564 Diamond-Fyre™
WARNING:
If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of
life.
-
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
-
Installation and service must be performed by a qualified installer, service agency or the
gas supplier.
This appliance may be installed in an aftermarket permanently
located, manufactured home (USA only) or mobile home, where
not prohibited by local codes.
This appliance is only for use with the type(s) of gas indicated on
the rating plate. A conversion kit is supplied with the appliance.
Owner's Manual
© Copyright 2010, T.I.
Fireplace
• Operation
• Maintenance
$10.00
100-01249_000
Tested and Listed by
OMNI-Test Laboratories, Inc.
Portland, Oregon
Report # 028-F-80c-5
ANSI Z21.88a-2003
www.travisproducts.com
4100507
4800 Harbour Pointe Blvd. SW
Mukilteo, WA 98275
Advertisement
Table of Contents
Related Manuals for Travis Industries 564 diamond-fyre
Summary of Contents for Travis Industries 564 diamond-fyre
- Page 1 Tested and Listed by 564 Diamond-Fyre™ Fireplace OMNI-Test Laboratories, Inc. • Operation Portland, Oregon Report # 028-F-80c-5 • Maintenance ANSI Z21.88a-2003 WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Introduction
Or, mail your warranty card to: Model: 564 DF Fireplace Travis Industries House of Fire 4800 Harbour Pointe Blvd. SW Mukilteo, WA 98275 Serial Number: Save Your Bill of Sale. -
Page 3: Table Of Contents
Heating Specifications Natural Gas Propane Approximate Heating Capacity (in square feet)* Maximum BTU Input Per Hour 20,500 20,500 Minimum BTU Input on Low 8,700 6,000 Heating capacity will vary with floor plan, insulation, and outside temperature. 4100507 © Travis Industries 100-01249_000... -
Page 4: Safety Precautions
Immediately call a qualified vicinity of this heater. service technician to inspect the appliance and to replace any part of the control system and any gas control that has been under water. 4100507 © Travis Industries 100-01249_000... - Page 5 If any component becomes damaged, replace with Travis Industries components. Children and adults should be Travis Industries, Inc. grants alerted to the hazards of high no warranty, implied or stated, surface temperature and should for the installation or...
-
Page 6: Operation
This switch turns the secondary burner on and off. AA Battery Holder This holder contains 4 AA batteries that allow the fireplace to operate during power outages. This switch turns the fireplace burners on and off. Main Burner 4100507 © Travis Industries 100-01249_000... -
Page 7: Starting The Fireplace For The First Time
The secondary portion of the burner may be shut off to lower the heat output and overall flame size (this is called the comfort control). Use the comfort control switch to adjust the burner as desired. COMFORT CONTROL 4100507 © Travis Industries 100-01249_000... -
Page 8: Adjusting The Flame Height
Accent Light This fireplace has a built-in accent light that may be turned on and off and dimmed to your preference. Turn the knob to achieve the desired light output. HIGH ACCENT LIGHT 4100507 © Travis Industries 100-01249_000... -
Page 9: Adjusting The Optional Blower Speed
Frequent On / Off Operation – if you are frequently turning the fireplace on and off, you may wish to leave it in continuous pilot. This allows the burner to turn on more quickly, without pilot ignition delay. CONTINUOUS PILOT GREEN SMART PILOT 4100507 © Travis Industries 100-01249_000... -
Page 10: Normal Operating Sounds
This appliance has several areas that reach high temperatures. Dust or other particles on these areas may burn and create an odor. This is normal during start-up. You may notice the smell is more acute if the appliance was left idle for a long period. 4100507 © Travis Industries 100-01249_000... -
Page 11: Maintenance
Panel Lights Lift up and swing the lower grill down to acces the area below the Swing the concealment cover firebox. up and slide it back to expose AA Battery the controls. Holder AA Battery Tray 4100507 © Travis Industries 100-01249_000... -
Page 12: Accent Light Replacement
NOTE: When replacing the cast burner cover, make sure the notch on the cover fits over the pilot assembly on the right side. Remove the four screws securing the glass tray. Lift the tray up and place it aside. 4100507 © Travis Industries 100-01249_000... - Page 13 When replacing the crushed glass you may want to use a plastic bag to direct the glass around the perimeter of the burner cover (see photo below). The glass should cover the glass tray and be evenly dispersed. 4100507 © Travis Industries 100-01249_000...
