Hyundai W220S User Manual

Multi function 2d/3d wide monitor
Hide thumbs Also See for W220S:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Quick Manual
NEXT
Type No. L22C0E080
Model. W220S
Multi Function 2D/3D Wide Monitor
User's Guide

Advertisement

Table of Contents
loading

Related Manuals for Hyundai W220S

Summary of Contents for Hyundai W220S

  • Page 1 NEXT Type No. L22C0E080 Model. W220S Multi Function 2D/3D Wide Monitor User’s Guide...
  • Page 2 U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Declaration Of Conformity

    DECLARATION OF CONFORMITY HYUNDAI IT CORP. Ami-ri Bubal-Eub Ichon-Si Kyungki-Do 467-860 KOREA declare under our sole responsibility that the product: Kind of equipment LCD MONITOR Type-Designation L22C0E080 to which this declaration relates is in conformity with the following standard(s) or other normative document(s)

  • Page 4: Table Of Contents

    W220S Multi Function 2D/3D Wide Monitor Contents 1. Introduction ........1/27 2. Safety Information ......1/27 3. Cautions for Health & Safety ..3/27 4. Handling Instructions .....5/27 5. 3D Monitor SettingGuide....5/27 6. Q&A for 3D Mode......6/27 7. 3D Mode Specification ....8/27 8. Installing the monitor ....9/27 9.

  • Page 5: Introduction

    Multi Function 2D/3D Wide Monitor 1. Introduction This manual contains instructions for installing and operating HYUNDAI IT CORP. W220S. HYUNDAI IT CORP. W220S is a highly ergonomic color display unit. 22” viewable WSXGA + LCD • • High quality screen re-scaling capability •...
  • Page 6 W220S Multi Function 2D/3D Wide Monitor Avoid operating the monitor in extreme heat, humidity or areas affected by dust. Temperature : 5~40°C Humidity : 30~80RH Be sure to turn the monitor off before plugging the power cord into the socket. Make sure that the power cord and the other cords are securely and rightly connected.

  • Page 7: Cautions For Health & Safety

    W220S Multi Function 2D/3D Wide Monitor - Cleaning and Maintenance • To avoid to risk of electric shock, do not disassemble the Cabinet of display Unit. The Cabinet is not user-serviceable. Remember to unplug the display unit from the power outlet before cleaning.
  • Page 8 W220S Multi Function 2D/3D Wide Monitor • If you feel any problems as follows, stop using it and take a rest. - Pain in the eyes, tears, dry eyes, heavy eyelids - Nausea, vomiting, dizziness, stomach pain, perspiration - Headache, heaviness in head or dizziness, dry mouth - Sickness If you don't feel better, go to your doctor.

  • Page 9: Handling Instructions

    W220S Multi Function 2D/3D Wide Monitor 4. Handling Instructions • When viewing stereoscopic images, please use the special polarized glasses. Without this glasses, you can not enjoy stereoscopic images. How to use If you use some polarized glasses from other companies, you can not fully enjoy the stereoscopic images.

  • Page 10: Q&A For 3D Mode

    W220S Multi Function 2D/3D Wide Monitor • For 3D viewing, go to 1:1 mode under Display Control of OSD MENU before viewing it (Monitor Manual: see 21 page). Viewing on a different mode may decrease 3D effects. • On 1:1 mode, the screen size changes according to the input resolution.
  • Page 11 W220S Multi Function 2D/3D Wide Monitor When you don't set the resolution properly. - 3D mode displays best in 1680*1050/60Hz resolution. (See 3D Monitor Setting Guide above ) When the left/right images are reversed - Change the option to have the image on the right displayed in the horizontal line of the odd number.

  • Page 12: D Mode Specification

    W220S Multi Function 2D/3D Wide Monitor The monitor screen reflects my face. - This monitor has a 3D filter on the surface of the panel. The reflection is caused by it. You cannot remove it. To reduce the reflected lights, it is recommended that you don't have any light source behind your back.

