Supero A+ SERVER 2022G-URF User Manual

Hide thumbs Also See for A+ SERVER 2022G-URF:
Table of Contents

Advertisement

Quick Links

Download this manual
S
UPER
®
A+ SERVER 2022G-URF
USER'S MANUAL
Revision 1.0b

Advertisement

Table of Contents
loading

Related Manuals for Supero A+ SERVER 2022G-URF

Summary of Contents for Supero A+ SERVER 2022G-URF

  • Page 1 UPER ® A+ SERVER 2022G-URF USER’S MANUAL Revision 1.0b...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 3: About This Manual

    Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the A+ SERVER 2022G-URF. Installation and maintainance should be performed by experienced technicians only. The A+ SERVER 2022G-URF is a high-end server based on the SC825TQ-R720UB 2U rackmount chassis and the H8DGU-F dual processor serverboard.
  • Page 4 A+ SERVER 2022G-URF User's Manual Chapter 6: Advanced Chassis Setup Refer to Chapter 6 for detailed information on the SC825TQ-R720UB server chassis. You should follow the procedures given in this chapter when installing, removing or reconfi guring SAS/SATA or peripheral drives and when replacing system power supply units and cooling fans.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    A+ SERVER 2022G-URF User's Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 UIO ........................1-2 Serial ATA ....................... 1-2 Onboard Controllers/Ports ................1-2 Graphics Controller ..................1-3 Other Features ....................1-3 Server Chassis Features ................
  • Page 7 Table of Contents Checking the Serverboard Setup ..............2-8 Checking the Drive Bay Setup ..............2-10 Chapter 3 System Interface Overview ......................3-1 Control Panel Buttons ..................3-1 Reset ....................... 3-1 Power ......................3-1 Control Panel LEDs ..................3-2 Power Fail ....................... 3-2 Overheat/Fan Fail: ..................
  • Page 8 A+ SERVER 2022G-URF User's Manual H8DGU(-F) Quick Reference .................5-11 Connector Defi nitions ................... 5-12 Jumper Settings .................... 5-18 Explanation of Jumpers ................5-18 5-10 Onboard Indicators ..................5-20 5-11 SATA Drive Connections ................5-21 5-12 Enabling SATA RAID ..................5-22 Serial ATA (SATA)..................
  • Page 9 Table of Contents Boot Menu ..................... 7-14 Exit Menu ...................... 7-15 Appendix A BIOS Error Beep Codes Appendix B Installing Windows Installing the Windows OS for a RAID System ..........B-1 Installing the Windows OS for a Non-RAID System ........B-2 Appendix C System Specifi...
  • Page 10 A+ SERVER 2022G-URF User's Manual Notes...

  • Page 11: Chapter 1 Introduction

    Chapter 1 Introduction Overview The A+ SERVER 2022G-URF is a high-end server comprised of two main subsystems: the SC825TQ-R720UB 2U server chassis and the H8DGU-F dual processor serverboard. Please refer to our web site for information on operating systems that have been certifi ed for use with the system (www.supermicro.com).

  • Page 12: Serverboard Features

    VER 2022G-URF User's Manual Serverboard Features At the heart of the A+ SERVER 2022G-URF lies the H8DGU-F, a dual processor serverboard based on the AMD SR5670/SP5100 chipset. Below are the main features of the H8DGU-F. (See Figure 1-1 for a block diagram of the chipset).

  • Page 13: Graphics Controller

    Chapter 1: Introduction Graphics Controller The H8DGU-F features an integrated Matrox G200eW graphics chip, which includes 16 MB of DDR2 memory. Other Features Other onboard features that promote system health include onboard voltage monitors, auto-switching voltage regulators, chassis and CPU overheat sensors, virus protection and BIOS rescue.

  • Page 14: Front Control Panel

    VER 2022G-URF User's Manual Front Control Panel The control panel on the A+ SERVER 2022G-URF provides you with system monitoring and control. LEDs indicate system power, HDD activity, network activity, system overheat and power supply failure. A main power button and a system reset button are also included.

  • Page 15: System Block Diagram

    Chapter 1: Introduction Figure 1-1. AMD SR5670/SP5100 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. DIMM A1 HT3 Link DIMM A1 DIMM A0 8x8-3.2GT/s DIMM A0 DIMM B1 DIMM B1 DIMM B0 HT3 Link DIMM B0 Socket G34...

