Yamaha XVS650A Owner's Manual

Dragstar 2003
Hide thumbs Also See for XVS650A:
Table of Contents

Advertisement

Quick Links

See also: Supplementary Service Manual
OWNER'S MANUAL
XVS650A
5SC-28199-E1

Advertisement

Table of Contents
loading

Related Manuals for Yamaha XVS650A

Summary of Contents for Yamaha XVS650A

  • Page 1 OWNER’S MANUAL XVS650A 5SC-28199-E1...
  • Page 2 EAU26941 DECLARATION of CONFORMITY Company: MORIC CO., LTD. Address: 1450-6 Mori Mori-Machi Shuchi-gun Shizuoka 437-0292 Japan Hereby declare that the product: Kind of equipment: IMMOBILIZER Type-designation: 5SL-00, 5VS-00, 5VX-00, 3HT-00, 5UX-00, 5UX-10, 5KS-00 and 5KS-10 is in compliance with following norm(s) or documents: R&TTE Directive(1999/5/EC) EN300 330-2 v1.1.1(2001-6), EN60950(2000) Two or Three-Wheel Motor Vehicles Directive(97/24/EC: Chapter 8, EMC)
  • Page 3 Yamaha a reputation for dependability. Please take the time to read this manual thoroughly, so as to enjoy all advantages of your XVS650A. The owner’s manual does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself and others from trouble and injury.

  • Page 4: Important Manual Information

    This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle is subsequently sold. Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your motorcycle and this manual.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10200 XVS650A OWNER’S MANUAL ©2003 by Yamaha Motor Co., Ltd. 1st edition, August 2003 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ....1-1 Ignition circuit cut-off system ..3-15 Tires ..........6-14 Spoke wheels ......6-16 DESCRIPTION ........2-1 PRE-OPERATION CHECKS ..... 4-1 Adjusting the clutch lever free Left view ..........2-1 Pre-operation check list ....4-2 play ........... 6-16 Right view ........2-2 Adjusting the brake lever free Controls and instruments....2-3...
  • Page 7 TABLE OF CONTENTS Replacing a turn signal light bulb or the tail/brake light bulb ..6-29 Replacing the auxiliary light bulb ...........6-29 Supporting the motorcycle ....6-30 Front wheel ........6-31 Rear wheel ........6-32 Troubleshooting ......6-34 Troubleshooting chart ....6-35 MOTORCYCLE CARE AND STORAGE ..........7-1 Care ..........7-1 Storage ...........7-3 SPECIFICATIONS ......8-1...

  • Page 8: Safety Information

    SAFETY INFORMATION EAU10250 AND/OR WHEN MADE NECES- • Ride where other motorists can SARY BY MECHANICAL CONDI- see you. Avoid riding in another MOTORCYCLES SINGLE TIONS. motorist’s blind spot. TRACK VEHICLES. THEIR SAFE USE Many motorcycle accidents in- AND OPERATION ARE DEPENDENT Safe riding volve inexperienced operators.
  • Page 9 Modifications made to this motorcycle other motorists can see you. the single most critical factor in the pre- not approved by Yamaha, or the re- The posture of the operator and vention or reduction of head injuries. moval of original equipment, may ren- passenger is important for proper Always wear an approved helmet.
  • Page 10 Since Yamaha cannot should be kept to a minimum. 198 kg (437 lb). When loading within test all other accessories that may be •...
  • Page 11 SAFETY INFORMATION Gasoline and exhaust gas • Do not park the motorcycle on a GASOLINE IS HIGHLY FLAMMA- slope or soft ground, otherwise it BLE: may fall over. • Always turn the engine off when • Do not park the motorcycle near refueling.

  • Page 12: Description

    DESCRIPTION EAU10410 Left view 1. Shift pedal (page 3-7) 2. Fuel cock (page 3-10) 3. Starter (choke) knob (page 3-11) 4. Shock absorber assembly spring preload adjusting ring (page 3-13) 5. Helmet holder (page 3-12) 6. Storage compartment (page 3-13) 7.

