Status Bar Indicators

Indicator Function
1
Muted
10
The signal-strength icon indicates the
strength of the signal and can assist the
user in determining if the handset is moving
out of range.
If voicemail is available the voicemail icon
will appear when a new voicemail message
is received.
The battery icon indicates the amount of
charge remaining in the Battery Pack. When
only one level remains, the Battery Pack
needs to be charged.
The speakerphone icon displays when the
speakerphone is active.
The line indicators are associated with
telephone line status and access.
Up and down arrows are displayed when a
menu has additional options above or
below.
Left or right arrows are displayed during
editing when the cursor may be moved left
or right.
The muted indicator displays after the
softkey has been pressed during a call. It
indicates that the microphone is not
transmitting sound. Press the
again to unmute the microphone.
Mute
Mute
softkey
