ASSEMBLY

Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the
included tools, assembly requires a Phillips screwdriver
wrench , and a rubber mallet
As you assemble the elliptical exerciser, use the drawings below to identify small parts. The number in parentheses
below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number
following the parentheses is the quantity needed for assembly. Note: Some small parts may have been pre-
assembled. If a part is not in the hardware kit, check to see if it has been preassembled.
M8 Split
Washer (90)-3
M4 x 16mm M6 x 10mm Button
Round Head
Screw (101)–14
Hub Screw (87)-8
M8 x 71mm Button
Bolt (80)-1
M8 x 23mm Shoulder
M8 x 16mm
Washer (110)-2
M8 Nylon Locknut
Screw (104)-8
M8 x 23mm Button
Screw (84)-4
M10 x 127mm Button Screw (83)-2
Screw (115)-2
, an adjustable
.
M8 Washer
(88)-4
22mm x 16mm
(78)-3
Wave Washer
(111)-2
M10 x 82mm Button
Screw (82)-2
M10 x 58mm Shoulder
Bolt (71)-2
5
M8 x 23mm x
1mm Washer
(112)-2
23mm x 19mm
Wave Washer
(97)-2
M8 x 38mm Button
Screw (4)-6