  • Page 13: Right View

    DESCRIPTION EAU10420 Right view 1. Engine oil filter element (page 6-7) 2. Battery (page 6-25) 3. Fuses (page 6-26) 4. Main switch/steering lock (page 3-2) 5. Air filter element (page 6-11) 6. Brake pedal (page 3-8)

  • Page 14: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 3-7) 2. Left handlebar switches (page 3-5) 3. Speedometer unit (page 3-5) 4. Fuel tank cap (page 3-8) 5. Right handlebar switches (page 3-5) 6. Throttle grip (page 6-13) 7. Brake lever (page 3-7)

  • Page 15: Instrument And Control Functions

    Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red Do not place any key close to bow for driving.

  • Page 16: Main Switch/Steering Lock

    INSTRUMENT AND CONTROL FUNCTIONS EAU10471 EAU33590 To lock the steering Main switch/steering lock All electrical circuits are supplied with power; the meter lighting, taillight and auxiliary light come on, and the engine can be started. The key cannot be re- moved.

  • Page 17: Indicator And Warning Lights

    INSTRUMENT AND CONTROL FUNCTIONS To unlock the steering EAU33000 EAU11001 (Parking) Indicator and warning lights The steering is locked, and the taillight and auxiliary light are on. The hazard light and turn signal lights can be turned on, but all other electrical systems are off.
  • Page 18 When this occurs, diagnosis device for the immobilizer vehicle, the code re-registering have a Yamaha dealer check the self- system. If the immobilizer system is de- key and both standard keys to a diagnosis system.

  • Page 19: Speedometer Unit

    EAU12342 Speedometer unit Anti-theft alarm (optional) Handlebar switches This model can be equipped with an Left optional anti-theft alarm by a Yamaha dealer. Contact a Yamaha dealer for more information. 1. Tripmeter reset knob 2. Speedometer 1. Pass switch “...
  • Page 20 INSTRUMENT AND CONTROL FUNCTIONS Right position. To cancel the turn signal EAU12731 Hazard switch “ ” lights, push the switch in after it has re- With the key in the “ON” or “ ” posi- turned to the center position. tion, use this switch to turn on the haz- ard light (simultaneous flashing of all EAU12500...

  • Page 21: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU12820 EAU12880 EAU12890 Clutch lever Shift pedal Brake lever 1. Clutch lever 1. Shift pedal 1. Brake lever The clutch lever is located at the left The shift pedal is located on the left The brake lever is located at the right handlebar grip.

  • Page 22: Brake Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12941 EAU13020 Brake pedal Fuel tank cap NOTE: The fuel tank cap cannot be installed unless the key is in the lock. In addition, the key cannot be removed if the cap is not properly installed and locked. EWA10130 WARNING Make sure that the fuel tank cap is...

  • Page 23: Fuel

    Your Yamaha engine has been de- signed to use regular unleaded gaso- line with a research octane number of 91 or higher. If knocking (or pinging) oc-...

  • Page 24: Catalytic Converter

    INSTRUMENT AND CONTROL FUNCTIONS EAU13440 EAU13550 Catalytic converter Fuel cock This vehicle is equipped with a catalytic The fuel cock supplies fuel from the converter in the muffler. tank to the carburetors while also filter- ing it. EWA10860 WARNING The fuel cock lever positions are ex- plained as follows and shown in the il- The exhaust system is hot after op- eration.

  • Page 25: Starter (Choke) Knob

    INSTRUMENT AND CONTROL FUNCTIONS This indicates reserve. With the fuel EAU13620 EAU14190 Starter (choke) knob “ ” Seats cock lever in this position, the fuel re- serve is made available. Turn the fuel Passenger seat cock lever to this position if you run out of fuel while riding.

  • Page 26: Helmet Holder

    INSTRUMENT AND CONTROL FUNCTIONS To install the rider seat EAU14281 Helmet holder 1. Insert the projection on the front of the rider seat into the holder as shown, place the seat in the origi- nal position, and then install the bolt.

