Page 1 ’02MY CELICA U (L/O 0108) SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Overview of instruments and controls Instrument panel overview ........Instrument cluster overview .
Page 2: Instrument Panel Overview
’02MY CELICA U (L/O 0108) Instrument panel overview 1. Side vents 2. Instrument cluster 3. Center vents 4. Electric moon roof switch and/or interior light 5. Glove box 6. Manual transmission gear shift lever or automatic transmission selector lever 7. Power window switches 8.
Page 3 ’02MY CELICA U (L/O 0108) 1. Instrument panel light control knob 2. Headlight and turn signal switch, and front fog light switch 3. Wiper and washer switches 4. Transmission shift switches 5. Emergency flasher switch 6. Clock 7. Auxiliary box 8.
Page 4: Instrument Cluster Overview
’02MY CELICA U (L/O 0108) Instrument cluster overview 1. Tachometer 4. Fuel gauge 7. Trip meter reset knob 2. Service reminder indicators and 5. Engine coolant temperature gauge 8. Gear position indicators indicator lights 6. Odometer and two trip meters 3.
Page 5: Indicator Symbols On The Instrument Panel
’02MY CELICA U (L/O 0108) Indicator symbols on the instrument panel Brake system warning light Anti–lock brake system warning light Driver’s seat belt reminder light Open door warning light Front passenger’s seat belt reminder light SRS warning light Automatic transmission fluid temperature warning Discharge warning light light Low engine oil pressure warning light...
Page 6 ’02MY CELICA U (L/O 0108) Turn signal indicator lights Automatic transmission indicator lights M mode indicator light Overdrive–off indicator light Cruise control indicator light : For details, see “Service reminder indicators and warning buzzers” in Section 1–5. : If this light flashes, see “Automatic transmission” in Section 1–6.
Page 7: Table Of Contents
’02MY CELICA U (L/O 0108) SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Keys and Doors Keys ............Side doors .
Page 8: Keys
Vehicles with a power door lock system— made by a Toyota dealer using the key Both side doors and back door lock and To protect things locked in the glove box number.
Page 9 ’02MY CELICA U (L/O 0108) Vehicles with a power door lock system— When both side doors and back door are unlocked simultaneously with a key, the interior light comes on for about 15 sec- onds and then fades out, even if the door is not opened.
Page 10 ’02MY CELICA U (L/O 0108) —Wireless remote control The wireless remote control system is CAUTION designed to lock or unlock both side doors and back door, or activate the Before driving, be sure that the side “PANIC” mode from a distance within doors are closed and locked, espe- approximately 1 m (3 ft.) of the vehicle.
Page 11 You can use up to 4 wireless remote con- The “PANIC” switch is used to deter ve- trol transmitters for the same vehicle. hicle theft when you witness anyone at- Contact your Toyota dealer for detailed tempting to break into or damage your information. vehicle.
Page 12 If you lose your transmitter, contact your 15 of the FCC Rules. These limits are " Toyota dealer as soon as possible to Connect the equipment into an outlet designed to provide reasonable protec- avoid the possibility of theft, or an acci-...
Page 13: 2002 My Celica_U (Om20792U)
’02MY CELICA U (L/O 0108) REPLACING TRANSMITTER BATTERY For replacement, use a CR2016 lithium battery or equivalent. CAUTION Special care should be taken that small children do not swallow the re- moved transmitter battery or compo- nents. NOTICE _ During replacing transmitter 1.
Page 14: Power Windows
After replacing battery, check that the transmitter operates properly. If the trans- mitter still does not operate properly, con- tact your Toyota dealer. 3. Put a new transmitter battery with posi- The windows can be operated with the tive (+) side up.
Page 15 ’02MY CELICA U (L/O 0108) Automatic operation open only): OPERATING PASSENGER’S If you push in the window lock switch on the instrument panel, the passenger’s win- Push the switch completely down and then WINDOW release it. The window will fully open. To dow cannot be operated.
Page 16: Back Door
’02MY CELICA U (L/O 0108) Back door CAUTION To avoid serious personal injury, you must do the following. " Always make sure the heads, hands and other parts of the bodies of all occupants are kept completely in- side the vehicle before you close the power windows.
Page 17: Hood
’02MY CELICA U (L/O 0108) Hood To open the hood: 2. In front of the vehicle, pull up the 3. Hold the hood open by inserting the auxiliary catch lever and lift support rod into the slot. 1. Pull the hood lock release lever. The hood.
Page 18: Fuel Tank Cap
’02MY CELICA U (L/O 0108) Fuel tank cap NOTICE Be sure to return the support rod to its clip before closing the hood. Clos- ing the hood with the support rod up could cause the hood to bend. This indicates that the fuel filler door 1.
Page 19: Electric Moon Roof
Make sure the cap is tightened securely. The indicator lamp goes off after driving several times. If the indicator lamp does not go off, contact your Toyota dealer as Sliding operation soon as possible. 2002 MY CELICA_U (OM20792U)
Page 20 If the moon roof cannot be operated prop- sure it is safe to do so. the switch on the “OPEN” side for more erly, have it checked by your Toyota deal- than 2 seconds. The roof will open com- pletely after tilting up.
Page 21 (See “Washing and waxing your Toyota” in Section 5.) _ Do organic substances (gasoline, kerosene, benzine strong solvents), which may toxic or cause damage.
Page 22 ’02MY CELICA U (L/O 0108) 2002 MY CELICA_U (OM20792U)
Page 23 ’02MY CELICA U (L/O 0108) SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Seats, Seat belts, Steering wheel and Mirrors Seats ............Front seats .
Page 24: Seats
" Do not put objects under the seats. injury. Consult your Toyota dealer if The objects may interfere with the you insist on modifications of this seat–lock mechanism or unexpect- kind.
Page 25 ’02MY CELICA U (L/O 0108) —Adjusting front seats 1. SEAT POSITION ADJUSTING LEVER " While adjusting the seat, do not put Hold the center of the lever and pull it your hands under the seat or near up. Then slide the seat to the desired the moving parts.
Page 26 ’02MY CELICA U (L/O 0108) —Moving passenger’s seat for rear seat entry 3. SEAT CUSHION ANGLE ADJUSTING CAUTION KNOB Turn the knob either way. " After putting back the seat, pushing the seat forward and rear- ward to make sure it is secured in place.
Page 27: Fold-Down Rear Seat
’02MY CELICA U (L/O 0108) Fold–down rear seat CAUTION When returning the seatback to the upright position, observe the follow- ing precautions in order to prevent personal injury in a collision or sud- den stop: " Make sure the seatback is securely locked by pushing forward and rear- ward on the top of the seatback and that the red mark at the button...
Page 28: Seat Belts
’02MY CELICA U (L/O 0108) Seat belts— —Seat belt precautions Toyota strongly urges that the driver and Pregnant woman. Toyota recommends the " Avoid reclining the seatbacks too passengers in the vehicle be properly re- use of a seat belt. Ask your doctor for much.
Page 29 It also may normally, immediately contact your lock if you lean forward too quickly. A Toyota dealer. Do not use the seat slow, easy motion will allow the belt to until the seat belt is fixed. It cannot extend, and you can move around freely.
Page 30 ’02MY CELICA U (L/O 0108) —Stowing the front passenger’s seat belt CAUTION " Both high–positioned lap belts and loose–fitting belts could cause seri- ous injuries due to sliding under the lap belt during a collision or other unintended result. Keep the lap belt positioned as low on hips as possible.
