Carbon Monoxide Alarm
User's Guide
AC Plug-in Operated with Self Recharging Battery Backup
ATTENTION: Please take a few minutes to thoroughly read this
user's guide which should be saved for future reference and
passed on to any subsequent owner.
Manual P/N 820-1280 Rev. C 08/11
900-0099
900-0099
KN-COPP-3-RC
with Digital Display
Advertisement
Table of Contents
Related Manuals for Kidde KN-COPP-3-RC
Summary of Contents for Kidde KN-COPP-3-RC
-
Page 1: Carbon Monoxide Alarm
Carbon Monoxide Alarm User’s Guide 900-0099 900-0099 KN-COPP-3-RC with Digital Display AC Plug-in Operated with Self Recharging Battery Backup ATTENTION: Please take a few minutes to thoroughly read this user’s guide which should be saved for future reference and passed on to any subsequent owner. - Page 2 What to do When the Alarm Sounds! Carbon Monoxide Alarm Procedure WARNING: Activation of the CO Alarm indicates the presence of Carbon Monoxide (CO) which can kill you. If the alarm sounds 4 quick “beeps”, 5 seconds off: 1) Immediately move to fresh air – outdoors. Check that all persons are accounted for.
- Page 3 Note: Many times throughout this User’s Guide, we will refer to Carbon Monoxide as “CO”. This Kidde carbon monoxide (CO) alarm is an important part of your family’s home safety plan. This alarm has been designed and tested to detect CO buildup in a residential environment. Your alarm is for use specifically in the home.
- Page 4 Important Warning Statements WARNING: This product is intended for use in ordinary indoor locations of family living units. It is not designed to measure compliance with commercial or industrial standards. It is not suitable for installation in hazardous locations as defined in the National Electric Code.
- Page 5 1. Information About Carbon Monoxide General Carbon Monoxide Information Carbon monoxide is a colorless, odorless and tasteless poison gas that can be fatal when inhaled. CO inhibits the blood’s capacity to carry oxygen. Periodically review this alarm manual and discuss your CO alarm emergency procedure with all the members of your family.
- Page 6 See “What to do When the Alarm Sounds” (inside front cover). Low Levels: Generally below 50 PPM. Kidde recommends you take action to eliminate the source of CO. See “What to do When the Alarm Sounds” (inside front cover).
- Page 7 Because carbon monoxide is a cumulative poison, long-term exposures to low levels may cause symptoms, as well as short-term exposures to high levels. This Kidde unit has a time-weighted alarm – the higher the level of CO present, the sooner the alarm will be triggered.
- Page 8 1. Information About Carbon Monoxide This CO alarm can only warn you of the presence of CO. It does not prevent CO from occurring, nor can it solve an existing CO problem. If your unit has alarmed and you’ve provided ventilation by leaving your windows and doors open, the CO buildup may have dissipated by the time help responds.
- Page 9 2. Product Features and Specifications 900-0099 Digital with digital display Display Blinking Red Dot Test/Reset Peak Level Button Button Adapter Thumb Release Sounder Alarm Back Removable Door Adapter Rechargeable Holes Backup Battery (shown installed) Cord Recess Cord Recess Slide Support for Table Top and Direct Plug Use Power Cord...
- Page 10 Recommended Installation Locations CO alarms should be mounted in or near bedrooms and living areas. It is recommended that you install a Kidde CO alarm on each level of your home. When choosing your installation Recommended Locations locations, make sure you can hear the alarm from all sleeping areas.
- Page 11 (40°F) or hotter than 37.8°C (100°F) such as crawl spaces, attics, porches and garages. • Do not install within 5 ft. of heating or cooking appliances. (Kidde recommends 15 ft. to prevent nuisance alarms). • Do not install near vents, flues, chimneys or any forced/unforced air ventilation openings.
-
Page 12: Installation Instructions
Direct Plug Alarm In its “as shipped” configuration, all you need to do is install the backup battery and your Kidde CO alarm is ready to be plugged directly into a wall socket. - Page 13 4. Installation Instructions If the outlet is mounted horizontally (sideways): If you are going to use your alarm as a direct plug and you are going to plug in to an outlet that is mounted horizontally (sideways), you will need to rotate the adapter 90˚.
- Page 14 Wall Table Top Alarm You can use your Kidde CO alarm as a table top unit. Follow steps 1 thru 4 above. Instead of mounting the unit to a wall, pull out the slide support and place in a location that is easily visible. Be sure the alarm is no more than three feet from the floor.
- Page 15 30 repeating Sounds” (inside and 999 front cover) Steady “Err” “Beep” every 30 Unit is not Unit malfunction Call Kidde customer and flashing seconds operational – service at will not detect 1-800-880-6788 No display Constant alarm Unit is not...
- Page 16 “Lb” sensing for CO 5 minutes of seated& oriented displayed once operation on properly. Connect every 60 battery backup. to AC power to seconds; fully charge battery. flashing dot. Call Kidde customer service at 1-800-880-6788 if condition continues...
-
Page 17: Peak Level Memory
& oriented approximately 7 discharged. properly. Connect to hours. WILL AC power to fully NOT DETECT charge battery. Call Kidde customer service at 1-800-880-6788 if condition continues. None None Unit is not Battery is Confirm battery operational. - Page 18 8 volt Lithium Ion battery backup – the 8 volt battery is to supply short term back-up during a power outage. WARNING: Replace the battery pack only with a Kidde rechargeable battery pack. Replacement battery packs can be purchased from Kidde customer service.
- Page 19 7. Maintenance Lithium Ion Battery Handling Precautions Handling • Do not use the battery for a purpose other than for the alarm it is specified. • Do not recharge the battery using any charging circuit other than the one provided in the alarm. A recharging operation under non- conforming recharging conditions can cause electrolyte leakage, overheating, smoke emission, bulging/bursting and/or ignition.
- Page 20 7. Maintenance • Li-Ion batteries may be disposed of in normal household waste. Contact local landfill for recycling practices in your area. Maintenance Tips To keep your alarm in good working order, you must follow these steps: • Test the alarm once a week by pressing the Test/Reset button. •...
-
Page 21: Limited Warranty
In many cases, the quickest way to exchange your alarm is to return it to the original place of purchase. Alternatively, you may return it for servicing to Kidde. If you have questions, call Kidde Customer Service at 1-800-880-6788.