  • Page 27: Storage Compartment

    INSTRUMENT AND CONTROL FUNCTIONS EAU14481 EAU14860 Storage compartment Adjusting the shock absorber The storage compartment is located on assembly the left side of the vehicle. To open the storage compartment 1. Slide the lock cover open, insert the key into the lock, and then turn it clockwise.

  • Page 28: Luggage Strap Holders

    Do not deform or damage the Standard: gas cylinder in any way, as this will result in poor damping per- Maximum (hard): formance. Always have a Yamaha dealer 3. Install the passenger and rider service the shock absorber. seats. 3-14...

  • Page 29: Sidestand

    INSTRUMENT AND CONTROL FUNCTIONS EAU15300 below and have a Yamaha dealer re- EAU15311 Sidestand Ignition circuit cut-off system pair it if it does not function proper- The sidestand is located on the left side The ignition circuit cut-off system (com- of the frame.
  • Page 30 5. Push the start switch. Does the engine start? The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 6. Move the sidestand up. 7. Keep the clutch lever pulled.

  • Page 31: Pre-Operation Checks

    PRE-OPERATION CHECKS EAU15591 The condition of a vehicle is the owner’s responsibility. Vital components can start to deteriorate quickly and unexpectedly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leakage or loss of tire air pressure could have serious consequences.

  • Page 32: Pre-Operation Check List

    • Make sure that operation is smooth. • Check cable free play. Throttle grip 6-13, 6-21 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-21 •...
  • Page 33 Chassis fasteners — • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 3-15 • If system is defective, have Yamaha dealer check vehicle.

  • Page 34: Operation And Important Riding Points

    Become thoroughly familiar following conditions must be met: Yamaha dealer check the electrical cir- The transmission is in the neutral with all operating controls and cuit. position. their functions before riding.

  • Page 35: Starting A Warm Engine

    EAU16640 EAU16671 Starting a warm engine Shifting engine, and have a Yamaha dealer Follow the same procedure as for start- check the self-diagnosis system. ing a cold engine with the exception 6. After starting the engine, move the that the starter (choke) is not required starter (choke) back halfway.

  • Page 36: Tips For Reducing Fuel Consumption

    OPERATION AND IMPORTANT RIDING POINTS ECA10260 EAU16800 Shift up points: Tips for reducing fuel CAUTION: 1st → 2nd: 23 km/h (14 mi/h) consumption 2nd → 3rd: 36 km/h (22 mi/h) Even with the transmission in 3rd → 4th: 50 km/h (31 mi/h) Fuel consumption depends largely on the neutral position, do not 4th →...

  • Page 37: Engine Break-In

    Do not park on a slope or on soft during the engine break-in period, tle operation or any condition that might ground, otherwise the vehicle immediately have a Yamaha dealer result in engine overheating must be may overturn. check the vehicle.

  • Page 38: Periodic Maintenance And Minor Repair

    Yamaha dealer certain maintenance work correctly. do it for you. NOTE: If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 39: Periodic Maintenance And Lubrication Chart

    The annual checks must be performed every year, except if a kilometer-based maintenance is performed in- stead. From 50000 km, repeat the maintenance intervals starting from 10000 km. Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. ODOMETER READING (× 1000 km)
  • Page 40 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (× 1000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK √ √ √ √ √ • Check for cracks or damage. 9 * Brake hose • Replace. Every 4 years • Check runout, spoke tightness and for damage. √...
  • Page 41 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (× 1000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK √ √ √ Engine oil filter element • Replace. √ √ √ • Check oil level and vehicle for oil leakage. Final gear oil √...

  • Page 42: Removing And Installing Panels

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU18771 To install the panel Removing and installing Place the panel in the original position, panels and then install the bolts. The panels shown need to be removed to perform some of the maintenance EAU19151 Panel B jobs described in this chapter.