Page 31 Please contact your local Toyota dealer so nally intended for. that the dealer can order the proper re- quired length for the extender. Bring the heaviest coat you expect to wear for prop- er measurement and selection of length.
Page 32 " If the seat belt does not function normally, immediately contact your Toyota dealer. Do not use the seat The driver and front passenger’s seat This indicator comes on when the igni- until the seat belt is fixed. It cannot belt pretensioners are designed to be tion key is turned to the “ON”...
Page 33 Do not perform any of the following gas may be released. This gas is harm- changes without consulting your less and does not indicate that a fire is Toyota dealer. Such changes occurring. interfere with proper operation of the front seat belt pretensioners in some Once the front seat belt pretensioners cases.
Page 34: Srs Driver Airbag And Front Passenger Airbagrbag
’02MY CELICA U (L/O 0108) SRS driver airbag and front passenger airbag This front seat belt pretensioner system In the following cases, contact your Toyota The SRS (Supplemental Restraint Sys- has a service reminder indicator to inform dealer as soon as possible: tem) front airbags are designed to pro- the driver of operating problems.
Page 35 The driver or front passenger who is too close to the steering wheel or dashboard during airbag deployment can be killed or seriously injured. Toyota strongly recommends that: " The driver sit as far back as pos- This indicator comes on when the igni-...
Page 36 ’02MY CELICA U (L/O 0108) However, this threshold velocity will be considerably higher if the vehicle strikes an object, such as a parked vehicle or sign pole, which can move or deform on Hitting a curb, edge Falling into or impact, or if it is involved in an underride of pavement or jumping over a...
Page 37 ’02MY CELICA U (L/O 0108) In a severe frontal impact, the sensors A crash severe enough to inflate the air- detect deceleration and the system trig- bags may break the windshield as the gers the airbag inflators. Then a chemical vehicle buckles.
Page 38 Toyota tems. The front seat occupants can be killed or seriously injured by the strongly recommends that all in- inflating airbags if they do not wear...
Page 39 ’02MY CELICA U (L/O 0108) " On vehicles with side airbags, do not allow the child to lean against the front door or around the front door even if the child is seated in the child restraint system. It is dan- gerous if the side airbags inflate, because the impact...
Page 40 Failure to follow these instructions can result in death or serious injury. Consult your Toyota dealer about any " " Do not allow a child to stand up, Do not put objects or your pets on repairs and modifications.
Page 41 Con- " bar, kangaroo bar, etc.), snowplow, The front of the vehicle (shaded in the tact your Toyota dealer as soon as pos- winches or any other equipment to illustration) was involved in an accident sible to service the vehicle.
Page 42: Srs Side Airbags
’02MY CELICA U (L/O 0108) SRS side airbags Your vehicle is equipped with a crash sensing and diagnostic module, which will record the use of the seat belt restraint system by the driver when the SRS side airbags are inflated. CAUTION SRS side airbags inflate with consid- erable force.
Page 43 ’02MY CELICA U (L/O 0108) Collision from the rear Collision from the front Vehicle rollover The SRS side airbag system may not The SRS side airbags are not designed The SRS side airbag system consists activate if the vehicle is subjected to a to inflate if the vehicle is involved in a mainly of the following components, and collision...
Page 44 When the airbags inflate, they produce a child restraint system. Toyota belt systems. To ensure maximum fairly loud noise and release some smoke protection in an accident, the driver strongly recommends that all in- and residue along with non–toxic gas.
Page 45 " " Do not lean against the front door Do not attach a cup holder or any Consult your Toyota dealer about any when the vehicle is in use. Other- other device or object on or around repairs and modifications.
Page 46 _ Modification of the suspension sys- This side airbag system has In the following cases, contact your Toyota _ Modification of the side structure of service reminder indicator to inform the dealer as soon as possible: driver of operating problems. If either of "...
Page 47: Child Restraint
’02MY CELICA U (L/O 0108) Child restraint— —Child restraint precautions Toyota strongly urges the use of child " NOTICE Toyota strongly urges use of restraint systems children small proper child restraint system which enough to use them. Do not disconnect the battery cables conforms to the size of the child, before contacting your Toyota dealer.
Page 48 ’02MY CELICA U (L/O 0108) —Child restraint system A child restraint system for a small " A forward–facing child restraint sys- CAUTION child or baby must itself be properly should allowed restrained on the seat with the lap por- " installed on front passenger Never install a rear–facing child re-...
Page 49 ’02MY CELICA U (L/O 0108) —Types of child restraint system Child restraint systems are divided into " After installing the child restraint the following 3 types according to the system, make sure it is secured in child’s age and size. place following the manufacturer’s (A) Infant seat instructions.
Page 50 ’02MY CELICA U (L/O 0108) —Installation with 3–point type seat belt (C) Booster seat (A) INFANT SEAT INSTALLATION CAUTION An infant seat is used in rear–facing position only. " Never install a rear–facing child re- straint system on the front passen- ger seat because the force of the rapid inflation of the front passen- ger airbag can cause death or seri-...
Page 51 Contact your 1. Run the lap and shoulder belt through Toyota dealer immediately. Do not " Do not install a rear–facing child or around the infant seat following the use the child restraint seat until the restraint system on the rear seat if instructions provided by its manufactur- seat belt is fixed.
Page 52 ’02MY CELICA U (L/O 0108) 2. Fully extend the shoulder belt to put it 3. While pressing the infant seat firmly CAUTION in the lock mode. When the belt is against the seat cushion and seatback, then retracted even slightly, it cannot let the shoulder belt retract as far as Push and pull the child restraint sys- be extended.
Page 53 ’02MY CELICA U (L/O 0108) 4. To remove the infant seat, press the (B) CONVERTIBLE SEAT INSTALLATION CAUTION buckle–release button and allow the A convertible seat is used in forward– belt to retract completely. The belt will facing or rear–facing position depend- "...
Page 54 ’02MY CELICA U (L/O 0108) " On vehicles with side airbags, do not allow the child to lean against the front door or around the front door even if the child is seated in the child restraint system. It is dan- gerous if the side airbags inflate, because the impact...
Page 55 1. Run the lap and shoulder belt through 2. Fully extend the shoulder belt to put it Toyota dealer immediately. Do not or around the convertible seat following in the lock mode. When the belt is use the seat until the seat belt is...
Page 56 ’02MY CELICA U (L/O 0108) 3. While pressing convertible seat 4. To remove the convertible seat, press CAUTION firmly against the seat cushion and the buckle–release button and allow the seatback, let the shoulder belt retract belt to retract completely. The belt will Push and pull the child restraint sys- as far as it will go to hold the convert- move freely again and be ready to...
