Replacing the Sliding Rear
Convenience Tray
The floor track assembly must be installed first for the
sliding rear convenience tray to stay locked into
place. See "Replacing the Floor Track Assembly" listed
previously for more information.
1. Pick up the tray by the handle and support the tray
from the bottom with your other hand.
2. Place the tray onto the floor track assembly. Make
sure that the two front axles are placed over the
hooks on the rear of the floor track assembly. There
are four axles on the bottom of the tray, two in
front and two in back.
Make sure the rollers on the bottom of the tray are
located in the tracks of the floor track assembly.
3. Roll the tray forward into the vehicle until you hear
a click.
4. Press the release lever and pull the tray onto the
tailgate. Connect the hook to the tethered ring
located on each side of the sliding rear
convenience tray.
5. Push the release lever and roll the tray back into
the vehicle.
You will hear a click when the tray is locked into
position.
