- Page 1 ..................... WAGL3E200 EN WASHING MACHINE USER MANUAL...
-
Page 2: Table Of Contents
16. INSTALLATION ............25 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. -
Page 3: Safety Information
ENGLISH 1. SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes in- juries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability. -
Page 4: Safety Instructions
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. • The operating water pressure (minimum and maximum) must be between 0,5 bar (0,05 MPa) and 8 bar (0,8 MPa) •... -
Page 5: Technical Information
ENGLISH • Do not put a container to collect possi- Water connection ble water leakage under the appliance. • Make sure not to cause damage to the Contact the Service to ensure which water hoses. accessories can be used. • The appliance is to be connected to the water mains using the new supplied 2.3 Care and Cleaning hose-sets. -
Page 6: Product Description
Water supply pressure Minimum 0,5 bar (0,05 MPa) Maximum 8 bar (0,8 MPa) Cold water Water supply Maximum load Cotton 7 kg Spin speed Maximum 1600 rpm 1) Connect the water inlet hose to a water tap with a 3/4'' thread. -
Page 7: Control Panel
ENGLISH To connect the drain hose on the edge of a sink. 4.2 Child safety device • When you activate this device, you can- not close the door. This prevents chil- dren or pets to be closed in the drum. To activate the device, turn it clockwise, until the groove is horizontal. -
Page 8: Programme Knob
5.2 Programme knob Turn this knob to set a programme. The related programme indicator comes on. 5.3 Display The display shows: • The maximum temperature of the programme. • The default spin speed of the programme. • 'No Spin' and 'Rinse Hold' symbols. -
Page 9: Delay Start Button
ENGLISH • The programme time When the programme starts, the time decreases with steps of 1 minute. • The delay start When you press the delay start button, the display shows the delay start time. • Alarm codes If the appliance has a malfunction, the display shows alarm codes. Refer to 'Troubleshooting' chapter. -
Page 10: Programmes
10 www.electrolux.com • To activate the function, press button 5.10 Temperature button and button at the same time un- Press button to change the default til the display shows the symbol temperature. • To deactivate the function, press button and button... - Page 11 ENGLISH Programme Type of load Cycle Functions Temperature max. weight of description load Pflegeleicht Synthetic or mixed Wash SPIN REDUCTION Synthétiques fabric items with nor- Rinses RINSE HOLD Synthetics mal level of soil. Short spin STAIN 60° - Cold max. 3.5 kg EXTRA RINSE TIME SAVING Pflegeleicht +...
- Page 12 12 www.electrolux.com Programme Type of load Cycle Functions Temperature max. weight of description load Gardinen Set this programme Prewash SPIN REDUCTION Rideaux to wash curtains. It Wash RINSE HOLD Curtains adds automatically Rinses EXTRA RINSE 40° - Cold the prewash phase...
-
Page 13: Consumption Values
ENGLISH 6) Set this programme to decrease the time and the consumption of energy and water. 7) Standard programmes for the Energy Label consumption values. According to regulation 1061/2010, the “Cottons Eco 60° C” and “Cottons Eco 40° C” are respectively the “standard 60°... -
Page 14: Before First Use
14 www.electrolux.com Off Mode (W) Left On Mode (W) The information given in the charts above are in compliance with the EU Commi- sion regulation 2015/2010 implementing directive 2009/125/EC. 7. BEFORE FIRST USE To activate the drain system, put 2 li- detergent dispenser. -
Page 15: Filling The Detergent And Additives
ENGLISH 10. FILLING THE DETERGENT AND ADDITIVES 10.1 USING THE DETERGENT AND ADDITIVES The detergent compartment for the prewash phase and the soak programme. Add the detergent for prewash and soak before the start of the programme. The detergent compartment for the washing phase. If you use a liquid detergent, put it immediately before you start the programme. -
Page 16: Setting And Starting A Programme
16 www.electrolux.com Measure out the detergent and the fabric conditioner. Press the lever down to remove the Carefully close the detergent dispens- dispenser. er. Make sure that the flap does not To use powder detergent, turn the cause a blockage when you close the flap up. -
Page 17: At The End Of The Programme
ENGLISH The appliance does not drain the Press button again and again until water. the display shows 0’. Press button . The programme 11.4 Change a function starts. You can change only some functions be- 11.7 Open the door fore they operate. Press button . -
Page 18: Helpful Hints And Tips
18 www.electrolux.com – The door stays locked. When the programme is completed and the door lock symbol goes off, – You must drain the water to open the you can open the door door. Deactivate the appliance. To drain the water:... -
Page 19: Care And Cleaning
ENGLISH Obey the instructions that you find on the • French degrees (°TH). packaging of the products. • mmol/l (millimol for each litre - interna- Equivalent scales measure the water tional unit for the hardness of water). hardness: • Clarke degrees. •... -
Page 20: Detergent Dispenser
20 www.electrolux.com • The display shows an alarm code be- 14.6 Detergent dispenser cause of the problem with water drain. Press the lever. WARNING! • Disconnect the mains plug from the mains socket. • Do not remove the filter while the appliance operates. - Page 21 ENGLISH • The appliance fills with the water for a long time. • The indicator of button flashes and the display shows the related alarm. Refer to 'Troubleshooting'. WARNING! Disconnect the mains plug from the mains socket. Cleaning the water inlet filters: Remove fluff and objects from the Close the water tap.
-
Page 22: Troubleshooting
22 www.electrolux.com °C, remove the remaining water from the 14.9 Emergency drain inlet hose and the drain pump. Because of a malfunction, the appliance Disconnect the mains plug from the cannot drain the water. mains socket. If this occurs, do steps (1) through (6) of Close the water tap. - Page 23 ENGLISH Problem Possible cause Possible solution The water pressure is Contact your local water authori- too low. The appliance The water drain hose is Make sure that the water drain does not drain the damaged. hose has no damages. water. The filter of the drain Clean the filter of the drain pump.
- Page 24 24 www.electrolux.com Problem Possible cause Possible solution Leakages from the drain Make sure that the drain pump pump. filter is tight. The water drain hose is Make sure that the water inlet damaged. hose has no damages. You cannot open The washing programme Let the washing programme end.
-
Page 25: Installation
ENGLISH 16. INSTALLATION Open the door. Remove the polystyr- 16.1 Fixing plate kit ene piece from the door seal and all (4055171146) the items from the drum. Available from your authorized dealer. If you install the appliance on a plinth, se- cure the appliance in the fixing plates. -
Page 26: Positioning And Levelling
26 www.electrolux.com 16.3 Positioning and levelling • Install the appliance on a flat hard floor. • Make sure that carpets do not stop the air circulation below the appliance. • Make sure that the appliance does not touch the wall or other units •... -
Page 27: Water Drainage
ENGLISH 16.5 Water drainage There are different procedures to connect the drain hose: With the plastic hose guide. • Connect the water inlet hose to the cold water tap with 3/4 thread. • On the edge of a sink. CAUTION! Make sure that there are no leaks from the couplings. -
Page 28: Environment Concerns
28 www.electrolux.com Refer to the illustration. Directly into a clip. Make sure that the drain hose drain pipe at a height of not less than makes a loop to prevent that remaining 60 cm and not more than 100 cm. The... - Page 29 ENGLISH...
- Page 30 30 www.electrolux.com...
- Page 31 ENGLISH...
- Page 32 www.electrolux.com/shop...