Page 57 ’02MY CELICA U (L/O 0108) CAUTION " A forward–facing child restraint sys- tem should be allowed to be put on the front passenger seat only when it is unavoidable. Always move the seat as far back as possible, be- cause the force of the deploying front passenger airbag could cause death or serious injury to the child.
Page 58 Always make sure the shoulder belt child from injury. Contact your Toyota dealer immediately. Do not is positioned across the center of child’s shoulder. The belt should be use the child restraint seat until the kept away from child’s neck, but seat belt is fixed.
Page 59 ’02MY CELICA U (L/O 0108) —Using a top strap Symbol Front of vehicle Anchor brackets 2. To remove the child restraint system, Follow the procedure below for a child Use the anchor bracket on the rear of the press the buckle–release button and al- restraint system that requires the use seat back to attach the top strap.
Page 60 ’02MY CELICA U (L/O 0108) 2. Fix the child restraint system with the seat belt. Latch the hook onto the exposed an- chor bracket and tighten the top strap. For instructions to install the child re- straint system, see “Child restraint” in this section.
Page 61: Tilt Steering Wheel
’02MY CELICA U (L/O 0108) Tilt steering wheel Outside rear view mirrors— Slide the back–plate of the flap under the To change the steering wheel angle, Adjust the mirror so that you can see hold the steering wheel, push the lock the side of your vehicle in the mirror.
Page 62: Anti-Glare Inside Rear View Mirroror
’02MY CELICA U (L/O 0108) —Power rear view mirror Anti–glare inside rear view —Folding rear view mirrors control mirror To adjust a mirror, use the switches. The rear view mirrors can be folded Adjust the mirror so that you can just backward parking restricted...
Page 63: Vanity Mirrors
’02MY CELICA U (L/O 0108) Vanity mirrors CAUTION Do not adjust the mirror while the vehicle is moving. It may cause the driver to mishandle the vehicle and an accident may occur resulting in death or serious injuries. To use the vanity mirror, swing down the sun visor and open the cover.
Page 64 ’02MY CELICA U (L/O 0108) 2002 MY CELICA_U (OM20792U)
Page 65 ’02MY CELICA U (L/O 0108) SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Lights, Wipers and Defogger Headlights and turn signals ........Emergency flashers .
Page 66: Headlights And Turn Signals
’02MY CELICA U (L/O 0108) Headlights and turn signals HEADLIGHTS Daytime running light system To turn on the following lights: Twist The headlights turn on at reduced intensi- the headlight/turn signal lever knob. ty when the parking brake is released with the engine started, even with the light Position 1—Parking, tail, license plate,...
Page 67 ’02MY CELICA U (L/O 0108) The daytime running light control sensor High–low beams—For high beams, turn TURN SIGNALS the headlights on and push the lever away is on the top of the driver’s side instru- To signal a turn, push the headlight/ from you (position 1).
Page 68: Emergency Flashers
’02MY CELICA U (L/O 0108) Emergency flashers Instrument panel light control NOTICE To prevent the battery from being dis- charged, do not leave the switch on longer than necessary when the en- gine is not running. To turn on the emergency flashers, To adjust the brightness of the instru- push the switch.
Page 69: Front Fog Lights
’02MY CELICA U (L/O 0108) Interior light Front fog lights (with moon roof) ILLUMINATED ENTRY SYSTEM (vehicles with power door lock system) With the switch in “DOOR” position, the light comes on when any of the side doors and back door is opened. After both side doors and back door are closed, the light remains on for about 15 seconds and fades out.
Page 70: Luggage Compartment Light
’02MY CELICA U (L/O 0108) Interior light Luggage compartment light (without moon roof) ILLUMINATED ENTRY SYSTEM (vehicles with power door lock system) With the switch in “DOOR” position, the light comes on when any of the side doors and back door is opened. After both side doors and back door are closed, the light remains on for about 15 seconds and fades out.
Page 71: Windshield Wipers And Washer
’02MY CELICA U (L/O 0108) Rear window wiper and Windshield wipers and washer washer With interval adjuster: The “INT TIME” band lets you adjust the wiping time inter- val when the wiper lever is in the intermit- tent position (position 1). Twist the band upward increase time between...
Page 72: Rear Window Defogger
’02MY CELICA U (L/O 0108) Rear window defogger Make sure you turn the defogger off when NOTICE the window is clear. Leaving the defogger on for a long time could cause the battery Do not operate the rear wiper if the to discharge, especially during stop–and–...
Page 73 ’02MY CELICA U (L/O 0108) SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Gauges, Meters and Service reminder indicators Fuel gauge ..........Engine coolant temperature gaugege .
Page 74: Fuel Gauge
The indicator lamp goes off after driving several times. If the indicator lamp does not go off, contact your Toyota dealer as The gauge works when the ignition The gauge indicates the engine coolant soon as possible.
Page 75: Tachometer
7100 rpm before it needle is not displayed, there may be a warms up. problem in the system. In this case, con- tact your Toyota dealer as soon as pos- sible. NOTICE _ Do not remove the thermostat in the engine cooling system as this may cause the engine to overheat.
Page 76: Odometer And Two Trip Meters
B, then back to the odometer each and contact time you push. Toyota dealer. To reset the trip meter A to zero, dis- play the meter A reading, then push Fasten driver’s and hold the knob until the meter is seat belt.
Page 77 Toyota dealer. Have your vehicle checked your Toyota dealer in the following cases: " Close both side The light does not come on even if the doors and back parking brake is applied when the igni- door.
Page 78 The light does not turn off even buzzer stops after about 4 to 8 seconds. blower, radio, etc., and drive directly to after the parking brake is released the nearest Toyota dealer or repair shop. (c) Front Passenger’s Seat Belt while the engine is running.
Page 79 It may ruin the engine. warning light system itself. but the brake system still operates con- Contact your Toyota dealer as soon as ventionally. (f) Malfunction Indicator Lamp possible to service the vehicle. When the “ABS” warning light is on (and...
Page 80 If the light does not go off, call a come on. The “ABS” warning light goes bag and front seat belt pretensioners Toyota dealer or qualified repair shop for off after a few seconds. The SRS are operating properly.
Page 81 ’02MY CELICA U (L/O 0108) SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Ignition switch, Transmission and Parking brake Ignition switch with steering lock ....... Automatic transmission .
Page 82: Ignition Switch With Steering Lock
’02MY CELICA U (L/O 0108) Ignition switch with steering lock You must push in the key to turn the key from “ACC” to the “LOCK” position. On vehicles with an automatic transmission, the selector lever must be in the “P” posi- tion before pushing the key.
Page 83: Automatic Transmission
’02MY CELICA U (L/O 0108) Automatic transmission "1ZZ–FE engine Your automatic transmission has a shift Overdrive switch lock system to minimize the possibility of Lock release button incorrect operation. This means you can To prevent misshifting only shift out of “P” position when the brake pedal is depressed (with the ignition Selector lever switch in “ON”...
Page 84 ’02MY CELICA U (L/O 0108) Vehicles with cruise control—When the 3. Release the parking brake and brake pedal. Depress the accelerator pedal cruise control is being used, even if you downshift the transmission by pushing and slowly for smooth starting. releasing overdrive switch,...