-
Page 14: Yearly Service Procedure
If the pilot or main burners do not burn correctly, contact your dealer for service. Monitor blower operation. Remove any debris or vegetation near the vent termination. Contact your dealer if any sooting or deterioration is found near the vent termination. 4100507 © Travis Industries 100-01249_000... -
Page 15: Grill Installation And Removal
(this prevents the it allows the grill to swing bushing. Once in place the grill is grill from accidentally falling off). forward. held in place by gravity. 4100507 © Travis Industries 100-01249_000... -
Page 16: Face Installation And Removal
Some fireplaces have a face that fits over the glass frame. The face can be removed following the directions below. Phillips Screwdriver Four screws hold the face in place. The screws are accessed through the grills on the face. 4100507 © Travis Industries 100-01249_000... -
Page 17: Glass Frame Removal And Installation
Lift the glass frame slightly and attach the lower latches. NOTE: Make sure the glass frame is all the way in place - it should be flush with the front of the fireplace when installed. 4100507 © Travis Industries 100-01249_000... - Page 18 Top of Firebox Glass Frame Anchor Note how the washer on the latch fits behind the flange on the glass frame anchor. Once fully inserted, turn the latch until it is upright. 4100507 © Travis Industries 100-01249_000...
-
Page 19: Glass Cleaning
With the outer glass Inner glass frame frame and screen removed, the outer surface of the glass The optional screen is may be cleaned. sandwiched between the inner and outer glass frame. Outer glass frame 4100507 © Travis Industries 100-01249_000... -
Page 20: Troubleshooting Table
The AA batteries may be dead Replace the AA batteries (see page 11) Comfort Control Does not Work Improper air shutter adjustment Adjust Air Shutter - contact your dealer Thin Layer of Soot Covers the Glass 4100507 © Travis Industries 100-01249_000... -
Page 21: Wiring Diagram
IPI / CPI Black Green Blue White Black White CONTINUOUS PILOT BATTERY COMFORT MAIN BURNER TRAY GREENSMART CONTROL PILOT Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. 4100507 © Travis Industries 100-01249_000... -
Page 22: Greensmart Wiring Diagram
Receiver IPI / CPI Blue White CONTINUOUS (4) AA Batteries PILOT FAN CONTROL Fan Controller POWER 120 VAC INTERMITTENT Power In 110V OUT AUX OUT PILOT Accent Thermodisk Light (s) Optional Blower(s) Accent Light Rheostat 4100507 © Travis Industries 100-01249_000... -
Page 23: Replacement Parts List
Maintenance Replacement Parts List Caution: Use only Travis Industries replacement parts. Do not use substitute materials. Warning: Do not operate appliance with the glass front removed, cracked, or broken. Replacement of the glass should be done by a licensed or qualified service person. -
Page 24: Warranty
2. Travis Industries has the option of either repairing or replacing the defective component. 3. If your dealer is unable to repair your appliance’s defect, he may process a warranty claim through TRAVIS INDUSTRIES, INC., including the name of the dealership where you purchased the appliance, a copy of your receipt showing the date of the appliance’s purchase, and the serial number on your appliance. -
Page 25: Optional Equipment
This accessory allows for remote control of your fireplace (burner, flame height, accent light).. It has a built-in thermostat if you wish for automatic temperature control. Blower The optional blowers help transfer heat to your home. 4100507 © Travis Industries 100-01249_000... -
Page 26: Index
Safety Precautions .............. 4 Starting the Fireplace for the First Time ......7 Troubleshooting Table ............20 Turning the Fireplace On and Off ........7 Warranty ................24 Wiring Diagram ..............21 Yearly Service Procedure ........... 14 4100507 © Travis Industries 100-01249_000...
