Electro-Voice ETX-35P Specifications

Electro-Voice | ETX-35P
ETX-35P
▪ 2000 W amplifier and 136 dB peak SPL
▪ Single-knob DSP includes presets for multiple
configurations and top+sub combinations
(performance style, locations, and space)
▪ Loudspeaker system performance monitoring via
integrated LCD and front panel LED
▪ Features three high-sensitivity transducers, for high
output sound which is optimized for precise
coverage and low distortion
▪ Designed for floor, stacked, or a combo pole cup
(insert and threaded) for portable or permanent
installation (Eight (8) M10 threaded suspension
points)
ETX-35P from Electro-Voice is a high-power three-way
loudspeaker, it can be used in a variety of portable and
permanent applications.
The DSP (Digital Signal Processing) menus offer
extensive configurations, crossovers, selective voicing,
protection limiters, EQ modes, and a lockout mode
prevents casual changes to the system. Loudspeaker
system performance is optimized via an LCD screen.
The front LED indicates power or can be configured to
indicate limit.
ETX-35P features three (3) high-sensitivity
transducers, for high output sound which is optimized
for precise coverage and low distortion. ETX EV
designed and manufactured transducers include SMX
woofer technology using composite cone materials,
flux stabilizing rings, and thermal management. This
transducer yields lower distortion, smooth response
and high SPL. The high-efficiency DH3-B compression
driver has a convex diaphragm driving a coherent
phase device extending frequency response to 20 kHz.
EV's FIR-Drive technology utilized the latest FIR (Finite
Impulse Response) filter technology to optimize
transducer linearity and advanced limiter algorithms
for independent peak and thermal transducer
protection. The enclosure is constructed out of
18-mm, 13-ply birch plywood finished with EVCoat.
ETX combines EV-engineered intelligent DSP,
high-powered amplifiers and high-efficiency
transducers to deliver that legendary EV sound and
performance.

Technical specifications

Frequency Response (-3 dB):
Frequency Range (-10 dB):
Maximum SPL:
Coverage (H x V):
Power Rating:
LF Transducer:
MB Transducer:
HF Transducer:
Crossover Frequency:
Connectors:
48 Hz – 20 kHz
1
38 Hz – 20 kHz
1
136 dB peak
2
60° x 40°
2000 W
SMX2151 380 mm (15 in)
EVS-6C 6.5-in mid-bass driver
DH3-B 1.25-in titanium compression
driver
700 Hz, 2900 Hz
(2) XLR/TRS combo jack and (1) XLR
link output
