A
X
3
7
D
P
l
u
s
/
A
A
X
3
7
D
P
l
u
s
/
A
Memory
With VIA Apollo Pro266 chipset, the AX37D Plus / AX37D Pro can support
interface allows zero wait state bursting between the SDRAM and the data buffers at 66/100/133MHz. The four banks of DDR
SDRAM can be composed of an arbitrary mixture of 1M/2M4M/8M/16M/32M/64MxN SDRAM and maximum up to 2GB. In addition,
the AX37D Plus / AX37D Pro has still added two 168-pin SDRAM sockets that allow you to install PC100 or PC133 memory up to 2
GB either. The AX37D Plus / AX37D Pro allows SDRAM to run at either synchronous or pseudo-synchronous mode with the host
CPU bus frequency (66/100/133MHz).
Ultra DMA 33/66/100 Bus Mater IDE
Comes with an on-board PCI Bus Master IDE controller with two connectors that supports four IDE devices in two channels,
supports
Ultra DMA
33/66/100, PIO Modes 3 and 4 and Bus Master IDE DMA Mode 4, and supports Enhanced IDE devices.
On-board ATA/100 IDE RAID (AX37D Plus Only)
1.
Supports data striping (RAID 0) and mirroring (RAID 1). Provides dramatic increase in drive performance and/or fault tolerant
options. Offers performance customization and data rebuilds from the BIOS menu. Mirroring supports automatic background
rebuilds. Fault tolerance can be restored automatically without rebooting.
2.
Supports up to four IDE drives which capacities are more than 8.4GB on the two IDE RAID connectors while still supporting
four IDE devices on the motherboard. The burst data transfer rates can up to 100MB/s from ATA/100 drives to boast overall
system performance.
3.
Supports IDE Bus Master operation allows multi-tasking during disk drives transfer which increase CPU efficiency, then the
CPU is free to process task during IDE data transfer through PCI bus interface to/from system memory.
X
3
7
D
P
r
o
X
3
7
D
P
r
o
Double-Data-Rate (DDR)
12
O
n
l
i
n
e
M
a
n
u
a
l
O
n
l
i
n
e
M
a
n
u
a
l
SDRAM. The DDR SDRAM
