERTY.
ADULT ASSEMBLY REQUIRED
Complete assembly before use by children.
Unpacked product and parts must be kept
away from children. Discard all packaging
material and extra parts after assembly.
ELECTRICALLY OPERATED PRODUCT
As with all electric products, precautions
should be taken to prevent electric shock.
Not recommended for children under 6
years of age.
© COPYRIGHT 2004 by HUFFY SPORTS
Dual Electronic Basketball System

Owners Manual

• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
Toll-Free Customer Service Number for U.S: 1-800-558-5234,
For Canada: 1-800-284-8339,
For Europe: 00 800 555 85234 (Sweden: 009 555 85234),
For Australia: 1-800-333 061
Internet Address: http://www.huffysports.com
Customer Service Center
1
WARNING!
SHARP OBJECT
Inflation needle
Keep out of reach of small children.
Not for children under 3 years.
CHOKING HAZARD
Small parts: inflation needle and small
hardware.
Not for children under 3 years.
Keep bags away from babies
and children. Do not use in cribs,
beds, carriages or playpens.
The thin film may cling to nose
and mouth and prevent breathing.
06/04
P/N 211511

Advertisement

loading

Related Manuals for Huffy Dual Electronic Basketball System

Summary of Contents for Huffy Dual Electronic Basketball System

  • Page 1: Owners Manual

    Not recommended for children under 6 years of age. Toll-Free Customer Service Number for U.S: 1-800-558-5234, For Canada: 1-800-284-8339, For Europe: 00 800 555 85234 (Sweden: 009 555 85234), For Australia: 1-800-333 061 Internet Address: http://www.huffysports.com 06/04 P/N 211511 © COPYRIGHT 2004 by HUFFY SPORTS...
  • Page 2 We appreciate your purchasing one of our many fine products. We are sure that you will be very satisfied with your selection. Although great care and effort have been taken, occasionally problems may occur. To ensure prompt and correct handling of any problems, or to answer any questions, please contact our Toll-Free Customer Service Number listed on front page.
  • Page 3 Item Qty Part # Description 203980 Left Net Hanger Tube 213980 Right Net Hanger Tube 203981 Right Vertical Board Mounting Support Tube 213981 Left Vertical Board Mounting Support Tube 203982 Vertical Support Tube 203985 Angle Top Frame Support Tube 203986 Angle Bottom Frame Support Tube 203987 Middle Telescoping Ramp Support Square Tube...
  • Page 4 Assemble back frame with bolts (22), nuts (23), and by snapping pins into tubes as shown. P/N 211511 06/04...
  • Page 5 Attach score keeper (19) to backboard with Attach rims (17) to backboard (15) bolts (27), washers (32), and nuts (28). with bolts (25), back plates (16), and nuts (23) as shown. Repeat for opposite side. NOTE: Attach scoring paddles (20) onto Paddles must be backboard below rims (17) with centered underneath rim...

  • Page 6: Outside View

    Attach nets (35) to rims (17). OUTSIDE VIEW Attach backboard assembly to back frame with bolts (26), J-hooks (30), and nuts (23). P/N 211511 06/04...
  • Page 7 Slide ball ramp (21) onto back frame as shown. Assemble frame tubes (8 and 11). Install tube caps (14) as shown. 06/04 P/N 211511...
  • Page 8 Insert ramp support tube (12) into end loop of ball ramp (21). Pass tube through elastic loop of ball ramp and insert into frame tube (11) END LOOP OF BALL RAMP Secure 2nd strap to ramp support tube (12) as shown.
  • Page 9 Attach frame cross brace (13) to ramp support tube (12) with bolts (24) and nuts (23) to add tension to ball ramp. Hook elastic strap over J-hooks (30) and snap secondary straps together around tubes as shown. Plug paddle connector into scorekeeper (19). 06/04 P/N 211511...
  • Page 10 BACK VIEW OF SCORING UNIT Operation. ON/OFF ADAPTER PADDLE CONNECTIONS AC POWER: REMOVE AC ADAPTER FROM BOX. INSERT AC PLUG INTO SLOT ON SCORING UNIT. INSERT AC ADAPTER INTO 110 VOLT WALL OUTLET. TURN SCORING UNIT “ON”. Electronic Game Scoring 1.
  • Page 11 Telescoping Unit To/From Storage Position: A. Depress all four locking pins in telescoping tubes (8 and 11). B. While holding front section of frame, gently slide frame towards backboard (15). C. To return unit to playing position, slide front section of frame away from backboard (15) until all four pins lock frame into position.
