Type No. L24C0F080
Model. W240S
Multi Function 2D/3D Wide Monitor
User's Guide

Advertisement

Table of Contents
loading

Related Manuals for Hyundai W240S

Summary of Contents for Hyundai W240S

  • Page 1 NEXT Type No. L24C0F080 Model. W240S Multi Function 2D/3D Wide Monitor User’s Guide...
  • Page 2 U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Declaration Of Conformity

    DECLARATION OF CONFORMITY HYUNDAI IT CORP. Ami-ri Bubal-Eub Ichon-Si Kyungki-Do 467-860 KOREA declare under our sole responsibility that the product: Kind of equipment LCD MONITOR Type-Designation L24C0F080 to which this declaration relates is in conformity with the following standard(s) or other normative document(s)

  • Page 4: Table Of Contents

    W240S Multi Function 2D/3D Wide Monitor Contents 1. Introduction ........1/29 2. Safety Information ......1/29 3. Cautions for Health &Safety ..3/29 4. Handling InstructionsHow to use ..5/29 5. 3D Monitor SettingGuide....6/29 6. Q&A for 3D Mod......6/29 7. 3D Mode Specification ....8/29 8.

  • Page 5: Introduction

    Multi Function 2D/3D Wide Monitor 1. Introduction This manual contains instructions for installing and operating HYUNDAI IT CORP. W240S. HYUNDAI IT CORP. W240S is a highly ergonomic color display unit. • 24” viewable WUXGA LCD • High quality screen re-scaling capability •...
  • Page 6 W240S Multi Function 2D/3D Wide Monitor Avoid operating the monitor in extreme heat, humidity or areas affected by dust. Temperature : 5~40°C Humidity : 30~80RH Be sure to turn the monitor off before plugging the power cord into the socket. Make sure that the power cord and the other cords are securely and rightly connected.

  • Page 7: Cautions For Health &Safety

    W240S Multi Function 2D/3D Wide Monitor Cleaning and Maintenance • To avoid to risk of electric shock, do not disassemble the Cabinet of display Unit. The Cabinet is not user-serviceable. Remember to unplug the display unit from the power outlet before cleaning.
  • Page 8 W240S Multi Function 2D/3D Wide Monitor • If you have any problems with your body such as convulsion, paralysis, disorientation, fainting and confusion, etc. while using it, stop using it and go to your doctor. • If you feel any problems as follows, stop using it and take a rest.

  • Page 9: Handling Instructionshow To Use

    W240S Multi Function 2D/3D Wide Monitor - Fire / Accident Prevention • Do not handle the LCD monitor with bare hands. It can cause you to get injured. • Do not place a heavy object over LCD monitor, bend nor give it a shock. It can break down or get damaged.

  • Page 10: D Monitor Settingguide

    W240S Multi Function 2D/3D Wide Monitor 5. 3D Monitor Setting • Optimal resolution for 3D viewing is 1920*1200/60Hz. If you run it on different resolutions, its 3D effects can decrease. Guide • Use signal input source at RGB under PC mode or DVI mode.
  • Page 11 W240S Multi Function 2D/3D Wide Monitor - 1m from the monitor screen. - If you exceed 75° out of the left/right visual angle or 10° out of the top/bottom visual angle while viewing 3D images, you cannot enjoy 3D images properly. So keep the visual angle as provided above.

  • Page 12: D Mode Specification

    W240S Multi Function 2D/3D Wide Monitor 3D images create Ghost effect - It can happen slightly depending on 3D contents. - It is due to the different stereoscopic imaging information of the camera when they are manufactured.(Use 3D contents suitable to this product ) The monitor screen reflects my face.