  • Page 43: Checking The Spark Plugs

    Do not attempt to diagnose such 1. Spark plug cap problems yourself. Instead, have a 2. Remove the spark plug as shown, Yamaha dealer check the vehicle. with the spark plug wrench includ- ed in the owner’s tool kit.

  • Page 44: Engine Oil And Oil Filter Element

    PERIODIC MAINTENANCE AND MINOR REPAIR 3. Check each spark plug for elec- 2. Clean the surface of the spark plug EAU19741 Engine oil and oil filter trode erosion and excessive car- gasket and its mating surface, and element bon or other deposits, and replace then wipe off any grime from the The engine oil level should be checked it if necessary.
  • Page 45 PERIODIC MAINTENANCE AND MINOR REPAIR 2. Place an oil pan under the engine NOTE: to collect the used oil. The engine oil should be between the 3. Remove the engine oil filler cap minimum and maximum level marks. and drain bolt to drain the oil from the crankcase.
  • Page 46 PERIODIC MAINTENANCE AND MINOR REPAIR Make sure that no foreign mate- Tightening torque: rial enters the crankcase. Engine oil drain bolt: 43 Nm (4.3 m·kgf, 31 ft·lbf) 10. Start the engine, and then let it idle for several minutes while checking 9.

  • Page 47: Final Gear Oil

    If any 3. Install the final gear oil drain bolt, NOTE: leakage is found, have a Yamaha deal- and then tighten it to the specified The oil level should be at the brim of the er check and repair the vehicle.

  • Page 48: Cleaning The Air Filter Element

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU33380 ECA10480 Cleaning the air filter element CAUTION: The air filter element should be cleaned Make sure that the air filter ele- at the intervals specified in the periodic ment is properly seated in the maintenance and lubrication chart.

  • Page 49: Adjusting The Carburetors

    Yamaha dealer, who has the neces- periodic maintenance and lubrication sary professional knowledge and expe- chart. rience. The adjustment described in the...

  • Page 50: Adjusting The Throttle Cable Free Play

    The valve clearance changes with use, resulting in improper air-fuel mixture and/or engine noise. To prevent this from occurring, the valve clearance must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. 1. Throttle stop screw Engine idling speed: 1150–1250 r/min...

  • Page 51: Tires

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU33390 passenger, cargo, and accesso- Tire air pressure (measured on cold Tires ries does not exceed the speci- tires): To maximize the performance, durabil- fied maximum load for the 0–90 kg (0–198 lb): ity, and safe operation of your motor- Front: vehicle.
  • Page 52 It is not recommended to patch BRIDGESTONE/G703 glass fragments in it, or if the sidewall is a punctured tube. If unavoid- DUNLOP/D404F cracked, have a Yamaha dealer re- able, however, patch the tube Rear tire: place the tire immediately. very carefully and replace it as...

  • Page 53: Spoke Wheels

    5. Loosen the locknut at the crank- age before each ride. If any dam- case. age is found, have a Yamaha dealer replace the wheel. Do not attempt even the smallest repair to 1. Locknut the wheel.

  • Page 54: Adjusting The Brake Lever Free Play

    PERIODIC MAINTENANCE AND MINOR REPAIR 7. Tighten the locknut at the clutch le- EAU22092 Adjusting the brake lever free ver and the crankcase. play 1. Locknut 2. Brake lever free play adjusting screw 1. Loosen the locknut at the brake le- 1.

  • Page 55: Adjusting The Brake Pedal Position And Free Play

    (b). 1. Distance between brake pedal and footrest 2. Brake pedal free play EWA10670 WARNING It is advisable to have a Yamaha dealer make these adjustments. 1. Locknut 2. Brake pedal position adjusting bolt NOTE: The brake pedal position should be ad- 3.

  • Page 56: Adjusting The Rear Brake Light Switch

    PERIODIC MAINTENANCE AND MINOR REPAIR Brake pedal free play EAU22270 EAU22380 Adjusting the rear brake light Checking the front brake pads The brake pedal free play should mea- switch and rear brake shoes sure 20.0–30.0 mm (0.79–1.18 in) at The front brake pads and the rear brake the brake pedal end.