Page 85 ’02MY CELICA U (L/O 0108) (g) Parking NOTICE CAUTION 1. Bring the vehicle to a complete stop. Be careful not to over–rev the en- 2. Pull the parking brake lever up fully to Be careful when downshifting on a gine. Watch the tachometer to keep securely apply the parking brake.
Page 86 ’02MY CELICA U (L/O 0108) (i) Rocking your vehicle in stuck If your vehicle remains stuck after CAUTION rocking the vehicle several times, CAUTION consider other ways such as tow- Always keep your foot on the brake ing. pedal while stopped with the engine your vehicle becomes stuck...
Page 87 ’02MY CELICA U (L/O 0108) "2ZZ–GE engine Your automatic transmission has a shift Overdrive switch lock system to minimize the possibility of Lock release button incorrect operation. This means you can To prevent misshifting only shift out of “P” position when the brake pedal is depressed (with the ignition Selector lever switch in “ON”...
Page 88 ’02MY CELICA U (L/O 0108) When you are driving in “M” mode, over- drive switch does not activate. (For de- tails, see (d) Driving in M mode and (e) Using engine braking in this section.) Vehicles with cruise control—When the cruise control is being used, even if you downshift the transmission by pushing and releasing...
Page 89 ’02MY CELICA U (L/O 0108) Always turn the overdrive on for better When you push the transmission upshift fuel economy and quieter driving. If the switch on the rear side of the steering engine coolant temperature is low, the wheel, the transmission upshifts from “1” transmission will not shift into the over- to “2”, “3”...
Page 90 Put the selector lever in the “D” transmission downshift switch to select eration is needed when you are cruising position. Consult with your Toyota dealer the “3” position. The transmission will below the above downshifting speeds. as soon as possible.
Page 91 ’02MY CELICA U (L/O 0108) Vehicles with cruise control—When the (h) Parking NOTICE cruise control is being used, even if you 1. Bring the vehicle to a complete stop. downshift the transmission by pushing and Be careful not to over–rev the en- 2.
Page 92 ’02MY CELICA U (L/O 0108) (j) Rocking your vehicle in stuck If your vehicle remains stuck after CAUTION rocking the vehicle several times, CAUTION consider other ways such as tow- Always keep your foot on the brake ing. pedal while stopped with the engine your vehicle becomes stuck...
Page 93: Manual Transmission
’02MY CELICA U (L/O 0108) Manual transmission The shift pattern is as shown above. : Under cold engine conditions. constant–speed cruise case driving your vehicle with constant–speed cruise after decelera- 6–speed manual transmission, the buzzer tion. will sound when you shift the gear into “R”...
Page 94: Parking Brake
’02MY CELICA U (L/O 0108) Parking brake Downshift to the appropriate gear if accel- NOTICE eration is needed when you are cruising below the above downshifting speeds. Do not downshift if you are going Upshifting too soon or downshifting too faster than the maximum allowable speed for the next lower gear.
Page 95: Cruise Control
’02MY CELICA U (L/O 0108) Cruise control When parking, firmly apply the parking The cruise control allows you to cruise brake to avoid inadvertent creeping. the vehicle at a desired speed over 40 km/h (25 mph) even with your foot off To set: Pull up the lever.
Page 96 Toyota deal- the set speed. When you release it, the er at the earliest opportunity. vehicle will return to the speed set prior RESETTING TO A FASTER SPEED to the acceleration.
Page 97 If this is the case, contact your Toyota will not be applied because the cruise dealer and have your vehicle inspected. control is not cancelled. To decrease the...
Page 98 ’02MY CELICA U (L/O 0108) 2002 MY CELICA_U (OM20792U)
Page 99 ’02MY CELICA U (L/O 0108) SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Car audio system Reference ..........Using your audio system .
Page 100 Reference —Some basics This section describes some of the basic TONE AND BALANCE features on Toyota audio systems. Some For details about your system’s tone and information may not pertain to your sys- balance controls, see the description of tem.
Page 101 Do not oil any part of the player and make sure it is removed before driv- do not insert anything other than cas- ing your Toyota through an automatic sette tapes into the slot, or the tape car wash. player may be damaged.
Page 102 ’02MY CELICA U (L/O 0108) —Controls and features Details of specific buttons, controls, and features are described in the alphabetical listing that follows. 2002 MY CELICA_U (OM20792U)
Page 103 ’02MY CELICA U (L/O 0108) 1 2 3 4 5 6 (Preset buttons) If a tape side rewinds completely, the cas- (Program) sette player will stop and then play that These buttons are used to preset and Push “ ” to select the other side of a same side.
Page 104 If the malfunction is not rectified, take track and disc number currently being the knob to suit your preference. your vehicle to your Toyota dealer. played. Each time you push “CD”, the The display will show the range from system changes to the automatic changer.
Page 105 ’02MY CELICA U (L/O 0108) DISC If the audio system is off, you can turn Compact disc auto changer only— on the radio by pushing “FM1·2”. Also, Compact disc auto changer only— To randomly play the tracks in the maga- push “FM1·2”...
Page 106 ’02MY CELICA U (L/O 0108) Compact Disc Player SCAN Compact disc player There are two repeat features—You can Radio There are two scan features—you can ei- either replay a disc track or a whole com- ther scan the tracks on a specific disc or You can either scan all the frequencies on pact disc.
Page 107 TUNE (Tuning) the number of tracks you want to skip. If ST (Stereo reception) display Your Toyota has an electronic tuning radio you push the button ten times, the skip Your radio automatically changes to stereo (ETR). Turn the knob clockwise to step up feature will be turned off.
Page 108 ’02MY CELICA U (L/O 0108) Car audio system operating hints Here are some common reception prob- NOTICE lems that probably do not indicate a prob- Fading—AM broadcasts are reflected by lem with your radio: To ensure the correct audio system the upper atmosphere—especially at night.
Page 109 ’02MY CELICA U (L/O 0108) " Use high–quality cassettes. If moisture gets into your compact disc " player, you may not hear any sound Low–quality cassette tapes can cause even though your compact disc player many problems, including poor sound, appears to be working.
Page 110 ’02MY CELICA U (L/O 0108) " Your compact disc player cannot play CAUTION special shaped or low–quality compact discs such as those shown here. Do Compact disc players use an invisible not use them as the player could be laser beam which could cause hazard- damaged.
Page 111 ’02MY CELICA U (L/O 0108) SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Air conditioning system Controls ........... Air flow selector settings .
Page 112 ’02MY CELICA U (L/O 0108) Controls 1. Temperature selector 2. Air intake selector 3. Air flow selector 4. “A/C” button (on some models) 5. Fan speed selector 2002 MY CELICA_U (OM20792U)
Page 113 ’02MY CELICA U (L/O 0108) Fan speed selector 4. Floor/Windshield—Air flows mainly from the floor vents and windshield Turn the knob to adjust the fan speed—to vents. the right to increase, to the left to de- crease. Use with the air intake selector posi- tioned in Fresh.
Page 114 If this happens, take your ve- hicle to a Toyota dealer for service. Air intake selector Move the lever to select the air source. 1. Recirculate—Recirculates the air inside the vehicle.
