Table of Contents
loading

Summary of Contents for Alpine F1 Status DAI-C990

  • Page 1 Phone 1-800-ALPINE-1 (1-800-257-4631) ALPINE ELECTRONICS OF CANADA, INC. 7300 Warden Ave., Suite 203, Markham, Ontario L3R 9Z6, Canada Phone 1-800-ALPINE-1 (1-800-257-4631) ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 6-8 Fiveways Boulevarde Keysborough, Victoria 3173, Australia Phone 03-9769-0000 ALPINE ELECTRONICS GmbH DAI-C990 DAI-C990 Frankfurter Ring 117, 80807 München,...
  • Page 2 FOR CAR USE ONLY/NUR FÜR AUTOMOBIL GEBRAUCH/POUR APPLICATION AUTOMOBILE UNIQUEMENT/ PARA USO EN AUTOMÓVILES/SOLO PER L'UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK DAI-C990 D/A CONVERTER • OWNER’S MANUAL Please read before using this equipment. • BEDIENUNGSANLEITUNG Lesen Sie diese Bedienungsanleitung bitte vor Gebrauch des Gerätes.
  • Page 3: Table Of Contents

    Contents WARNING WARNING ..........................2 CAUTION ..........................3 PRECAUTIONS ........................4 Control and Connection Descriptions ......6 Accessories ............... 8 Installation ................. 9 Connection ..............10 Example of system expansion ........11 Information In case of difficulty ........................12 Specifications .......................... 13 LIMITED WARRANTY...
  • Page 4: Warning

    WARNING DO NOT SPLICE INTO ELECTRICAL WARNING CABLES. Never cut away cable insulation to supply This symbol means important power to other equipment. Doing so will instructions. exceed the current carrying capacity of the Failure to heed them can result in wire and result in fire or electric shock.
  • Page 5: Caution

    HALT USE IMMEDIATELY IF A PROBLEM APPEARS. Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Centre for repairing.
  • Page 6: Precautions

    PRECAUTIONS • Be sure to disconnect the cable from the (–) battery post before installing your DAI-C990. This will reduce any chance of damage to the unit in case of a short-circuit. • Be sure to connect the color coded leads according to the diagram. Incorrect connections may cause the unit to malfunction or damage to the vehicle’s...
  • Page 7: Serial Number

    • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors. Contact them for further information.
  • Page 8: Control And Connection Descriptions

    Control and Connection Descriptions 1 Crossover Mode Selector Switch (Front HPF) Set to HP to turn on the HPF crossover. The Front output becomes mid- range to highs only. To use the Front output for full-range, set to OFF. 2 Crossover Frequency Adjustment Control (Front HPF) Use with the crossover mode selector switch (Front HPF) set to HP.
  • Page 9 8 9 p 7 Fuse (7.5A) 8 Battery terminal Connect this terminal directly to the positive (+) terminal of the vehicle’s battery. Do not connect this terminal to a switched voltage source (such as Ignition). 9 Remote OUT terminal Use this output to control an amplifier or other peripheral device. p Ground terminal Connect securely to a metal part of the vehicle’s body using the ground cord.
  • Page 10: Accessories

    (When connecting to the main unit, attach the core at a location of approx. 4 cm from the terminal end.) • For connection of DAI-C990, the battery power cable (sold separately), ground cable (sold separately), remote out cable (sold separately), are necessary.
  • Page 11: Installation

    Installation 1. Decide on the installation location. • The trunk, etc., is the best place. 2. Mark the positions of the mounting screws at the chosen location. 3. Drill 3 mm (1/8”) holes or smaller. WARNING: When making holes, be careful not to damage pipes, tanks, electric wires, etc.
  • Page 12: Connection

    Battery power cable (sold separately) • When connecting the Battery power cable direct to the battery terminal, a fuse at the battery should be used to protect your equipment. Please consult with your Alpine dealer for the proper fuse value.
  • Page 13: Example Of System Expansion

    Example of system expansion • DAI-C990 + DVI-9990R/DVI-9990E Head Unit + TMI-M990 Monitor + Ai-NET compatible Changer Connected Set to SYSTEM System switch 1:SYSTEM 2:STANDALONE DVI-9990R/DVI-9990E To IONBUS IONBUS port TMI-M990 compatible head IONBUS cable IONBUS unit (sold compatible separately)
  • Page 14: Information

    If you encounter a problem, please review the items in the following checklist. This guide will help you isolate the problem if the unit is at fault. Otherwise, make sure the rest of your system is properly connected or consult your authorized Alpine dealer. Set does not operate.
  • Page 15: Specifications

    Specifications Frequency response (DVD-Audio): 20 Hz to 20 kHz (20 Hz~96 kHz) (when HPF is off for front/rear channel) S/N ratio: 110 dB (IHF-A) Channel separation: 90 dB Front/Rear (when HPF is on), Subwoofer crossover: 30 to 400 Hz (ANALOG-VR) Fixed Slope 12dB/OCT.