  • Page 13: Installing The Monitor

    W220S Multi Function 2D/3D Wide Monitor 8. Installing the The following items should be found in the packaging. monitor - Packing List Power Cord Japan Signal Cable America/Canada Europe DVI Cable South Africa Australia Audio Cable Manual & 3D Soft Program...
  • Page 14 W220S Multi Function 2D/3D Wide Monitor - Selecting a suitable • Place the monitor at least 30cm from other electrical or heat-emitting equipment and allow at least 10cm on each side for ventilation. location • Place the monitor in a position where no light shines directly onto or is reflected on the screen.
  • Page 15 W220S Multi Function 2D/3D Wide Monitor • Way to Connect Turn on the power to the computer. The picture will appear within about 10 seconds. Adjust the picture to obtain optimum picture quality. See section Adjusting the picture in this guide for more information.
  • Page 16 W220S Multi Function 2D/3D Wide Monitor • Audio system This monitor has an audio system including two micro loudspeakers. Each of two micro loudspeakers has an 3W(max.) output power. This system also supports a Audio output jack. This system has been tuned to get a best tone quality which an audio input level is under 500mv rms.
  • Page 17 W220S Multi Function 2D/3D Wide Monitor - Setting the refresh rate Follow the instructions below to set your refresh rate in Windows 98/ME/XP/2000/VISTA. Go to the configuration window(Start-Settings-Configuration window). Double click on the ‘Display’ icon. Click on the ‘Settings’ tab.
  • Page 18 W220S Multi Function 2D/3D Wide Monitor • Preset Timing Table If the signal from the system doesn't equal to the preset timing mode, adjust the mode with reference to the user guide of videocard because the screen may not be displayed.
  • Page 19 W220S Multi Function 2D/3D Wide Monitor - User’s Environment Recommended Ergonomic User’s Environment Viewing angle of the monitor should be between -5 ~ 15 degree. • Supports Pivot. (Option) The screen can be vertically rotated by 90 degrees. This reduces the inconvenience of...
  • Page 20 W220S Multi Function 2D/3D Wide Monitor • Kensington Security • This display unit supports a Kensington-type security device to secure your (Locking) Slot monitor. Kensington lock is not included. • To purchase and install the Kensington locking device, please refer to the following contact information.

  • Page 21: Adjusting The Picture

    W220S Multi Function 2D/3D Wide Monitor 9. Adjusting the picture You can adjust the screen display by using the buttons located below the screen. The second Menu from the OSD can't be chosen in digital-mode. 17/27...
  • Page 22 W220S Multi Function 2D/3D Wide Monitor To make adjustments in the On Screen Display, follow these steps: - Using the On Screen Display Push the MENU button to call the OSD to the screen. Push the button to choose the item you want to adjust. The selected item is highlighted.
  • Page 23 W220S Multi Function 2D/3D Wide Monitor - OSD Adjustments PC MODE • Picture BRIGHTNESS To adjust the brightness of the screen. CONTRAST To adjust the contrast of the screen. H.POSITION To move image left and right. V.POSITION To move image up and down CLOCK To adjust the horizontal size of the entire screen image.
  • Page 24 W220S Multi Function 2D/3D Wide Monitor PC ANALOG, DVI • Color STANDARD For general Color tone. REDISH For Redish color with warm tone. BLUISH For Bluish color with cool tone. USER For adjusting degree of RGB as User wants AUTO COLOR (ANALOG ONLY) TO adjust the horizontal size of the entire screen image.
  • Page 25 W220S Multi Function 2D/3D Wide Monitor • Sound VOLUME To adjust the audio volume level. BASE To emphasize low frequency audio. TREBLE To empahsize high frequency audio. BALANCE To use this function to balance sound from the left and right speakers.
  • Page 26 W220S Multi Function 2D/3D Wide Monitor DISPLAY CONTROL If you choose DISP. CONTROL on the OSD menu, you can adjust the following <PC> - Full (16:10) : Shows full screen regardless of screen size. - Aspect : It keeps the vertical & horizontal ratio on the screen and shows with full screen.

  • Page 27: Display Power Management

    W220S Multi Function 2D/3D Wide Monitor If the power management function of your computer is enabled, your monitor turns on and off automatically. You can control power management features from 10. Display power your computer. management Your computer may have power management features which enable the computer or monitor to enter a power saving mode when the system is idle.

  • Page 28: Troubleshooting

    W220S Multi Function 2D/3D Wide Monitor 11. Troubleshooting If your monitor is not functioning properly, you may be able to solve the problem by following the suggestions below : Problem Possible solution Blank screen If the power LED is not lit, push the Soft power switch or check the AC cord to turn the monitor on.
  • Page 29 W220S Multi Function 2D/3D Wide Monitor Problem Possible solution Color defects Check that the signal cable connector is properly connected and that the connection pins are not bent or damaged. Try another color temperature. Size, position, Adjust the picture characteristics as described in the section shape or quality Adjustment.
  • Page 30 W220S Multi Function 2D/3D Wide Monitor Problem Possible solution The power LED is LED Indicator can be orange color on changing of video mode or a orange color Input Signal. Check the Resolution and the frequency on the video part of your computer.

  • Page 31: Specifications

    522 X 412 X 210 mm Dimensions (W X H X D mm) 522 X 415 X 240 mm (Pivot) • Specification is subject to change without notice. • HYUNDAI IT CORP. specification on “dead pixel” of LCD Panel applies to ISO 13406-2 Standard. 27/27...