  • Page 16: Contacting Supermicro

    + SE VER 2022G-URF User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 17: Chapter 2 Server Installation

    Unpacking the System You should inspect the box the A+ SERVER 2022G-URF was shipped in and note if it was damaged in any way. If the server itself shows damage you should fi le a damage claim with the carrier who delivered it.

  • Page 18: Warnings And Precautions

    A+ SERVER 2022G-URF User's Manual • This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display Units.

  • Page 19: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating temperature of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (Tmra).

  • Page 20: Installing The System Into A Rack

    A+ SERVER 2022G-URF User's Manual Installing the System into a Rack This section provides information on installing the SC825 chassis into a rack unit with the quick-release rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the installation instructions that came with the rack unit you are using.
  • Page 21 Chapter 2: Server Installation Figure 2-1: Separating the Rack Rails Separating the Inner and Outer Rails Rail Assembly Locate the rail assembly in the chassis packaging. Extend the rail assembly by Extending the Rails pulling it outward. Press the quick-release tab. Separate the inner rail Quick-Release Tab extension from the outer rail...

  • Page 22: Outer Rack Rails

    A+ SERVER 2022G-URF User's Manual Figure 2-2. Assembling the Outer Rails Outer Rack Rails Outer rails attach to the rack and hold the chassis in place. The outer rails for the SC825 chassis extend between 30 inches and 33 inches.
  • Page 23 Chapter 2: Server Installation Figure 2-3. Installing the Rack Rails Installing the Chassis into a Rack Extend the outer rails as illustrated above. Align the inner rails of the chassis with the outer rails on the rack. Slide the inner rails into the outer rails, keeping the pressure even on both sides.

  • Page 24: Checking The Serverboard Setup

    A+ SERVER 2022G-URF User's Manual Checking the Serverboard Setup After you install the 2022G-URF in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. Accessing the inside of the System First, grasp the two handles on either side and pull the unit straight out until it locks (you will hear a "click").
  • Page 25 Chapter 2: Server Installation Figure 2-3. Accessing the Inside of the System...

  • Page 26: Checking The Drive Bay Setup

    A+ SERVER 2022G-URF User's Manual Checking the Drive Bay Setup Next, you should check to make sure the peripheral drives and the SAS/SATA drives have been properly installed and all connections have been made. Checking the Drives All drives are accessable from the front of the server. For servicing the DVD- ROM, you will need to remove the top chassis cover.

  • Page 27: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specifi...

  • Page 28: Control Panel Leds

    A+ SERVER 2022G-URF User's Manual Control Panel LEDs The control panel located on the front of the chassis has several LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 29: Hdd

    Chapter 3: System Interface On the A+ SERVER 2022G-URF, this LED indicates hard drive and/or DVD-ROM drive activity when fl ashing. Power Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating.
  • Page 30 A+ SERVER 2022G-URF User's Manual Notes...

  • Page 31: Chapter 4 System Safety

    System Safety Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the A+ SERVER 2022G-URF from damage: • Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.

  • Page 32: General Safety Precautions

    A+ SERVER 2022G-URF User's Manual • This product may be connected to an IT power system. In all cases, make sure that the unit is also reliably connected to Earth (ground). • Serverboard Battery: CAUTION - There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 4-1).

  • Page 33: Esd Precautions

    Chapter 4: System Safety • Remove any jewelry or metal objects from your body, which are excellent metal conductors that can create short circuits and harm you if they come into contact with printed circuit boards or areas where power is present. •...

  • Page 34: Operating Precautions

    A+ SERVER 2022G-URF User's Manual Operating Precautions Care must be taken to assure that the chassis cover is in place when the 2022G- URF is operating to assure proper cooling. Out of warranty damage to the system can occur if this practice is not strictly followed.

  • Page 35: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install processors and heatsinks to the H8DGU-F serverboard, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are described and a layout and quick reference chart are included in this chapter.

  • Page 36: Processor And Heatsink Installation

    + SE VER 2022G-URF User's Manual Processor and Heatsink Installation When handling the processor, avoid placing direct pressure on the label area of the fan. Also, do not place the serverboard on a conductive surface, which can damage the BIOS battery and prevent the system from booting up.
  • Page 37 Chapter 5: Advanced Serverboard Setup Use your thumb and your index fi nger to hold the CPU. Locate and align pin 1 of the CPU socket with pin 1 of the CPU. Both are marked with a triangle. Align pin 1 of the CPU with pin 1 of the socket.