  • Page 13: Installing The Monitor

    W240S Multi Function 2D/3D Wide Monitor 8. Installing the The following items should be found in the packaging. monitor - Packing List Power Cord Japan Signal Cable America/Canada Europe DVI Cable South Africa Australia USB Cable Audio Cable (Option) HDMI Cable...
  • Page 14 W240S Multi Function 2D/3D Wide Monitor - Selecting a suitable • Place the monitor at least 30cm from other electrical or heat-emitting equipment and allow at least 10cm on each side for ventilation. location • Place the monitor in a position where no light shines directly onto or is reflected on the screen.
  • Page 15 W240S Multi Function 2D/3D Wide Monitor Turn on the power to the computer. The picture will appear within about 10 • Way to Connect seconds. Adjust the picture to obtain optimum picture quality. See section Adjusting the picture in this guide for more information.
  • Page 16 W240S Multi Function 2D/3D Wide Monitor • Audio system This monitor has an audio system including two micro loudspeakers. Each of two micro loudspeakers has an 3W(max.) output power. This system also supports a headphone output jack. This system has been tuned to get a best tone quality which an audio input level is under 500mv rms.
  • Page 17 W240S Multi Function 2D/3D Wide Monitor • USB hub(Option) The USB hub(Bus-powerd mode) have 1 upstream port and 2 downstream ports. The upstream port can be connected to the root hub of host PC or other downstream port self-power hub. Two(2) downstream ports allow to connect another USB device such as USB mouse, joystick, printer etc.
  • Page 18 W240S Multi Function 2D/3D Wide Monitor - Setting the refresh rate Follow the instructions below to set your refresh rate in Windows 98/ME/XP/2000/VISTA. Go to the configuration window(Start-Settings-Configuration window). Double click on the ‘Display’ icon. Click on the ‘Settings’ tab.
  • Page 19 W240S Multi Function 2D/3D Wide Monitor • Preset Timing Table If the signal from the system doesn't equal to the preset timing mode, adjust the mode with reference to the user guide of videocard because the screen may not be displayed.
  • Page 20 - Watching the DVD/HDTV • Connect component cable (Y, Pb, Pr) between output terminal (Y, Pb, Pr) of DVD player and input terminal (Y, Pb, Pr) of DVD on the rear of W240S. • Connecting (Connect cable and terminal in the matching color) component cable •...
  • Page 21 W240S Multi Function 2D/3D Wide Monitor - User’s Environment Recommended Ergonomic User’s Environment Viewing angle of the monitor should be between 0 ~ 30 degree. • Supports Pivot. The screen can be vertically rotated by 90 degrees. This reduces the inconvenience of...
  • Page 22 W240S Multi Function 2D/3D Wide Monitor • Kensington Security • This display unit supports a Kensington-type security device to secure your (Locking) Slot monitor. Kensington lock is not included. • To purchase and install the Kensington locking device, please refer to the following contact information.

  • Page 23: Adjusting The Picture

    W240S Multi Function 2D/3D Wide Monitor 9. Adjusting the picture You can adjust the screen display by using the buttons located below the screen. The second Menu from the OSD can't be chosen in digital-mode. 19/29...
  • Page 24 W240S Multi Function 2D/3D Wide Monitor To make adjustments in the On Screen Display, follow these steps: - Using the On Screen Display Push the MENU button to call the OSD to the screen. Push the button to choose the item you want to adjust. The selected item is highlighted.
  • Page 25 W240S Multi Function 2D/3D Wide Monitor - OSD Adjustments PC MODE • Picture BRIGHTNESS To adjust the brightness of the screen. CONTRAST To adjust the contrast of the screen. H.POSITION To move image left and right. V.POSITION To move image up and down CLOCK To adjust the horizontal size of the entire screen image.
  • Page 26 W240S Multi Function 2D/3D Wide Monitor PC ANALOG, DVI • Color STANDARD For general Color tone. REDISH For Redish color with warm tone. BLUISH For Bluish color with cool tone. USER For adjusting degree of RGB as User wants AUTO COLOR (ANALOG ONLY) TO adjust the horizontal size of the entire screen image.
  • Page 27 W240S Multi Function 2D/3D Wide Monitor • Sound VOLUME To adjust the audio volume level. BASE To emphasize low frequency audio. TREBLE To empahsize high frequency audio. BALANCE To use this function to balance sound from the left and right speakers.
  • Page 28 W240S Multi Function 2D/3D Wide Monitor DISPLAY CONTROL If you choose DISP. CONTROL on the OSD menu, you can adjust the following <PC> - Full (16:10) : Shows full screen regardless of screen size. - Aspect : It keeps the vertical & horizontal ratio on the screen and shows with full screen.

  • Page 29: Display Power Management

    W240S Multi Function 2D/3D Wide Monitor 10. Display power If the power management function of your computer is enabled, your monitor turns on and off automatically. You can control power management features from management your computer. Your computer may have power management features which enable the computer or monitor to enter a power saving mode when the system is idle.

  • Page 30: Troubleshooting

    W240S Multi Function 2D/3D Wide Monitor 11. Troubleshooting If your monitor is not functioning properly, you may be able to solve the problem by following the suggestions below : Problem Possible solution Blank screen If the power LED is not lit, push the Soft power switch or check the AC cord to turn the monitor on.
  • Page 31 W240S Multi Function 2D/3D Wide Monitor Problem Possible solution Color defects Check that the signal cable connector is properly connected and that the connection pins are not bent or damaged. Try another color temperature. Size, position, Adjust the picture characteristics as described in the section shape or quality Adjustment.
  • Page 32 W240S Multi Function 2D/3D Wide Monitor Problem Possible solution The power LED is LED Indicator can be orange color on changing of video mode or a orange color Input Signal. Check the Resolution and the frequency on the video part of your computer.

  • Page 33: Specifications

    9.9Kg unpacked, 13.4Kg packed Dimensions (W X H X D mm) 579 X 455 X 240 mm • Specification is subject to change without notice. • HYUNDAI IT CORP. specification on “dead pixel” of LCD Panel applies to ISO 13406-2 Standard. 29/29...