  • Page 57: Checking The Brake Fluid Level

    When checking the fluid level, brake fluid level goes down sud- the wear limit line, have a Yamaha make sure that the top of the brake denly, have a Yamaha dealer dealer replace the brake shoes as a fluid reservoir is level.

  • Page 58: Changing The Brake Fluid

    EAU23100 EAU23110 Changing the brake fluid Checking and lubricating the Checking and lubricating the Have a Yamaha dealer change the cables throttle grip and cable brake fluid at the intervals specified in The operation of all control cables and The operation of the throttle grip should...

  • Page 59: Checking And Lubricating The Brake And Shift Pedals

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU23131 EAU23140 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease (all-pur- brake and shift pedals brake and clutch levers pose grease) Brake lever Clutch lever The operation of the brake and shift pedals should be checked before each The operation of the brake and clutch ride, and the pedal pivots should be lu-...

  • Page 60: Checking And Lubricating The Sidestand

    2. While applying the front brake, If the sidestand does not move up push down hard on the handlebars and down smoothly, have a Yamaha several times to check if the front dealer check or repair it. fork compresses and rebounds smoothly.

  • Page 61: Checking The Steering

    Securely support the vehicle so that fork does not operate smoothly, there is no danger of it falling over. have a Yamaha dealer check or re- pair it. 2. Hold the lower ends of the front fork legs and try to move them for- ward and backward.

  • Page 62: Checking The Wheel Bearings

    Therefore, keep sparks, flames, cigarettes, etc., To charge the battery away from the battery and pro- Have a Yamaha dealer charge the bat- vide sufficient ventilation when tery as soon as possible if it seems to charging it in an enclosed have discharged.

  • Page 63: Replacing The Fuses

    IES OUT OF THE REACH OF If you do not have access to a CHILDREN. sealed-type (MF) battery charg- er, have a Yamaha dealer charge your battery. To store the battery 1. If the model will not be used for...

  • Page 64: Replacing The Headlight Bulb

    2. Remove the blown fuse, and then 4. If the fuse immediately blows install a new fuse of the specified amperage. again, have a Yamaha dealer check the electrical system. 6-27...
  • Page 65 7. Have a Yamaha dealer adjust the the glass, the luminosity of the bulb, headlight beam if necessary. and the bulb life will be adversely af- fected.

  • Page 66: Replacing A Turn Signal Light Bulb Or The Tail/Brake Light Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU24281 2. Remove the defective bulb by EAU33411 Replacing a turn signal light Replacing the auxiliary light pushing it in and turning it counter- bulb or the tail/brake light bulb bulb clockwise. 1. Remove the lens by removing the If the auxiliary light bulb burns out, re- 3.

  • Page 67: Supporting The Motorcycle

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU24350 a jack either under each side of the Supporting the motorcycle frame in front of the rear wheel or under Since this model is not equipped with a each side of the swingarm. centerstand, follow these precautions when removing the front and rear wheel or performing other maintenance requiring the motorcycle to stand up-...

  • Page 68: Front Wheel

    EAU24660 To remove the front wheel jections mesh with the slots. EWA10820 WARNING It is advisable to have a Yamaha dealer service the wheel. Securely support the motor- cycle so that there is no danger 1. Rubber cap of it falling over.

  • Page 69: Rear Wheel

    To remove the rear wheel EWA10820 Tightening torques: WARNING Wheel axle: It is advisable to have a Yamaha 59 Nm (5.9 m·kgf, 43 ft·lbf) dealer service the wheel. Front wheel axle pinch bolt: Securely support the motor- 20 Nm (2.0 m·kgf, 14 ft·lbf) cycle so that there is no danger 6.
  • Page 70 PERIODIC MAINTENANCE AND MINOR REPAIR EAU25511 7. Tighten the axle nut, the final gear To install the rear wheel case bolts and the brake torque 1. Install the rear wheel, wheel axle, rod nuts to the specified torques. final gear case, and drive shaft by pushing the wheel forward and Tightening torques: guiding the drive shaft into the mid-...