  • Page 38: Installing A Passive Cpu Heatsink

    + SE VER 2022G-URF User's Manual Installing a Passive CPU Heatsink Do not apply any thermal grease to the heatsink or the CPU die -- the required amount has already been applied. Place the heatsink directly on top of the CPU so that the heat sink screws are aligned with the mounting holes on the back plate.

  • Page 39: Connecting Cables

    Chapter 5: Advanced Serverboard Setup Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed in preconfi...

  • Page 40: I/O Ports

    + SE VER 2022G-URF User's Manual Figure 5-1. Front Control Panel Header Pins (JF1) Ground x (key) x (key) Power LED HDD LED NIC1 NIC2 OH/Fan Fail LED Power Fail LED Ground Reset Ground Power I/O Ports The I/O ports are color coded in conformance with the PC 99 specifi cation. See Figure 5-2 below for the colors and locations of the various I/O ports.

  • Page 41: Installing Memory

    Chapter 5: Advanced Serverboard Setup Installing Memory CAUTION! Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The H8DGU-F supports up to 256GB of DDR3-1333/1066/800MHz registered ECC SDRAM or 64 GB of DDR3-1333/1066/800 MHz unbuffered ECC/non-ECC SDRAM in 16 DIMM slots.

  • Page 42: Dimm Module Population Confi Guration

    + SE VER 2022G-URF User's Manual Memory Population for Optimal Performance -For a Motherboard with One CPU (CPU1) Installed # DIMMS Branch 0 Branch 1 Branch 2 Branch 3 2 DIMMs CPU1 P1-1A P1-2A 4 DIMMs CPU1 P1-1A P1-2A P1-3A P1-4A 8 DIMMs CPU1...

  • Page 43: Adding Pci Expansion Cards

    Chapter 5: Advanced Serverboard Setup Possible System Memory Allocation & Availability System Device Size Physical Memory Available (4 GB Total System Memory) Firmware Hub fl ash memory (System BIOS) 1 MB 3.99 GB Local APIC 4 KB 3.99 GB Area Reserved for the chipset 2 MB 3.99 GB I/O APIC (4 Kbytes)

  • Page 44: Serverboard Details

    + SE VER 2022G-URF User's Manual Serverboard Details Figure 5-4. SUPER H8DGU-F Layout (not drawn to scale) COM1 JPL1 CPU2 Winbond BATTERY CPU1 JBT1 SR5670 SP5100 JWF1 SATA0 SATA2 SATA4 JOH1 FAN3 SATA1 SATA3 SATA5 Notes: Jumpers not indicated are for test purposes only. When LE1 LED is on, the onboard power connection is on.

  • Page 45: H8Dgu(-F) Quick Reference

    Chapter 5: Advanced Serverboard Setup H8DGU(-F) Quick Reference Jumper Description Default Setting JBT1 CMOS Clear (See Section 2-7) JI2C1/JI2C2 I2C to PCI-E Slot Enable/Disable Both Closed (Enabled) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1 LAN 1/2 Enable/Disable Pins 1-2 (Enabled) Watch Dog Pins 1-2 (Reset) Description...

  • Page 46: Connector Defi Nitions

    + SE VER 2022G-URF User's Manual Connector Defi nitions ATX Power 24-pin Connector Pin Defi nitions Pin# Defi nition Pin # Defi nition Power Connectors +3.3V +3.3V A 24-pin main power supply connector(JPW1) -12V +3.3V and three 8-pin CPU PWR connectors (JPW2/JPW3/JPW4) on the motherboard.
  • Page 47 Chapter 5: Advanced Serverboard Setup Overheat/Fan Fail LED (OH) OH/Fan Fail LED Pin Defi nitions OH/Fan Fail Connect an LED to the OH connection on (JF1) LED Status pins 7 and 8 of JF1 to provide advanced Pin# Defi nition State Indication warning of chassis overheating or fan...
  • Page 48 + SE VER 2022G-URF User's Manual Universal Serial Bus Ports Universal Serial Bus Ports Pin Defi nitions (USB0/1, USB6) Two Universal Serial Bus ports (USB 2.0) are USB0 USB1 located beside the Keyboard and Mouse PS2 Pin # Defi nition Pin # Defi...
  • Page 49 Chapter 5: Advanced Serverboard Setup T-SGPIO SGPIO Header Pin Defi nitions (T-SGPIO1/T-SGPIO2) The T-SGPIO1/ T-SGPIO2 (Serial General Pin# Defi nition Pin# Defi nition Purpose Input/Output) headers provide a bus Data In between the SATA controller and the backpane Ground Data Out to provide SATA enclosure management Load Ground...
  • Page 50 + SE VER 2022G-URF User's Manual Chassis Intrusion Chassis Intrusion Pin Defi nitions A Chassis Intrusion header is located at JL1. (JL1) Attach the appropriate cable to inform you of Pin# Defi nition a chassis intrusion. Battery voltage Intrusion signal Overheat LED Overheat LED Pin Defi...
  • Page 51 Chapter 5: Advanced Serverboard Setup Unit Identifi er Button UID Button Pin Defi nitions In addition to the UID (Unit Identifi er) button Pin# Defi nition on the rear I/O panel, there is another UID Ground button located on the control panel. When Ground you push either UID button, both Rear Button In...

