Summary of Contents for Turtle Beach Ear Force Z22
- Page 1 WIRED WIRED For: PS3 I Xbox 360 I PC ™ ® For: PC I Mac I Mobile ® I Mobile ® AMPLIFIED PC GAMING HEADSET User Guide...
- Page 2 Congratulations on your purchase of the Ear Force Z22 headset from Turtle Beach. The Z22 works with your PC or Mac and all of your favorite mobile devices. Welcome to the Turtle Beach Audio Advantage! For our Knowledgebase and Technical Support Contact info please visit: http://www.turtlebeach.com/support...
-
Page 3: Table Of Contents
table of Contents Package Contents Features Amplifi er Function Map / Use PC / Mac Hardware Setup ® PC Setup Mac Setup Mobile Setup On The Go Mobile Setup Auxiliary Specifi cations Compliance / Conformity Warranty... -
Page 4: Package Contents P4
# 1 I N G A M I N G A U D I O Quick Start Guide For the full user guide please go to www.turtlebeach.com/products/Z22 Product support and warranty information: Watch Turtle Beach product training videos at: youtube.com / TurtleBeachVideos TurtleBeach.com / support 3.5mm, 4-Pole Auxiliary Cable... -
Page 5: Features P5
Features Features · Adjustable Bass & Treble Levels: Tune bass and treble levels to add depth and realism. · Dynamic Chat Boost: Automatically adjusts the volume of chat based on game volume changes. · Independent Volume Controls: Separate game and chat volume controls plus mic mute on the inline amp. ·... -
Page 6: Amplifi Er Function Map / Use P6
Amplifier Function Map / Use Inline Amplifier Chat & Game Bass & Volume Controls Treble Controls Mic Switch: MODE SWITCH Mic On (High) Mic On (Low) Variable Mic Monitor Phone Call Mode Mic Mute Mic Mute Indicator LED: Chat Boost Indicator LED Bright blue = Mic On (High), Dark blue = Mic On (Low), Purple = Phone Call Mode,... -
Page 7: Pc / Mac ® Hardware Setup P7
When used as a PC/Mac gaming headset, the Z22 functions as an Amplified USB Stereo Headset. When connected to a PC or Mac, the Z22 appears in Windows and Mac operating systems as “TUrTLe BeACh Z22.” This allows the Z22 microphone to be assigned for chat use in game software as a USB audio device. -
Page 8: Pc Setup P8
NOTe: In order to maintain independent volume controls for chat and game, please make sure to set “TUrTLe BeACh Z22 ChAT” as both the recording and playback device in the audio setting for your voice chat application. -
Page 9: Mac Setup P9
1. Click on the Apple Menu and select System Preferences » Sounds. 2. On Output tab, select “headphones”. 3. On Input tab, select “TUrTLe BeACh Z22 ChAT”. NOTe: In order to maintain independent volume controls for chat and game, please make sure to set “TUrTLe BeACh Z22”... -
Page 10: Mobile Setup On The Go P10
Mobile Setup on the Go Direct Connection Connect the 3.5mm plug to a mobile device to listen to music or movies, play games or take phone calls. headset Works with many mobile devices... - Page 11 Mobile Setup Auxiliary Input Using the Inline Amplifier PLeASe NOTe: Inline amp must be in phone call mode or your voice will be routed over your PC/Console’s chat channel. You will hear the caller no matter where the switch is set but if not in the phone call mode, your caller will not hear you and others will.
-
Page 12: Specifi Cations P12
Specifications · PC/Mac Audio Connection: USB and stereo 3.5mm · Power: USB... - Page 13 Regulatory Compliance Statements for the Z22 Models Federal Communications Commission (FCC) Compliance notices Class B Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15, Subpart B of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 14: Declaration Of Conformity
Declaration of Conformity Heading Marking by this symbol: indicates compliance with the Essential Requirements of the EMC Directive of the European Union (2004/108/EC). This equipment meets the following conformance standards: Safety: EN 60950-1: 2006 + A11 + A1 + A12 (T-Mark License) Also Licensed for Standards: EC 60950-1: 2005 + A1: 2009, (CB Scheme Report/Certificate), UL60950-1 (NRTL License), CSA22.2, 60950-1 (SCC License) - Page 15 WARRANTY SERVICE: In the USA and CANADA Warranty Service is provided by our Turtle Beach USA offices and in all other Countries it is provided by our local International Distributors when available. Refurbished/Recertified products are sold on an AS IS basis with a 90-day Warranty or less in accordance with each ven- dor’s policy.
- Page 16 EXCLUSIONS FROM LIMITED WARRANTY: This Limited Warranty shall not apply and VTB has no liability under this Limited Warranty if the Turtle Beach Product: - is used for commercial purposes such as “LAN, Call Centers” (including rental or lease); - is modified or tampered with;...
- Page 17 Copyright © 2013 Voyetra Turtle Beach, Inc. (VTB, Inc.) All rights reserved. Turtle Beach, the Turtle Beach Logo, Voyetra, and Ear Force are either trademarks or registered trademarks of VTB, Inc. Mac is a registered trademark of Apple, Inc. All other trademarks are properties of their respective companies and are hereby acknowledged.