  • Page 71: Troubleshooting

    However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 72: Troubleshooting Chart

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.

  • Page 73: Motorcycle Care And Storage

    MOTORCYCLE CARE AND STORAGE EAU26060 ucts onto seals, gaskets and wheel thinner, fuel (gasoline), rust re- Care axles. Always rinse the dirt and de- movers or inhibitors, brake flu- While the open design of a motorcycle greaser off with water. id, antifreeze or electrolyte.
  • Page 74 MOTORCYCLE CARE AND STORAGE After normal use ECA10790 5. Touch up minor paint damage CAUTION: Remove dirt with warm water, a mild caused by stones, etc. detergent, and a soft, clean sponge, 6. Wax all painted surfaces. Do not use warm water since it in- and then rinse thoroughly with clean 7.

  • Page 75: Storage

    Always store your motorcycle in a cool, NOTE: into the fuel tank. dry place and, if necessary, protect it Consult a Yamaha dealer for advice on 4. Fill up the fuel tank and add fuel against dust with a porous cover. what products to use.
  • Page 76 MOTORCYCLE CARE AND STORAGE EWA10950 than 30 °C (90 °F)]. For more in- WARNING formation on storing the battery, To prevent damage or injury from see page 6-25. sparking, make sure to ground the NOTE: spark plug electrodes while turning Make any necessary repairs before the engine over.

  • Page 77: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Fuel tank capacity: 16.0 L (4.23 US gal) (3.52 Imp.gal) Overall length: Type: Fuel reserve amount: 2450 mm (96.5 in) SAE10W30 or SAE10W40 or SAE15W40 3.0 L (0.79 US gal) (0.66 Imp.gal) Overall width: or SAE20W40 or SAE20W50 Carburetor: 930 mm (36.6 in) Overall height:...
  • Page 78 SPECIFICATIONS Gear ratio: Manufacturer/model: Operation: 1st: DUNLOP/D404G Right hand operation 38/14 (2.714) Loading: Recommended fluid: 2nd: DOT 4 Maximum load: 38/20 (1.900) Rear brake: 198 kg (437 lb) 3rd: (Total weight of rider, passenger, cargo and Type: 35/24 (1.458) accessories) Drum brake 4th: Tire air pressure (measured on cold...
  • Page 79 SPECIFICATIONS Headlight: Ignition fuse: 10.0 A Bulb type: Parking lighting fuse: Halogen bulb 10.0 A Bulb voltage, wattage x quantity: Carburetor heater fuse: Headlight: 12 V, 60 W/55.0 W × 1 15.0 A Ignitor unit fuse: Tail/brake light: 12 V, 5.0/21.0 W × 1 5.0 A Backup fuse: Front turn signal light:...

  • Page 80: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.
  • Page 81 1. Model label The model label is affixed to the frame under the rider seat. (See page 3-11.) Record the information on this label in the space provided. This information will be needed when ordering spare parts from a Yamaha dealer.
  • Page 82 INDEX Pass switch ..........3-6 Periodic maintenance and lubrication Air filter element, cleaning..... 6-11 Final gear oil ......... 6-10 chart............6-2 Anti-theft alarm (optional)......3-5 Front fork, checking ......6-23 Pre-operation check list......4-2 Auxiliary light bulb, replacing ....6-29 Fuel............3-9 Fuel cock ..........
  • Page 83 INDEX Turn signal light bulb or tail/brake light bulb, replacing ........6-29 Turn signal switch........3-6 Valve clearance, adjusting....6-13 Vehicle identification number....9-1 Wheel bearings, checking ....6-25 Wheel (front) ......... 6-31 Wheel (rear).......... 6-32 Wheels..........6-16...
  • Page 86 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2003.09-0.3×1 CR...
