Toyota Prius EH5 Installation Manual
Toyota Prius EH5 Installation Manual

Toyota Prius EH5 Installation Manual

Dual player headrest video

Advertisement

Quick Links

Document: 09.39.00
Toyota
Prius
Part Number: 00016-47210-01; 04; 11
Code : EH5
ATTENTION: SECURITY COVERS ARE NO LONGER INCLUDED IN THE HEADREST KITS AS OF 01/17/2011
Conflicts
Kit Contents
Item # Quantity Reqd.
1
2
2
2
3
2
4
1
5
1
6
1
7
1
9
2
10
8
11
1
12
1
13
1
14
4
Hardware Bag Contents
Item # Quantity Reqd. Description
1
2
2
2
3
12
4
1
5
1
Recommended Tools
Safety Tools
Seat/Floor Covers
Installation Tools
10mm Box end wrench Pliers
Nylon Removal Tool
10mm Socket
12mm Socket
Special Tools
Torque Wrench 48in/lbs
Special Chemicals
Southeast Toyota Distributors, LLC
Description
Headrest Assembly
Remote Control
Cables #3
Power Cord #9
Bag with Storage Straps
Metal Wire Puller
Owner's Manual
IR Headphones
AAA Batteries
Control Box
Hardware Bag
Fm Antenna
Cable Clamps
Red T-taps
10" Wire Ties
6" Wire Ties
4" x 8" Foam Tape
3"x1/2" Two Side Tape
Blankets
Wire Cutters
Ratchet
Nylon Removal Tool NRT
Page 1 of 15
PIO / DIO Rev. A
2011 -
Dual Player Headrest Video
Color Applicability/Trim Level
Vehicle Trim Color
Dark Gray
Misty Gray
Bisque
General Applicability
P riu s
03/15/11
X
X
X