  • Page 52: Jumper Settings

    + SE VER 2022G-URF User's Manual Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the motherboard, Jumper jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function Setting of the connector.
  • Page 53 Chapter 5: Advanced Serverboard Setup I2C to PCI-Express Slot I2C to PCI-Express Slot Jumper Settings C1/JI C2 allows you to enable the I C bus (JI2C1/JI2C2) to communicate with the PCI-Express slot. Jumper Setting Defi nition For the jumpers to work properly, please set Closed Enabled both jumpers to the same setting.

  • Page 54: 5-10 Onboard Indicators

    + SE VER 2022G-URF User's Manual 5-10 Onboard Indicators LAN LED (Connection Speed Indicator) LAN1/LAN2 LEDs LED Color Defi nition The Ethernet ports (located beside the VGA 10 MHz port) have two LEDs. On each Gb LAN port, Green 100 MHz one LED blinks to indicate activity while the Amber 1 GHz...

  • Page 55: 5-11 Sata Drive Connections

    Chapter 5: Advanced Serverboard Setup 5-11 SATA Drive Connections SATA Ports SATA Ports Pin Defi nitions (SATA0-SATA3) There are no jumpers to confi gure the SATA Pin # Defi nition Pin # Defi nition ports, which are designated SATA0 through Ground SATA5.

  • Page 56: 5-12 Enabling Sata Raid

    + SE VER 2022G-URF User's Manual 5-12 Enabling SATA RAID Now that the hardware is set up, you must install the operating system and the SATA RAID drivers, if you wish to use RAID with your SATA drives. The installation procedure differs depending on whether you wish to have the operating system installed on a RAID array or on a separate non-RAID drive.

  • Page 57: Enabling Sata Raid In The Bios

    Chapter 5: Advanced Serverboard Setup Note: You need to have an external USB fl oppy when building the driver diskette. Window's Vista, Windows 2008 or later Windows OS systems can use a USB stick instead of a fl oppy. Enabling SATA RAID in the BIOS Before installing the Windows Operating System, you must change some settings in BIOS.

  • Page 58: Using The Adaptec Raid Utility

    + SE VER 2022G-URF User's Manual After exiting the BIOS Setup Utility, the system will reboot. When prompted during the startup, press the <CTRL+A> key when prompted to run the Dot- Hill RAID Utility program (see Figure 5-6). Figure 5-6.Adaptec RAID Utility Program Screen Using the Adaptec RAID Utility The Adaptec®...

  • Page 59: 5-13 Installing Drivers

    Chapter 5: Advanced Serverboard Setup Highlight the fi rst "Adaptec RAID" driver shown and press the <Enter> key to install it. Press <Enter> again to continue with the Windows setup. 5-13 Installing Drivers The CD that came bundled with the system contains drivers, some of which must be installed, such as the chipset driver.

  • Page 60: Supero Doctor Iii

    VER 2022G-URF User's Manual Supero Doctor III The Supero Doctor III program is a Web base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The Supero Doctor III program included on the CD-ROM that came with your motherboard allows you to monitor the environment and operations of your system.
  • Page 61 Chapter 5: Advanced Serverboard Setup Figure 5-9. Supero Doctor III Interface Display Screen (Remote Control) Note: Super Doctor III Software Revision 1.0 can be downloaded from our Web Site at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download the Super Doctor III User's Guide at: <http://www.supermicro.com/ PRODUCT/Manuals/SDIII/UserGuide.pdf>.
  • Page 62 + SE VER 2022G-URF User's Manual Notes 5-28...

  • Page 63: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC825TQ-R720UB chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.