Page 115 ’02MY CELICA U (L/O 0108) Air flow selector settings Operating tips " To cool off your Toyota after it has been parked in the hot sun, drive with the windows open for a few minutes. This vents the hot air, allowing the air conditioning to cool the interior more quickly.
Page 116 ’02MY CELICA U (L/O 0108) " If following another vehicle on a dusty Heating Air conditioning road, or driving in windy and dusty For best results, set controls to: For best results, set controls to: conditions, it is recommended that the air intake selector be temporarily set to Fan speed—Any setting except “OFF”...
Page 117 ’02MY CELICA U (L/O 0108) Instrument panel vents Defogging and defrosting The outside of the windshield Open The inside of the windshield For best results, set controls to: For best results, set controls to: Fan speed—Any setting except “OFF” Temperature—Towards WARM Fan speed—Any setting except “OFF”...
Page 118 ’02MY CELICA U (L/O 0108) You can change air flow direction by turn- ing the instrument panel vents. 2002 MY CELICA_U (OM20792U)
Page 119 ’02MY CELICA U (L/O 0108) SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Other equipment Clock ............Cigarette lighter and ashtray .
Page 120: Clock
For example, if the “:00” button is de- pressed when time between Use a Toyota genuine cigarette lighter or 1:01—1:29, the time will change to 1:00. equivalent for replacement. If the time is between 1:30—1:59, the time will change to 2:00.
Page 121: Glove Box
’02MY CELICA U (L/O 0108) Glove box Auxiliary boxes ASHTRAY To use the ashtray, pull out the lid. When finished with your cigarette, thor- oughly extinguish it in the ashtray to pre- vent other cigarette butts from catching fire. After using the ashtray, close the lid completely.
Page 122: Cup Holders
’02MY CELICA U (L/O 0108) Cup holders To use the boxes, open them as shown The cup holders are designed for hold- in the illustrations. ing cups or drink–cans securely. CAUTION CAUTION To reduce the chance of injury in Do not place anything else other than case of an accident or a sudden stop, cups or drink–cans in the cup holder, always keep the auxiliary box closed...
Page 123: Tie-Down Hooks
’02MY CELICA U (L/O 0108) Tie–down hooks Luggage cover Grocery bag hooks To secure your luggage, use the tie– When you open the back door, the lug- These hooks are designed to hang down hooks as shown above. gage cover tilt ups for easy access to things like grocery bags.
Page 124: Floor Mat
’02MY CELICA U (L/O 0108) Floor mat Use a floor mat of the correct size. CAUTION If the floor carpet and floor mat have a hole, then it is designed for use with a Make sure the floor mat is properly locking clip.
Page 125 ....... Your Toyota’s identification ........
Page 126: Break-In Periodod
To help prevent gas station mix–ups, your engine performance. to the future economy and long life of Toyota has a smaller fuel tank opening. your vehicle: Use of unleaded gasoline with an octane The special nozzle on pumps with un- "...
Page 127 Toyota, be sure that it has an octane try changing gasoline brands. If this does The WWFC consists of three categories rating no lower than 87.
Page 128: Fuel Pump Shut Off System
Operation in foreign countries Three–way catalytic converter The fuel pump shut off system stops sup- If you plan to drive your Toyota in another country... plying fuel to the engine to minimize the risk of fuel leakage when the engine stalls First, comply with the vehicle registration or an airbag inflates upon collision.
Page 129: Engine Exhaust Cautions
" vehicle in for a check–up as pos- Avoid inhaling the engine exhaust. flowing into the three–way catalytic sible. Remember, your Toyota dealer It contains carbon monoxide, which converter may cause it to overheat knows your vehicle and its three–...
Page 130: Facts About Engine Oil Consumption
’02MY CELICA U (L/O 0108) Facts about engine oil consumption FUNCTIONS OF ENGINE OIL The amount of engine oil consumed de- " Keep the back door closed while pends on the viscosity of the oil, the Engine oil has the primary functions of driving.
Page 131: Iridium-Tipped Spark Plugs
Also, the function will not be impaired. Therefore, it brake system warning light may come on. is essential that the oil level be checked regularly. Toyota recommends that the oil level be checked every time you refuel CAUTION the vehicle.
Page 132 ’02MY CELICA U (L/O 0108) When the anti–lock brake system is ac- Effective way to press the ABS brake CAUTION tivated, the following conditions may pedal: When the anti–lock brake system occur. They do not indicate a malfunc- function is in action, you may feel the "...
Page 133 ’02MY CELICA U (L/O 0108) If tires grip performance exceeds its Install all 4 tires of specified size at capability, or if hydroplaning occurs appropriate pressure: The anti–lock during high speed driving in the rain, brake system detects vehicle speeds the anti–lock brake system does not using the speed sensors for respec- provide vehicle control.
Page 134: Brake Pad Wear Limit Indicators
Contact your replaced when necessary. Have your Toyota dealer perform the bed- Toyota dealer as soon as possible to ding–down. service the vehicle.
Page 135: Luggage Stowage Precautions
This is the primary identification number ing, and impair the driver’s control low, as close to the floor as pos- for your Toyota. It is used in registering of the vehicle. In an accident they sible. the ownership of your vehicle.
Page 136 ’02MY CELICA U (L/O 0108) —Engine number The engine number is stamped on the engine block as shown. 1ZZ–FE engine The vehicle identification number (VIN) is also on the Certification Label. 2ZZ–GE engine 2002 MY CELICA_U (OM20792U)
Page 137: Theft Prevention Labels
’02MY CELICA U (L/O 0108) Theft prevention labels Suspension and chassis Types of tires (except for Canada) Your new vehicle carries theft preven- Determine what kind of tires your ve- CAUTION tion labels which are approximately 56 hicle is originally equipped with. mm (2.20 in.) by 16 mm (0.63 in.).
Page 138 ’02MY CELICA U (L/O 0108) CAUTION " Do not mix summer and all season tires on your vehicle as this can cause dangerous handling charac- teristics, resulting in loss of con- trol. " Do not use tires other than the manufacture’s designated tires, and never mix tires or wheels of the sizes different from the originals.
Page 139 ’02MY CELICA U (L/O 0108) SECTION STARTING AND DRIVING Before starting the engine ........How to start the engine .
Page 140: Before Starting The Engine
’02MY CELICA U (L/O 0108) How to start the engine— Before starting the engine (b) Starting the engine (a) Before cranking 1. Check the area around the vehicle be- 1. Apply the parking brake firmly. Before starting the engine, be sure to follow instructions “(a)
Page 141: Tips For Driving In Various Conditionsns
If they still do not work safely, pull to the side of the road and call a Toyota dealer for assistance. 2002 MY CELICA_U (OM20792U)
Page 142: Winter Driving Tips
If you are not sure about “TOYOTA Long Life Coolant” or equivalent. Driving over 140 km/h (85 mph) may which oil to use, call your Toyota deal- See Section 7–2 for details about coolant result in tire failure, loss of control er—he will be pleased to help.
Page 143: Dinghy Towing
’02MY CELICA U (L/O 0108) Dinghy towing Dinghy towing (with automatic transmission) (with manual transmission) Do not use your parking brake when there is a possibility it could freeze. When parking, put the transmission into “P” (automatic) or into first or reverse (manual) and block the rear wheels.
Page 144: Trailer Towing
Before dinghy towing, be sure to ob- safety and the safety of others, you must serve the following in order to reduce not overload your vehicle or trailer. Toyota the damage to your vehicle. warranties do not apply to damage or 1.
