American Standard Green Tea 3572.328 Specification Sheet

Green Tea™ 5-1/2' x 36" Premium air BaTh
❏ 3572.328 Green Tea™ 5-1/2' x 36" Premium air Bath
• Smooth Air™ Massage System with perfectly smooth
air jets throughout tub bottom
• Programmable automatic purge with timer
• 1.0 hp variable speed blower with built-in heater
• Everclean System
®
• Acrylic with fiberglass reinforcement
• Pre-leveled tub bottom
• Form-fitted backrest and raised neck support
• Dual, molded-in armrests
• Can be under-mount installed
• Drain and overflow in Chrome included
❏
3572.328.K2 Premium air Bath
with Chromatherapy
Same as 3572.328 but also includes:
• Two digitally controlled lights
• Electronic control with color selector and
color cycle function
nominal Dimensions:
66" x 36" x 22"
(1676 x 914 x 559mm)
Compliance Certifications -
meets or exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
American Standard whirlpools and air baths with
EverClean incorporate a patented silver-ion additive
®
right into the circulation piping to protect the pipes
from mold, mildew, algae and fungus that could cause
deterioration or staining of the pipes.
SEE REVERSE FOR PRODUCT DIMENSIONS
AND SPECIFICATIONS
© 2008 AS America Inc.
Green Tea™ 5-1/2' x 36"
Premium air BaTh
To Be Specified - required:
❏ Color
❏ Bath Filler: (specify finish)
❏ Bath Drain: (included in Chrome)
To Be Specified - Optional:
❏ Universal Tile Bead Kit: 751755-100
❏ Drain Trim Kit: 1585.200 (specify finish)
❏ Air Blower Remote Mounting Kit: 754025-0071A
For color/finish availability and other faucet choices, please
see the Product Selector and Pricing Guide.
H13
hiGh GLOSS
Rev. 2/08