  • Page 64: Control Panel

    A+ SERVER 2022G-URF User's Manual Figure 6-1. Front and Rear Chassis Views 3.5" Drive Bays (2) USB Ports (2) COM Port Slim DVD-ROM Drive Control Panel SAS/SATA Drives (8) System Reset Main Power Keyboard/Mouse Ports IPMI LAN 4 Standard Size PCI Slots...

  • Page 65: System Fans

    Chapter 6: Advanced Chassis Setup System Fans Three 8-cm hot-swap fans provide the cooling for the system. It is very important that the chassis top cover is properly installed and making a good seal in order for the cooling air to circulate properly through the chassis and cool the components. See Figure 6-2.

  • Page 66: Replacing System Fans

    A+ SERVER 2022G-URF User's Manual Replacing System Fans Removing a Fan Remove the chassis cover. Press the tabs on the sides of the fan to unlock and remove the fan and its housing. The fan's power connections will automatically detach.

  • Page 67: Sas/Sata Drive Installation

    Chapter 6: Advanced Chassis Setup SAS/SATA Drive Installation These drives are mounted in carriers to simplify their installation and removal from the chassis. The carriers also help promote proper airfl ow for the drives. For this reason, even empty carriers without hard drives installed must remain in the chassis. Note: SAS drives are supported only with a SAS UIO controller card installed.

  • Page 68: Hard Drive Backplane

    A+ SERVER 2022G-URF User's Manual Figure 6-4. Removing a SAS/SATA Drive Carrier Handle Release Button Important: All of the drive carriers must remain in the drive bays to maintain proper cooling airfl ow. Hard Drive Backplane The hard drives plug into a backplane that provides power, drive ID and bus termination.

  • Page 69: Dvd-Rom Installation

    Chapter 6: Advanced Chassis Setup DVD-ROM Installation The top cover of the chassis must be opened to gain full access to the DVD-ROM drive bay. The 2022G-URF accomodates only slim type DVD-ROM drives. Side mounting brackets are typically needed to mount a slim DVD-ROM drive in the server.

  • Page 70: Power Supply

    A+ SERVER 2022G-URF User's Manual Power Supply The A+ SERVER 2022G-URF has a 720 watt redundant power supply consisting of two power modules. Each power supply module has an auto-switching capability, which enables it to automatically sense and operate at a 100V - 240V input voltage.

  • Page 71: Chapter 7 Bios

    BIOS Introduction This chapter describes the AMI BIOS Setup Utility for the A+ SERVER 2022G-URF. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS Setup Utility setup screens.

  • Page 72: System Time/System Date

    + SE VER 2022G-URF User's Manual System Time/System Date You can edit this fi eld to change the system time and date. Highlight System Time or System Date using the <Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the <Arrow> keys to move between fi elds. The date must be entered in DAY/MM/DD/YYYY format.

  • Page 73: Processor And Clock Options

    Chapter 7: BIOS Watch Dog Function Allows system to restart when system is inactive more than 5-minutes. The options are Enabled and Disabled. Power Button Function This sets the function of the power button when you turn off the system. Options include 4-second Overide and Instant Off.

  • Page 74: Advanced Chipset Control

    + SE VER 2022G-URF User's Manual Power Cap This option can decide the highest P-state in the OS. Options include P-state 0 through P-state 4. ACPI SRAT Table This option Enables or Disables the building of the ACPI SRAT Table. CPU Down Core This option sets down core support for the CPU.
  • Page 75 Chapter 7: BIOS Bank Swizzle Mode This setting Enables or Disables the bank swizzle mode. ECC Confi guration ECC Mode This submenu affects the DRAM scrub rate based on its setting. Options include Disabled, Basic, Good, Super, Max and User. Selecting User activates the other options for user setting.
  • Page 76 + SE VER 2022G-URF User's Manual Legacy USB Support Select "Enabled" to enable the support for USB Legacy. Disable Legacy support if there are no USB devices installed in the system. "Auto" disabled Legacy support if no USB devices are connected. The options are Disabled, Enabled and Auto.
  • Page 77 Chapter 7: BIOS PIO Mode PIO (Programmable I/O) mode programs timing cycles between the IDE drive and the programmable IDE controller. As the PIO mode increases, the cycle time decreases. The options are Auto, 0, 1, 2, 3, and 4. Select Auto to allow BIOS to auto detect the PIO mode.
  • Page 78 + SE VER 2022G-URF User's Manual PCI/PnP Confi guration Clear NVRAM Select Yes to clear NVRAM during boot-up. The options are Yes and No. Plug & Play O/S Select Yes to allow the OS to confi gure Plug & Play devices. (This is not required for system boot if your system has an OS that supports Plug &...
  • Page 79 Chapter 7: BIOS SuperIO Device Confi guration Serial 1 Address This option specifi es the base I/O port address and Interrupt Request address of serial port 1. Select "Disabled" to prevent the serial port from accessing any system resources. When this option is set to Disabled, the serial port physically becomes unavailable.
  • Page 80 + SE VER 2022G-URF User's Manual Redirection After BIOS POST Options are Disable (no redirection after BIOS POST), Boot Loader (redirection during POST and during boot loader) and Always (redirection always active). Note that some OS's may not work with this set to Always. Terminal Type Selects the type of the target terminal.