Page 145 ’02MY CELICA U (L/O 0108) CAUTION Total trailer weight Tongue load " total trailer weight (trailer weight plus its cargo load) must not exceed 907 kg (2000 lb.). Ex- ceeding this weight is dangerous. Tongue load 100 = 9 to 11% Total trailer weight "...
Page 146 ’02MY CELICA U (L/O 0108) " " Toyota recommends removing the trail- A safety chain must always be used " The trailer cargo load should be er hitch whenever you are not towing between the towing vehicle and the distributed so that the tongue load a trailer to reduce the possibility of trailer.
Page 147 Make sure the trailer cargo is securely move the trailer to the right. (This pro- " loaded so that it can not shift. Toyota recommends that you do not cedure is generally opposite to that " when backing without a trailer.) Also,...
Page 148 ’02MY CELICA U (L/O 0108) " " " Because stopping distance may be in- Crosswinds and rough roads will ad- Because of the added load of the trail- creased, vehicle–to–vehicle distance versely affect handling of your vehicle er, your vehicle’s engine may overheat should be increased when towing a and trailer, causing sway.
Page 149: How To Save Fuel And Make Your Vehicle Last Longer
’02MY CELICA U (L/O 0108) How to save fuel and make your vehicle last longer When restarting out after parking on a Improving fuel economy is easy—just take CAUTION slope: it easy. It will help make your vehicle last longer, too. Here are some specific tips 1.
Page 150 ’02MY CELICA U (L/O 0108) " " Avoid long engine idling. If you have Keep front wheels in proper CAUTION a long wait and you are not in traffic, alignment. Avoid hitting the curb and it is better to turn off the engine and slow down on rough roads.
Page 151: In Case Of An Emergency
’02MY CELICA U (L/O 0108) SECTION IN CASE OF AN EMERGENCY If your vehicle will not start ........If your engine stalls while drivingng .
Page 152 3. If the light is out, dim or goes out If the engine still will not start, it needs when the starter is cranked, the battery adjustment or repair. Call a Toyota dealer is discharged. You may try jump start- or qualified repair shop for assistance.
Page 153 ’02MY CELICA U (L/O 0108) (c) Jump starting To avoid serious personal injury and JUMP STARTING PROCEDURE " The gas normally produced by a damage to your vehicle which might re- 1. If the booster battery is installed in battery will explode if a flame or sult from battery explosion, acid burns, another vehicle, make sure the vehicles spark is brought near.
Page 154 ’02MY CELICA U (L/O 0108) Jumper cable Discharged battery Booster battery Positive terminal Discharged battery (“+” mark) Booster battery Jumper Positive terminal Negative terminal cable (“+” mark) (“–” mark) Connecting point 4. Make the cable connections in the or- c. Connect the clamp of the negative der a, b, c, d.
Page 155 ’02MY CELICA U (L/O 0108) If your engine stalls while If your vehicle overheats driving 5. Start your engine in the normal way. If your engine stalls while driving... your engine coolant temperature gauge indicates overheating, if you ex- After starting, run it at about 2000 rpm 1.
Page 156 5. If there are no obvious leaks, check the coolant reservoir. CAUTION If it is dry, call a Toyota dealer for assistance as soon as possible. When jacking, be sure to observe the following to reduce the possibility of...
Page 157 ’02MY CELICA U (L/O 0108) " NOTICE Stop the vehicle on a level firm Type A ground, firmly set the parking brake Do not continue driving with a de- and put the transmission in “P” flated tire. Driving even a short dis- (automatic) reverse (manual).
Page 158 CAUTION " The compact spare tire was de- signed especially for your Toyota. Compact spare tire Do not use it on any other vehicle. " The compact spare tire is designed for Do not exceed 80 km/h (50 mph) temporary emergency use only.
Page 159 ’02MY CELICA U (L/O 0108) —Required tools and spare tire 1. Get the required tools and spare tire. 1 Jack 2 Wheel nut wrench 3 Spare tire 4 Jack handle To prepare yourself for an emergency, you should familiarize yourself with the use of the jack, each of the tools and their stor- age locations.
Page 160 ’02MY CELICA U (L/O 0108) 2. Twist the jack head clockwise and pull To store the jack, put the jack base on To remove the spare tire: out the jack. the fitting place. Turn the joint until the 1. Remove the spare tire cover. jack upper side fits securely with the pro- 2.
Page 161 ’02MY CELICA U (L/O 0108) —Blocking the wheel —Removing wheel ornament 3. Remove the wheel ornament. Pry off the wheel ornament, using the beveled end of the wheel nut wrench as shown. CAUTION Do not try to pull off the ornament by hand.
Page 162 ’02MY CELICA U (L/O 0108) —Loosening wheel nuts —Positioning the jack —Raising your vehicle 4. Loosen all the wheel nuts. 5. Position the jack at the correct jack 6. After making sure that no one is in point as shown. the vehicle, raise it high enough so Always loosen the wheel nuts before rais- that the spare tire can be installed.
Page 163 ’02MY CELICA U (L/O 0108) —Changing wheels CAUTION Never get under the vehicle when the vehicle supported jack alone. 7. Remove the wheel nuts and change Before putting on wheels, remove any cor- rosion on the mounting surfaces with a tires.
Page 164 ’02MY CELICA U (L/O 0108) —Reinstalling wheel nuts —Lowering your vehicle CAUTION When lowering the vehicle, make sure all portions of your body and all oth- er persons around will not be injured the vehicle is lowered to the ground. 8.
Page 165 ’02MY CELICA U (L/O 0108) —Reinstalling wheel ornament —After changing wheels 10. Reinstall the wheel ornament. 11. Check the air pressure of the re- placed tire. 1. Put the wheel ornament into position. Adjust the air pressure to the specification Steel wheels—Align the cutout...
Page 166 If towing is necessary, we recommend (a) Towing with wheel lift type truck (a) Towing with wheel lift type truck— you to have it done by your Toyota From front—Release the parking brake. dealer or a commercial tow truck ser- —From front...
Page 167 ’02MY CELICA U (L/O 0108) —Emergency towing " Automatic transmission: (c) Towing with sling type truck Use a towing dolly under the front wheels. NOTICE Never tow a vehicle with an automatic transmission from the rear with the front wheels on the ground, as this may cause serious damage to the transmission.
Page 168 ’02MY CELICA U (L/O 0108) If towing is necessary, we recommend CAUTION CAUTION you to have it done by your Toyota dealer or a commercial tow truck ser- Use extreme caution when towing ve- If the engine is not running, the pow- vice.
Page 169 If you cannot shift automatic If you lose your keys transmission selector lever You can purchase a new key at your Toyota dealer if you can give them the key number. See the suggestion given in “Keys” in Section 1–2.
Page 170 Have the registered identification numbers of your transmitters deleted from your ve- hicle by your Toyota dealer as soon as possible to avoid the possibility of theft or an accident. Then, have the identification number of your new transmitter registered.
Page 171: Corrosion Prevention And Appearance Care
..... . . Washing and waxing your Toyota ......
Page 172 Now, it is up to you. Proper High ambient temperatures can cause mud and debris without removing them. care of your Toyota can help ensure long– corrosion to those components of the The lower edge of doors, rocker panels term corrosion prevention.
Page 173 Washing and waxing your Toyota 1. Rinse off loose dirt with a hose. Re- Check the interior of your vehicle. Wa- Washing your Toyota ter and dirt can accumulate under the move any mud or road salt from the Keep your vehicle clean by regular floor mats and could cause corrosion.
