Graco 309322D Instructions And Parts List

Instructions - Parts List
Frame, Roller
3600 psi (24.8 MPa, 248 bar) Maximum Working Pressure
*The best operating pressure is the lowest pressure that provides an even paint
supply to the roller and typically does not exceed 300 psi (2.1 MPa, 21 bar).
Model 244271, Series C
• 9 in. (22.9 cm) length
• 7/8 in. inlet with 1/2 in. roller cover
Model 244623, Series C
• 9 in. (22.9 cm) length
• 1/8 in. inlet with 1/2 in. roller cover
IMPORTANT SAFETY INSTRUCTIONS.
Read all warnings and instructions in this manual.
Save these instructions.
WARNING
To help prevent injection injuries, follow this
procedure whenever you stop painting.
1. Engage gun trigger safety.
2. Shut off power to pump.
3. Turn prime/spray valve to PRIME position to
relieve pressure in system.
4. Disengage gun trigger safety and trigger gun
to relieve any pressure in hose.
5. Engage gun trigger safety and keep prime/spray
valve in PRIME position until you paint again.
If you suspect that the frame or hose is completely
clogged or that pressure has not been fully relieved
after following the steps above, VERY SLOWLY
loosen the tip retaining nut or hose end coupling and
relieve pressure gradually, then loosen completely.
Then clear the frame or hose obstruction.
309322D
ENG
ti1538a