  • Page 81: View Bmc System Event Log

    Chapter 7: BIOS ACPI Confi guration PS2 KB/MS Wakeup This setting allows you to Enable or Disable PS2 keyboard and mouse wakeup. ACPI Aware O/S This setting Enables or Disables ACPI support for the system's operating system. Options include Yes (enabled) or No (disabled). ACPI APIC Support Determines whether to include the ACPI APIC table pointer in the RSDT pointer list.
  • Page 82 + SE VER 2022G-URF User's Manual IP Address Source Select the source of this machine's IP address. If Static is selected, you will need to know and enter manually the IP address of this machine below. If DHCP is selected, the BIOS will search for a DHCP (Dynamic Host Confi gu- ration Protocol) server in the network it is attached to, and request the next available IP address.

  • Page 83: Security Menu

    Chapter 7: BIOS Event Log Confi guration View Event Log Pressing the Enter key will open the event log. Use the " " and " " keys to navigate through the system event log. Mark All Events as Read Selecting this and pressing the Enter key marks all events as read in the event log.

  • Page 84: Boot Menu

    + SE VER 2022G-URF User's Manual Boot Menu Boot Device Priority This feature allows you to prioritize the boot sequence from the list of available devices. A device that is in parenthesis has been disabled in the corresponding type menu. Hard Disk Drives This feature allows you to specify the boot sequence from the list of available hard disk drives.

  • Page 85: Exit Menu

    Chapter 7: BIOS Exit Menu Select the Exit tab from AMI BIOS Setup Utility screen to enter the Exit BIOS Setup screen. Save Changes and Exit When you have completed the system confi guration changes, select this option to leave BIOS Setup and reboot the computer, so the new system confi guration parameters can take effect.
  • Page 86 + SE VER 2022G-URF User's Manual Notes 7-16...

  • Page 87: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 88 + SE VER 2022G-URF User's Manual Notes...

  • Page 89: Appendix B Installing Windows

    Appendix B: Installing Windows Appendix B Installing Windows After all hardware components have been installed, you must fi rst confi gure Intel South Bridge RAID Settings before you install the Windows OS and other software drivers. To confi gure RAID settings, please refer to RAID Confi guration User Guides posted on our web site at www.supermicro.com/support/manuals.

  • Page 90: B-2 Installing The Windows Os For A Non-Raid System

    + SE VER 2022G-URF User's Manual B-2 Installing the Windows OS for a Non-RAID System Insert Microsoft's Windows XP/Windows 2003/Windows 2008/Windows Vista Setup CD in the CD drive, and the system will start booting up from CD. Continue with the OS installation. The Windows OS Setup screen will display. From the Windows OS Setup screen, press the <Enter>...

  • Page 91: Appendix C System Specifi Cations

    Appendix C: System Specifi cations Appendix C System Specifi cations Processors Dual AMD Opteron 6100 series (Socket G34 type) processors Note: You must install at least two processors for full functions to be supported. Note: Please refer to our web site for a complete listing of supported processors. Chipset One AMD SR5670 chipset and one SP5100 Southbridge chipset BIOS...
  • Page 92 + SE VER 2022G-URF User's Manual Serverboard H8DGU-F (Proprietary form factor) Dimensions: 12.28" x 13.05" (312 x 331 mm) Chassis SC825TQ-R700UBP(2U rackmount) Dimensions: (WxHxD) 16.8 x 3.5 x 25.5 in. (427 x 89 x 648 mm) Weight Gross (Bare Bone): 57 lbs. (25.9 kg.) System Cooling Three 8-cm system cooling fans System Input Requirements...
  • Page 93 Appendix C: System Specifi cations Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/- 3-3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
  • Page 94 + SE VER 2022G-URF User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...