Page 174 Toyota through an automatic _ Always remove the plastic bumpers car wash. if your vehicle is re–painted and 3. Rinse thoroughly—dried...
Page 175 ’02MY CELICA U (L/O 0108) Cleaning the interior Vinyl interior Carpets CAUTION The vinyl upholstery may be easily Use a good foam–type shampoo to cleaned with a mild soap or detergent clean the carpets. " Vehicles with side airbags: and water. Begin by vacuuming thoroughly to remove Be careful not to splash water or First vacuum over the upholstery to re-...
Page 176 _ If you use cleaners or polishing _ Never use organic substances such Toyota dealer will be pleased to answer them. agents, make sure their ingredients as benzine, alcohol or gasoline or do not include the substances men- alkaline or acid solutions for clean- tioned above.
Page 177 ’02MY CELICA U (L/O 0108) SECTION VEHICLE MAINTENANCE AND CARE Maintenance requirements ........General maintenance .
Page 178 Simple instructions for how to per- or if you prefer, your Toyota dealer will be dating this warranty. See “Owner’s War- form them are presented in Section 7.
Page 179 Booklet” or “Owner’s Manual Supple- should investigate the cause or take your check the nuts for looseness. Tighten ment” for the details. vehicle to your Toyota dealer or a quali- them if necessary. fied service shop immediately. It is recom- Tire rotation...
Page 180 Battery electrolyte level nism securely in any position. For folding–down Your Toyota has a maintenance free bat- Check the lock release button of the se- rear seatbacks, check that the latches tery. You do not have to add distilled wa- lector lever for proper and smooth opera- lock securely.
Page 181 If you notice any of these clues, take your Check the level on the dipstick with the mance, sounds, and visual tip–offs that vehicle to your Toyota dealer as soon as engine turned off and the vehicle parked indicate service is needed. Some impor- possible.
Page 182: Malfunction Indicator Lamp
Contact your Toyota dealer to even the malfunction indicator lamp does service the vehicle. not come on, contact your Toyota dealer Even if the malfunction indicator lamp to prepare the vehicle for re–testing. does not come on, your vehicle may not pass the I/M test as readiness codes have not been set in the OBD system.
Page 183 ’02MY CELICA U (L/O 0108) SECTION – DO–IT–YOURSELF MAINTENANCE Introduction Engine compartment overview ....... Fuse locations .
Page 184: Engine Compartment Overview
’02MY CELICA U (L/O 0108) Engine compartment overview "1ZZ–FE engine 1. Power steering fluid reservoir 2. Engine oil level dipstick 3. Engine coolant reservoir 4. Engine oil filler cap 5. Battery 6. Brake fluid reservoir 7. Fuse blocks 8. Radiator 9.
Page 185 ’02MY CELICA U (L/O 0108) "2ZZ–GE engine 1. Power steering fluid reservoir 2. Engine oil level dipstick 3. Engine coolant reservoir 4. Engine oil filler cap 5. Battery 6. Brake fluid reservoir 7. Fuse blocks 8. Radiator 9. Electric cooling fans 10.
Page 186: Fuse Locations
’02MY CELICA U (L/O 0108) Fuse locations Spare fuses 2002 MY CELICA_U (OM20792U)
Page 187: Do-It-Yourself Service Precautions
Use eye protection whenever you warranty coverage. Read separate compartment—the engine, radiator, work under your vehicle Toyota Warranty statement for details and exhaust manifold, power steering where you may be exposed to flying suggestions. fluid reservoir spark plug or falling material, fluid spray, etc.
Page 188: Positioning The Jack
’02MY CELICA U (L/O 0108) Positioning the jack Use only spark plugs of the speci- Be extremely cautious when work- fied type. Using other types will ing on the battery. It contains poi- cause engine damage, loss of per- sonous and corrosive sulfuric acid. formance or radio noise.
Page 189: Parts And Tools
Remember all Toyota parts are de- alone. signed in metric sizes, so your tools must be metric. CAUTION Do not raise the vehicle with some- one in the vehicle.
Page 190 ’02MY CELICA U (L/O 0108) CHECKING BRAKE FLUID ADDING WASHER FLUID Parts (if level is low): Parts: SAE J1703 or FMVSS No.116 DOT 3 Water brake fluid Washer fluid containing antifreeze Tools: (for winter use) Rag or paper towel Tools: Funnel (only for adding fluid) Funnel CHECKING POWER STEERING FLUID...
Page 191 ’02MY CELICA U (L/O 0108) SECTION – DO–IT–YOURSELF MAINTENANCE Engine and Chassis Checking the engine oil level ....... . . Checking the engine coolant levelel .
Page 192: Checking The Engine Oil Level
’02MY CELICA U (L/O 0108) Checking the engine oil level ENGINE OIL SELECTION CAUTION Use API grade SJ “Energy–Conserving”, Low level Full level SL “Energy–Conserving” or ILSAC multi- Be careful not to touch the hot ex- grade engine oil. haust manifold. Recommended viscosity (SAE): If the oil level is below or only slightly above the low level, add engine oil of...
Page 193: Checking The Engine Coolant Levelel
Visually check the radiator, hoses, drain cock and water pump. If you can find no leak, have your Toyota dealer test the cap pressure and check for leaks in the cooling system. ILSAC certification mark...
Page 194: Checking The Radiator And Condenserr
We recommend to use 50% solution for If any of the above parts are extremely CAUTION your Toyota, to provide protection down to dirty or you are not sure of their condi- about –35_C (–31_F). When it is extreme- tion, take your vehicle to Toyota dealer.
Page 195: Checking Brake Fluid
’02MY CELICA U (L/O 0108) Checking brake fluid Checking power steering fluid If the level is low, add SAE J1703 or Open FMVSS No.116 DOT 3 brake fluid to the brake reservoir. If hot If cold O.K. Remove and replace the reservoir cap by O.K.
Page 196: Checking Tire Pressure
If a tire frequently needs refilling, have it The reservoir tank may be hot so be size and the vehicle capacity weight are checked by your Toyota dealer. careful not to burn yourself. given in Section 8. They are also on the The following instructions for checking tire pressure label as shown.
Page 197: Checking And Replacing Tires
REPLACING YOUR TIRES The tires on your Toyota have built–in " Be sure to reinstall the tire inflation tread wear indicators to help you know When replacing a tire, use only the valve caps.
Page 198: Rotating Tires
Do not use tires or wheels other than manufacturer’s recom- mended size. Toyota recommends all four tires, or at least both front or rear tires be re- Turning direction indicator (type A) placed as a set. See “If you have a flat tire” in Section 4 for tire change procedure.
Page 199: Installing Snow Tires And Chains
To equalize the wear and help extend WHEN SNOW TIRES CHAINS tire life, Toyota recommends that you rotate your tires according to the main- Snow tires or chains are recommended tenance schedule. (For scheduled main- when driving on snow or ice.
Page 200: Replacing Wheels
Regulations regarding the use of tire Correct replacement wheels are available versely affect vehicle handling. chains vary according to location or at your Toyota dealer. " When driving with chains installed, type of road, so always check them A wheel of a different size or type may be sure to drive carefully.
Page 201: Aluminum Wheel Precautions
1600 km (1000 miles). for a tubeless tire. " When using tire chains, be careful not to damage the aluminum wheels. " Use only the Toyota wheel nuts and wrench designed for your aluminum wheels. " When balancing your wheels, use only Toyota balance weights or equivalent and a plastic or rubber hammer.
Page 202 ’02MY CELICA U (L/O 0108) 2002 MY CELICA_U (OM20792U)
Page 203 ’02MY CELICA U (L/O 0108) SECTION – DO–IT–YOURSELF MAINTENANCE Electrical components Checking battery condition ........Battery recharging precautions .
Page 204: 02My Celica U (L/O 0108)
’02MY CELICA U (L/O 0108) Checking battery condition— —Checking battery exterior —Precautions " Ground Terminals CAUTION If electrolyte gets on your skin, cable thoroughly wash the contact area. If BATTERY PRECAUTIONS you feel pain or burning, get medi- cal attention immediately. The battery produces flammable and "...
Page 205: Battery Recharging Precautions
Charging necessary. Have Dark White battery checked NOTICE by your Toyota dealer. Never recharge the battery while the engine is running. Also, be sure all Clear or Have battery accessories are turned off. light checked by your yellow Toyota dealer.
Page 206: Checking And Replacing Fuses
’02MY CELICA U (L/O 0108) Checking and replacing fuses Good Blown Good Blown Type A Type C the headlights or other electrical components do not work, check the fuses. If any of the fuses are blown, they must be replaced. See “Fuse locations”...
Page 207: Adding Washer Fluid
Follow the If the new fuse immediately blows out, manufacturer’s directions for how much to there is a problem with the electrical sys- mix with water. tem. Have your Toyota dealer correct it as soon as possible. 2002 MY CELICA_U (OM20792U)
Page 208 — if there is a large drop of water on the (with moon roof) inside of the lens, or if there is water Interior light — pooled inside light, contact your (without moon roof) Toyota dealer. 2002 MY CELICA_U (OM20792U)
Page 209 ’02MY CELICA U (L/O 0108) —Headlights (low beam) 1. Open the hood. Bulb Light bulbs Type RIGHT SIDE HEADLIGHT—Remove the clips and take out the cover. In doing — Glove box light so, remove the washer hose from the Luggage notch on the cover.
Page 210 ’02MY CELICA U (L/O 0108) Removing clip 2. Unplug the connector. Remove the 3. Release the bulb retaining spring rubber cover. and remove the bulb along with the socket. Install a new bulb into the If the connector is tight, wiggle it. socket and return the bulb retaining spring to its original position.
Page 211 Always notch the washer hose before fastening it when installing the cover. Aiming is not necessary after replacing This prevents washer hose damage. the bulb. When aiming adjustment is nec- essary, contact your Toyota dealer. 2002 MY CELICA_U (OM20792U)
Page 212 ’02MY CELICA U (L/O 0108) 1. Open the hood. RIGHT SIDE HEADLIGHT—Remove the clips and take out the cover. In doing so, remove the washer hose from the notch on the cover. Remove and install the cover clips as shown in the following illustrations. Removing clip 2.
Page 213 If the connector is tight, wiggle it. Aiming is not necessary after replacing NOTICE the bulb. When aiming adjustment is nec- essary, contact your Toyota dealer. Always notch the washer hose before fastening it when installing the cover. This prevents washer hose damage.
Page 214 If either the left or right front fog or RIGHT SIDE PARKING LIGHT—Remove front side marker lights burns out, con- and install the clips as shown in the tact your Toyota dealer. following illustrations. NOTICE NOTICE Do not try to replace the front fog or...
Page 215 ’02MY CELICA U (L/O 0108) —Front turn signal lights Removing clip Installing clip 2002 MY CELICA_U (OM20792U)
Page 216 ’02MY CELICA U (L/O 0108) RIGHT SIDE FRONT TURN SIGNAL LIGHT—Remove and install the clips as shown in the following illustrations. NOTICE Always notch the washer hose before fastening it when installing the cover. This prevents washer hose damage. Removing clip Installing clip 2002 MY CELICA_U (OM20792U)
Page 217 ’02MY CELICA U (L/O 0108) —Rear turn signal, stop/tail, —License plate lights and back–up lights Remove the cover. a: Stop/tail light Use a Phillips–head screwdriver. b: Back–up light c: Rear turn signal light Remove the cover. 2002 MY CELICA_U (OM20792U)
Page 218 ’02MY CELICA U (L/O 0108) 2002 MY CELICA_U (OM20792U)
Page 219 ’02MY CELICA U (L/O 0108) SECTION SPECIFICATIONS Dimensions and weight ........Engine .
Page 220: Dimensions And Weight
’02MY CELICA U (L/O 0108) Dimensions and weight Engine Fuel Overall length mm (in.) 4330 (170.5) Model: Fuel type: 1ZZ–FE and 2ZZ–GE 1ZZ–FE engine Overall width mm (in.) 1735 (68.3) Type: Unleaded gasoline, Octane Rating 87 Overall height mm (in.) 1305 (51.8) 4 cylinder in line, 4 cycle, gasoline...
Page 221: Service Specifications
5.8 (6.1, 5.1) With filter 4.4 (4.8, 4.0) Without filter 4.2 (4.6, 3.8) Spark plug type: Coolant type: Oil grade: 1ZZ–FE engine “TOYOTA Long Life Coolant” or equiva- API grade SJ “Energy–Conserving”, SL DENSO SK16R11 lent “Energy–Conserving” ILSAC multi- IFR5A11 With ethylene–glycol type coolant for a...
Page 222 Lining wear limit, mm (in.): Notice: Using automatic transmission 2.3 (2.4 2.0) 1.0 (0.04) fluid other than Toyota Genuine ATF Oil type: Parking brake adjustment when pulled with Type T–IV may cause deterioration in Gear oil API GL–4 or GL–5...
Page 223: Tires
’02MY CELICA U (L/O 0108) Tires Tire size and pressure: Except spare tire Tire pressure Tire ressure kPa (kgf/cm or bar, psi) Model Model Tire size Tire size Wheel size Wheel size Front Rear 195/60R15 88H 210 (2.1, 29) 210 (2.1, 29) 6 1/2JJ 1ZZ–FE engine 1ZZ–FE engine...
Page 224: Fuses
’02MY CELICA U (L/O 0108) Fuses Engine compartment Engine compartment Instrument panel Fuses (type A) 7. IG2 15 A: Starting system, multiport 13. EFI 15 A: Multiport fuel injection sys- fuel injection system/sequential multi- tem/sequential multiport fuel injection 1. HEAD LH LWR 10 A: Left–hand head- port fuel injection system system, “EFI NO.1”...
Page 225 ’02MY CELICA U (L/O 0108) 20. HEAD RH UPR 10 Right–hand 32. RADIO 15 A: Car audio system 43. a. PANEL1 7.5 A: Car audio system, headlight (high beam), daytime running cigarette lighter, glove box light 33. WIPER 25 A: Windshield wipers and light system b.
Page 226 ’02MY CELICA U (L/O 0108) Fuses (type D) 51. ALT 120 A: Cooling system, electric cooling fan, starting system, rear win- dow defogger, tail lights, “ABS NO.1”, “ABS NO.2”, “HTR”, “FR P/W”, “FL P/W”, “DOOR”, “OBD”, “STOP”, “S/ ROOF”, “MIR HTR”, “FR FOG” and “AM1”...
Page 227 ’02MY CELICA U (L/O 0108) SECTION REPORTING SAFETY DEFECTS FOR U.S. OWNERS AND UNIFORM TIRE QUALITY GRADING Reporting safety defects for U.S. ownersrs ..... Uniform tire quality grading .
Page 228 Department Transportation, quality grading. addition to notifying Toyota Motor Washington, D.C. 20590. You can Your Toyota dealer will help answer any Sales, U.S.A., Inc. also obtain other information about questions you may have as you read this (Toll–free: 1–800–331–4331). motor vehicle safety from the Hot- information.
Page 229 ’02MY CELICA U (L/O 0108) Treadwear—The treadwear grade Temperature A, B, C—The temperature comparative rating based on the wear rate grades are A (the highest), B, and C, of the tire when tested under controlled representing the tire’s resistance to the conditions on a specified government test generation of heat and its ability to dissi- course.
Page 230 ’02MY CELICA U (L/O 0108) 2002 MY CELICA_U (OM20792U)
Page 231 ’02MY CELICA U (L/O 0108) U−5 Quick index " If a service reminder indicator or warning buzzer comes on .." If your vehicle will not start ........"...

This manual is also suitable for:

2002 celica

Toyota Celica 2002 Operating Manual

1 1 Section -

1 2 Section -

1 3 Section -

1 4 Section -

1 5 Section -

1 6 Section -

1 9 Section -

2 Section

3 Section

7 1 Section -

7 2 Section -

7 3 Section -

Quick Links

Chapters

Related Manuals for Toyota Celica 2002

Summary of Contents for Toyota Celica 2002

This manual is also suitable for:

Table of Contents
